BEFORE YOU BEGIN

Remove any lint from the wall exhaust opening.
Internal
Duct
Opening
STANDARD REAR EXHAUST
We recommend that you install your
dryer before installing your washer. This
will permit direct access for easier exhaust
connection.
Slide the end of the exhaust duct on the back
of the dryer and secure with duct tape or
a hose clamp.
Duct
NOTE: We strongly recommend using rigid metal
exhaust duct. If using semi-rigid metal duct,
cut it to the proper length and avoid bunching
of the duct behind the dryer.
• For straight-line installation, connect the dryer
exhaust to the wall, using duct tape.
Installation Instructions
Wall
Check that exhaust
hood damper opens
and closes freely.
Wall Side
Dryer
Side
RECOMMENDED CONFIGURATION
TO MINIMIZE EXHAUST BLOCKAGE
Using duct elbows will prevent duct kinking and
collapsing.
Transition
Ducting
27
