INSTALLER / CONSUMER
SAFETY INFORMATION
PLEASE READ THIS MANUAL
BEFORE INSTALLING AND USING
APPLIANCE.
WARNING!
IF THE INFORMATION IN THIS
MANUAL IS NOT FOLLOWED
EXACTLY, A FIRE OR EXPLOSION
MAY RESULT CAUSING
PROPERTY DAMAGE, PERSONAL
INJURY OR LOSS OF LIFE.
FOR YOUR SAFETY
Installation and service must be
performed by a qualified installer,
service agency or the gas suppler.
WHAT TO DO IF YOU SMELL
GAS:
•
Do not try to light any appliance.
•
Do not touch any electric switch; do
not use any phone in your building.
•
Immediately call your gas supplier
from your neighbor's phone. Follow
the gas supplier's instructions.
•
If you cannot reach your gas supplier,
call the fire department.
DO NOT STORE OR USE
GASOLINE OR OTHER
FLAMMABLE VAPORS AND
LIQUIDS IN THE VICINITY OF THIS
OR ANY OTHER APPLIANCE.
This appliance may be installed in an
after market permanently located
manufactured (mobile) home where not
prohibited by local codes.
This appliance is only for use with the
type of gas indicated on the rating plate.
This appliance is not convertible for use
with other gases unless a certified kit is
used.
Stardance
Natural Vent Gas Heater
Model SNV30: 3980-3996
Homeowner's Installation
and Operating Manual
7067
SDV fully assembled
cover
12/22/03
INSTALLER: Leave this manual with the appliance.
CONSUMER: Retain this manual for future reference.
C E R T I F I E D
20007067 1/07 Rev. 8
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Vermont Castings SNV30
Summary of Contents for Vermont Castings SNV30
-
Page 1: Safety Information
This appliance is not convertible for use with other gases unless a certified kit is used. Stardance Natural Vent Gas Heater Model SNV30: 3980-3996 Homeowner’s Installation and Operating Manual 7067 SDV fully assembled cover 12/22/03 INSTALLER: Leave this manual with the appliance. -
Page 2: Table Of Contents
Stardance Natural Vent Gas Heater PLEASE READ THE INSTALLATION & OPERATING INSTRUCTIONS BEFORE USING APPLIANCE. Thank you and congratulations on your purchase of a Vermont Castings stove. IMPORTANT: Read all instructions and warnings carefully before starting installation. Failure to follow these instructions may result in a possible fire hazard and will void the warranty. -
Page 3: General Information
The Stardance Natural Vent Room Heater, Model Nos. 3980- 3996 is a vented gas appliance listed to the ANSI standard Z21.88b-2002 and CSA-2.33b-2002 for Vented Room Heaters, and CSA 2.17-M91, Gas-Fired Appliances For Use at High Al- titudes. The installation of the Stardance Natural Vent Room Heater must conform with local codes, or in the absence of local codes, with National Fuel Gas Code, ANSI Z223.1/NFPA 54 —... -
Page 4: Stove Dimensions
Stardance Natural Vent Gas Heater Stardance Natural Vent Gas Heater Dimensions Fig. 1 Stardance dimensions. 9" (229mm) C L Valve Inlet 26���" (680 mm) Valve Inlet 3" (76 mm) 25" (635 mm) 7067 Stardance fully assembled dimensions 12/22/03 djt See Page 5 for Flue Collar Centerline Dimensions. -
Page 5: Clearance Requirements
Clearance Requirements Minimum Clearances to Combustible Materials Measure side clearances as shown in Figures 2 through 5 from the outer edge of the cast iron stove top. Measure rear clearances from the outermost surface of the sheet metal rear skirt. The Stardance heater is approved for installation into an alcove constructed of combustible materials to the dimensions and clearances shown on the next page. -
Page 6: Gas Specifications
Stardance Natural Vent Gas Heater Gas Specifications Model Fuel Gas Control SNV30RN Millivolt SNV30RP Prop Millivolt Weight: Fully assembled 350 lbs. Gas Inlet and Manifold Pressures Natural Inlet Minimum 5.5” w.c. Inlet Maximum 14” w.c. Manifold Pressure 3.5” w.c. Stardance Natural Vent Certified to: ANSI Z21.88-2005 / CSA Z2.33-2005 Vented Gas Fireplace Heaters... -
Page 7: Passing Through A Combustible Wall Or Ceiling
Passing Through a Combustible Wall or Ceiling An approved pass-through device is always required when a vent passes through a combustible wall or ceil- ing. Check with the maker of the vent system for the correct listed devices that are available. A listed pass- through device is required whether or not the installa- tion includes decorative pipe around the Type B venting system. -
Page 8: Installation
Stardance Natural Vent Gas Heater Unpack the Stove The Stardance is shipped fully assembled on its back. Unpack the stove and carefully set it upright. CAUTION Porcelain enamelled surfaces are fragile. Handle porcelain enamelled castings tenderly. Familiarize yourself with the assembly steps before you begin and proceed with deliberation and care. -
Page 9: Venting System Assembly
ST671 The SNV30 stove includes a spill switch. Operating this stove when not connected to a properly installed and maintained venting system, or tampering with or discon- necting the spill switch, can result in carbon monoxide (CO) poisoning and possible death. -
Page 10: Paint Option For Enamelled Stoves
Stardance Natural Vent Gas Heater Insert the B-vent adapter into the flue collar and drill 1/8” (3mm) pilot holes through both the stove’s collar and the adapter. Attach the adapter to the flue collar with sheet metal screws. (Fig. 15) Attach the first section of venting to the B-vent adapter. -
Page 11: Burner Information
Burner Information The appliance must only use the gas specified on the rating plate, unless converted using a Fuel Conversion Kit. Refer to Page 25 for the correct Fuel Conversion Kit for your model. Conversion instructions are provided with each kit and beginning on Page 16 in this manual. -
Page 12: Install The Front Plate
Stardance Natural Vent Gas Heater Left Log Rear Log Decorative Grate Fig. 19 Install the back, left and right logs. LG141 Stardance Install logs 1 12/11/00 djt Lava Rock Fig. 20 Completed log installation. LG142 Stardance Install logs 2 12/11/00 djt 1212 Install the Front Plate Hold the front plate by the window bars and lift it into... -
Page 13: Operation
The Stardance is operated with the operable door front plate in place with the doors open or closed. To open the front doors, insert the handle into the door latch stub and turn it to the left and up. (Fig. 22) When not in use, the handle may be stored in the handle holder on the right side of the rear shroud. -
Page 14: Lighting And Operating Instructions
Stardance Natural Vent Gas Heater Lighting and Operating Instructions FOR YOUR SAFETY READ BEFORE LIGHTING WARNING:If you do not follow these instructions exactly, a fire or explosion may result causing property damage, personal injury or loss of life. A. This heater has a pilot which must be lit manu- ally. -
Page 15: Troubleshooting
Troubleshooting / Honeywell #8420 Gas Control System NOTE: Before troubleshooting the gas control system, be sure the external gas shutoff is in the “ON” position. WARNING: REMOVE THE GLASS PANEL BEFORE PERFORMING ANY GAS CONTROL SERVICE WORK. SYMPTOM POSSIBLE CAUSES A. -
Page 16: Conversion Procedure
Stardance Natural Vent Gas Heater Fuel Conversion Instructions WARNING! This conversion kit shall be installed by a qualified service agency in accordance with the manufacturer’s instructions and all applicable codes and requirements of the authority having jurisdiction. If the information in these instruc- tions is not followed exactly, a fire, explosion or production of carbon monoxide may result causing property damage, personal injury or loss... - Page 17 Fig. 30 Remove mounting screws, pressure regulator tower and spring and diaphragm assembly. FC107 SIT820 valve conversion 10/03 Fig. 31 Replace regulator. FC108 3. Install the enclosed conversion label (F) to the valve body where it can easily be seen. (Fig. 31) regulator Pilot Orifice Conversion conversion...
- Page 18 Stardance Natural Vent Gas Heater 17. Replace burner. Slide the burner in at an angle with left side lower than the right side. Slide the left side onto the injectors, making sure the burner leg remains at a 90° angle to the base. Lower the right hand side down in to place.
-
Page 19: Maintenance
Your Stardance Gas Heater will provide years of service with minimal upkeep. The following procedures will help ensure that your stove continues to function properly. Annual System Inspection Have the entire heater and venting system inspected annually by a qualified gas technician. Replace any worn or broken parts. -
Page 20: Gasket Replacement
Stardance Natural Vent Gas Heater NOTE: Shown without top for clarity. Fig. 38 Release the latches to release the glass frame. Gasket Replacement The Stardance Gas Heater uses a ‘tadpole’ type gasket to seal between the glass panel and the frame. In time, this gasket can become brittle and compressed and should be replaced. -
Page 21: Wiring Diagrams
Wiring Diagrams On/Off Switch Wiring TP/TH Black Thermostat (Optional) Optional Thermostat Millivolt Gas Valve Wiring St124b on/off/switch wiring 1/11/00 djt TP/TH Black Fig. 41 On/off switch and optional thermostat circuit. NOTE: IF ANY OF THE ORIGINAL WIRE, AS SUP- PLIED WITH THE APPLIANCE, MUST BE RE- St124c PLACED, IT MUST BE REPLACED WITH TYPE SF-2, 200°C WIRE OR ITS EQUIVALENT. -
Page 22: Replacement Parts
Stardance Natural Vent Gas Heater 8a,b 42a,b CFM Corporation reserves the right to make changes in design, materials, specifications, prices and discontinue colors and products at any time, without notice. Stardance Natural Vent Gas Heater (SNV30) Models 3980-3996 Ref. Description SDV30 Log Set Assembly... - Page 23 Stardance Natural Vent Gas Heater (SNV30) Models 3980-3996 Ref. Description Lava Rock - Burner Gasket, Glass Med. Knit - RDV40 Glass, DV25 Glass Frame Assembly SDV30 Valve RN Honeywell VS8420E 2038 (Serial #’s up to 6361)* Valve RP Honeywell VS8420E 2020 (Serial #’s up to 6361)** Pilot Assembly 3Way N/DV RN 0.199.706...
- Page 24 Stardance Natural Vent Gas Heater Stardance Natural Vent Gas Heater (SNV30) Models 3980-3996 Ref. Description Right End 1/4” Fiberglass Gasket 42a. Valve Nova SIT820.662 RN (Serial #’s starting with 6362) 42b. Valve Nova SIT820.653 RP (Serial #’s starting with 6362)
-
Page 25: Optional Accessories
Optional Accessories Available Fan Kits FK26 Fan The FK26 fan kit helps distribute heated air from within the firebox out into the room. The fan is controlled by a snapstat that turns power on and off as the firebox tem- perature rises above and falls below a preset tempera- ture. - Page 26 Stardance Natural Vent Gas Heater Fig. 46 Screen in place. KT231 Screen in place 6/13/01 djt 2626 Warming Shelf Warming shelves add versatility to your stove and can be used to keep foods warm at mealtime. Model 2702 2684 2685 2688 2704 2706...
- Page 27 Stardance Natural Vent Gas Heater 20007067...
- Page 28 Stardance Natural Vent Gas Heater 2828 20007067...
- Page 29 Stardance Natural Vent Gas Heater 20007067...
-
Page 30: Warranty
Stardance Natural Vent Gas Heater PRODUCT COVERED BY THIS WARRANTY All Vermont Castings gas stoves, gas inserts, and gas fireplaces, and all Majestic or brand gas fireplaces equipped with an Insta-Flame Ceramic Burner, or standard steel tube burner. BASIC WARRANTY CFM Corporation (hereinafter referred to collectively as the Company) warrants that your new Vermont Castings or Majestic Gas Fireplace/ Stove is free from manufacturing and material defects for a period of... - Page 31 PRODUIT COUVERT PAR LA PRÉSENTE GARANTIE L’ensemble des cuisinières à gaz, des poêles encastrables et des foyers à gaz Vermont Castings, ainsi que l’ensemble des foyers à gaz de marque Majestic équipés d’un brûleur en céramique Insta-Flame ou d’un brûleur en acier standard. GARANTIE DE BASE La société...
-
Page 32: Efficiency Ratings
Efficiency Ratings Model EnerGuide Ratings Fireplace Efficiency (%) SNV30RN 51.1 SNV30RP 51.1 CFM Corporation 410 Admiral Blvd. • Mississauga, Ontario, Canada L5T 2N6 800-668-5323 • www.cfmcorp.com...
