Check Rotating Floor Brush and Drive Belt
You should check your vacuum cleaner's Rotating
Floor Brush and Drive Belt regularly for wear or
damage. You should also clean the brush and brush
ends of strings, hair, and carpet fibers. These can
wrap around the brush and hamper its ability to
effectively clean your carpet. Also remove any
debris that has accumulated under the brush cover.
Unplug cleaner from electrical outlet.
1.
Place handle in Low position and turn vacuum cleaner
2.
over so bottom side is up.
Remove the five screws as shown with a Screwdriver.
3.
Lift the Brush Cover off.
Grasp Rotating Floor Brush at both ends and lift.
4.
Clean strings, hair and other debris from Rotating Floor
5.
Brush, paying particular attention to brush ends.
Clean strings, hair and other debris from Motor Pulley and
6.
Drive Belt areas.
Check Drive Belt carefully for wear, cuts or stressed areas.
7.
Check Air Passageway for obstructions. Remove debris
8.
from this area.
Replace Drive Belt
Use only BISSELL Style 7 Replacement Belts in your
CleanView Bagless Power Trak Plus.
Unplug cleaner from electrical outlet.
1.
With Rotating Floor Brush removed from vacuum cleaner
2.
(Steps 1-4 of check Rotating Floor Brush and Drive Belt),
grasp old Drive Belt and remove from Motor Pulley.
Discard old Drive Belt.
Place new Drive Belt over Motor Pulley and stretch other end
3.
over Rotating Floor Brush in the space between the bristles.
Place ends of Rotating Floor Brush down into slots on
4.
sides as shown.
Turn Rotating Floor Brush by hand several times in the
5.
direction of Motor Pulley. If properly installed, Drive Belt
will center itself on Rotating Brush crown.
Reposition Brush Cover and screw or snap back into place.
6.
Check to be sure all screws are secure.
WARNING:
To reduce the risk of injury
from moving parts, turn
off vacuum cleaner and
disconnect Power Plug
from electrical outlet.
Wide Power Trak foot
Motor Pulley
Air Passageway
11
