Owner's Guide and Installation Manual
Attach sales receipt to this card and retain as your proof of purchase
DATE OF PURCHASE:
MODEL NUMBER:
To register your fixture, please visit our website www.montecarlofans.com
3AOR60XXX Series Fan
cETL Model NO. : 3AOR60XXX
RETAILER NAME:
RETAILER ADDRESS:
7.05 kg
15.51 lbs
Total fan weight
Advertisement
Related Manuals for Monte Carlo Fan Company 3AOR60 Series
Summary of Contents for Monte Carlo Fan Company 3AOR60 Series
- Page 1 Owner’s Guide and Installation Manual 3AOR60XXX Series Fan cETL Model NO. : 3AOR60XXX Attach sales receipt to this card and retain as your proof of purchase DATE OF PURCHASE: RETAILER NAME: RETAILER ADDRESS: MODEL NUMBER: To register your fixture, please visit our website www.montecarlofans.com 7.05 kg 15.51 lbs Total fan weight...
-
Page 2: Cautions And Warnings
Cautions and Warnings WARNING: TO REDUCE THE RISK OF FIRE, ELECTRIC SHOCK, OR INJURY TO PERSONS, OBSERVE THE FOLLOWING READ AND SAVE THESE INSTRUCTIONS Installation work and electrical wiring must be done by qualified person(s) in accordance with applicable codes and standards (ANSI/NFPA 70), including fire-rated construction. - Page 3 Mounting bracket Before you begin installing the fan, Switch Before installing this fan make sure the Use metal outlet box suitable for fan power off at Service panel and lock outlet box is properly installed to the support and use only the screws provided service disconnecting means to prevent house structure.
-
Page 4: Safety Cable Installation
SAFETY CABLE INSTALLATION Canopy Yoke cover Lag screw Safety cable Slot Washer Lock washer Place yoke cover and canopy over lead Install ball end of downrod into mounting For Canadian installation and for USA fan wires, safety cable and downrod, and then bracket opening. - Page 5 This side up Top plate Blade Coupler Adapter Blade bracket Install blade onto blade bracket with a top Install blade assembly. Align the holes on Install the adapter onto fan housing with plate by 4 blade screws provided. Tighten blade bracket with the screw holes on the set screws provided.
- Page 6 Remote Controller Operation Remove the battery cover from the remote control transmitter and install batteries. Replace the cover. This remote uses 2 1.5V/AAA batteries. Note: If not using for long periods of time, remove battery to prevent DIM (D) damage to remote transmitter, and store the remote transmitter away from excess heat or humidity ON/OFF (O) Dimming, Non Dimming Setting (Only available for fans with light)
- Page 7 Install Transmitter wall mount cradle with 2 screws provided. The receiver provides the following protective functions Lock protection- The DC motor has a build-in safety feature against blade obstruction during operation. If something obstructs the fan blades, the motor will stop operation after about 20 seconds of interruption.
-
Page 8: Troubleshooting
Trouble Shooting or wiring. In some cases, these installation errors may be mistaken for defects. If you experience any faults, installation, please call our Customer Service Center at the number printed on your parts list insert sheet. Warning means to prevent power from being switched on accidentally. When the service disconnecting means cannot be locked, securely fasten a prominent warning device, such as a tag, to the service panel. - Page 9 Jan.2020...
