Summary of Contents for Monte Carlo Fan Company 3HYR56**D Series
- Page 1 ’ wner anual Ceiling Fan Installation Instructions For 3hYr56XXd series Fans read and save These InsTrucTIOns Total fan weight with light kit...
-
Page 2: Tools Required
Installation aFeTY WARNING: TO REDUCE THE RISK OF FIRE, ELECTRIC SHOCK, OR INJURY TO PERSONS, OBSERVE THE FOLLOWING: READ AND SAVE THESE INSTRUCTIONS Installation work and electrical wiring must be done by qualified person(s) in accordance with applicable codes ANSI/NFPA 70-1999), including fire-rated construction. -
Page 3: Mounting Bracket
Thread leadwires and safety cable Loosen the 2 screws on the yoke to Insert down rod into yoke on top of through the downrod. allow down rod to slip into yoke. the fan body. Align the hole in the down rod with the hole in the yoke. Insert the Pin through the yoke and down rod until the point appears on the other side. - Page 4 Make wire connections to power source using wire nuts provided. Make sure that no filiments are outside of the wirenut. After making the wire connections, the Check motor for shipping stabilizers and wires should be spread apart with the grounded con- remove if present.
- Page 5 HAND HELD INSTALL WALL MOUNT INSTALL Remove battery cover. Install 12V battery into Place face plate over battery compartment and wall remote. Duracell MN21 / Eveready A23 / GP buttons. Place remote over 2 pins on front 23A all 12V.Attach cover of remote by placing cover.
- Page 6 remote control Transmitter Features: FAN REVERSE LED LIGHT (Press once to change direction of MEDIUM SPEED the fan)Fanmust be running to reverse. LOW SPEED HIGH SPEED FAN OFF SETTING LIGHT ON/OFF SET- (Turns fan off only) TING AND DIMMER (Press and hold to dim light infinitively) Fan speed Depress “l dot”...
- Page 7 ROUBLE HOOTING If you have difficulty operating your new ceiling fan, it may be the result of incorrect assembly, installation, or wiring. In some cases, these installation errors may be mistaken for defects. If you experience any faults, please check this Trouble Shooting Chart.
