- Page 1 DIAMOND P R O D U C T S Operator’s Manual Core Cut MASONRY SAW MODEL: CC500M Part#: 1800739...
-
Page 2: Safety Precautions
SAFETY PRECAUTIONS Note: Failure to comply with following warnings could result in serious bodily injury! 1. Read and understand operator’s manual before operating saw. 2. Keep guards in place and in good condition when saw is in operation. 3. Always wear approved ear, eye, head and respiratory protection. 4. -
Page 3: Operating Instructions
OPERATING INSTRUCTIONS 1. Set saw frame on a sturdy, level surface. If using standard legs, insert them in square tubes under saw frame. Tighten wing screws before allowing frame’s weight to rest on legs. This will prevent the saw frame from wobbling on the legs, possibly cocking them in different directions, which will impair saw stability. - Page 4 5. For Saws With Electric Motors: Connect motor to a properly grounded outlet. Motor may be operated on 115 or 230 volts. Set switch on motor capacitor housing to match desired voltage. Plug on motor cord must also be changed to match correct voltage. WARNING: Always make sure that motor is connected to a properly grounded outlet.
- Page 5 b) Clamp or hold material firmly against the conveyor cart measuring stop. CAUTION: If material being cut is allowed to slip, blade may bind, damaging it. Do not cock, jam, wedge or twist the blade in the cut. Do not grind on the side of the blade. c) Push conveyor cart through blade at a reasonable, even rate that allows the blade to cut efficiently, but doesn’t bog down the engine or overload the motor.
- Page 6 Replace cord if damaged. 6. If you experience any problems with your electric motor or gas engine, contact Diamond Products for the nearest Authorized Service Center. If motor or engine is serviced by an unauthorized service center, the warranty will be voided.
- Page 7 SPECIFICATIONS Blade capacity: 14” Maximum Depth of Cut: 5” Arbor Size: 1” Blade drive: Matched set of 2 premium V-belts Models: CC515M-E1 Baldor Electric Motor, Spec. #35N301X136G1 1.5 Hp - 1 Phase, Totally Enclosed Fan Cooled 115/230 Volts, 60 Hz 13.4 Amps @ 115V / 6.7 Amps @ 230V 3450 RPM at Motor Output Shaft 2585 RPM at Blade Shaft...
