Owner's Guide and Installation Manual
Attach sales receipt to this card and retain as your proof of purchase
DATE OF PURCHASE:
MODEL NUMBER:
To register your fixture, please visit our website www.montecarlofans.com
3DIR52XXD Series Fan
UL Model NO. : 3DIR52XXD
RETAILER NAME:
RETAILER ADDRESS:
8.2 kgs
18 lbs
Total fan weight with light
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Monte Carlo Fan Company 3DIR52XXD Series
Summary of Contents for Monte Carlo Fan Company 3DIR52XXD Series
- Page 1 Owner’s Guide and Installation Manual 3DIR52XXD Series Fan UL Model NO. : 3DIR52XXD Attach sales receipt to this card and retain as your proof of purchase DATE OF PURCHASE: RETAILER NAME: RETAILER ADDRESS: MODEL NUMBER: To register your fixture, please visit our website www.montecarlofans.com 8.2 kgs...
-
Page 2: Cautions And Warnings
Note: Suitable for use in damp locations. Tools Required for Assembly (not included): Electrical Tape, Phillips Screwdriver, Pliers, Safety Glasses, Stepladder and Wire Strippers Customer Service 800-969-3347 Customer Service Center 7400 Linder Ave. Skokie, IL 60077 www.montecarlofans.com © 2015 Monte Carlo Fan Company 9/15/2015... - Page 3 Place yoke cover on top housing of fan. Warning: Cross pin and keeper pin must be installed securely, failure to install them will result in serious injury. © 2015 Monte Carlo Fan Company 9/15/2015...
-
Page 4: Flush Mount Installation
Make sure the studs protruding from the up into the outlet box. bottom of the Mounting bracket are installed with threads all the way through the bracket. Go to step 20 to finish installation © 2015 Monte Carlo Fan Company 9/15/2015... -
Page 5: Safety Cable Installation
Insert the remote receiver into mounting : If Installing The Secondary Support bracket. Safety Cable in the U.S., Do Not Remove Refer to page 7 for receiver setting. Knockouts In The Outlet Box. © 2015 Monte Carlo Fan Company 9/15/2015... - Page 6 Attach LED light kit onto the light pan, aligning the keyhole slots on the LED light kit with the preassembled screws on the light pan. Twist clockwise till lock. Reinstall the screw which was just removed. Tighten all screws securely. © 2015 Monte Carlo Fan Company 9/15/2015...
- Page 7 Take remote transmitter up by pushing it at lower area of the Back side of the transmitter. wall mount cradle The remote transmitter can be held on magnetic metal material by a magnet built in the transmitter. Fig. 2 © 2015 Monte Carlo Fan Company 9/15/2015...
-
Page 8: Remote Control Setting And Operation
“OFF” button of the transmitter which you are using for at least 10 seconds. You must press the ‘OFF” button within 60 seconds of restoring power to the fan. © 2015 Monte Carlo Fan Company 9/15/2015... - Page 9 THIS DEVICE COMPLIES WITH PART 15 OF THE FCC RULES OPERATION IS SUBJECT TO THE FOLLOWING TWO CONDITIONS. (1)THIS DEVICE MAY NOT CAUSE HARMFUL INTERFERENCE AND (2) THIS DEVICE MUST ACCEPT ANY INTERFERENCE RECEIVED, INCLUDING INTERFERENCE THAT MAY CAUSE UNDESIRED OPERATION. © 2015 Monte Carlo Fan Company 9/15/2015...
-
Page 10: Troubleshooting
6.If this fan uses remote controller, make sure dip switches are setting properly and make sure battery is effective. CAUTION: Make sure main power is turned off before entering switch housing and/or canopy. © 2015 Monte Carlo Fan Company 9/15/2015... - Page 11 Sep.2015...
