Bissell Cleanview Turbo Manual

Blowing dust

1) Locate post-motor filter on back of vacuum. Press down on filter door tab to

remove door.

2) Clear away any debris build up on and around filter. Reattach filter door.

3) Remove dirt tank by pressing release button and lifting tank away from machine.

Updated by A. Lentz 10/7/2021 P:\Customer Service Dept\Knowledge Base\Troubleshooting\TROUBLESHOOTING GUIDES NEW

MODELS\VACUUM\Troubleshooting 1994U\1994U Blowing Dust.docx

Cleanview Turbo

1994U

Blowing Dust

Table of Contents

Do you have a question about the Cleanview Turbo and is the answer not in the manual?

Page 1 Cleanview Turbo 1994U Blowing Dust 1) Locate post-motor filter on back of vacuum. Press down on filter door tab to remove door. 2) Clear away any debris build up on and around filter. Reattach filter door. 3) Remove dirt tank by pressing release button and lifting tank away from machine.
Page 2 4) Over a trash bin, press empty latch on back of tank to empty tank. Snap shut bottom lid. 5) Separate top handle from bottom tank by grasping carry handle and base of dirt tank. Twist the carry handle counterclockwise. 6) Grasp filter handle and lift it out of dirt tank.
Page 3 9) To reassemble, align tabs on filter piece with their mating slots on the inner cyclone and twist clockwise. 10) Do the same to connect inner and outer cyclone pieces. Reinsert pieces into dirt tank. Filter should sit level. NOTE: filter will not sit level if tabs on front are not aligned Updated by A.
Page 4 11) Reattach top lid to dirt tank by aligning clear notch with slot on top lid. Clear notch should point towards unlocked. Twist clockwise to lock. 12) Reattach dirt tank to canister and turn on. If still blowing dust, remove hose to check for clog.
Page 5 16) Also, inspect hose section by section for holes or cracks. If a hole or crack is found, BISSELL Consumer Care: please refer to product changeover guide. External Support: Contact BISSELL 17) Reattach pieces by inserting them into their corresponding parts.

1994u
