AHA-3940/3940W
MultiChannel SCSI-to-PCI Host Adapter
with SCSISelect
A
AAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAA
A A
AHA-3940/3940W User's Guide
A
A A
Stock Number: 510600-00, Rev. A
A A
A A
Print Spec Number: 492707-00
A A
Current Date: 8/24/94
A
AAAA AAAA
AAAA AAAA
AAAA AAAA
AAAA AAAA
AAAA AAAA
AAAA AAAA
AAAA
User's Guide
Page: Front Cover
ECN Date: 08/30/94
AAAA AAAA
AAAA AAAA
AAAA AAAA
AAAA AAAA
AAAA AAAA
AAAA AAAA
AAAA AAAA
AAAA AAAA
A
A A
A A
A A
A
A A
A A
AAAA A A
A A
Advertisement
Table of Contents
Troubleshooting
Subscribe to Our Youtube Channel
Related Manuals for Adaptec AHA-3940
Summary of Contents for Adaptec AHA-3940
- Page 1 User’s Guide AHA-3940/3940W MultiChannel SCSI-to-PCI Host Adapter with SCSISelect AAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAA AHA-3940/3940W User’s Guide Stock Number: 510600-00, Rev. A Page: Front Cover Print Spec Number: 492707-00 Current Date: 8/24/94 ECN Date: 08/30/94 AAAA AAAA AAAA AAAA AAAA AAAA AAAA AAAA AAAA AAAA...
- Page 2 Adaptec, Inc. 691 South Milpitas Boulevard Milpitas, CA 95035 Copyright © 1994, Adaptec, Inc. All rights reserved. Adaptec and the Adaptec logo are registered trademarks of Adaptec, Inc. Printed in Singapore STOCK NO.: 510600-00, Rev. A KL 8/94 AAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAA AHA-3940/3940W User’s Guide Stock Number: 510600-00, Rev.
- Page 3 AHA-3940/3940W MultiChannel SCSI-to-PCI Host Adapter with SCSISelect User’s Guide AAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAA Document Name Stock Number: 510600-00, Rev. A Page: i Print Spec Number: 492707-00 Current Date: 8/24/94 ECN Date: 08/30/94 AAAA AAAA AAAA AAAA AAAA AAAA AAAA AAAA AAAA AAAA AAAA AAAA...
- Page 4 Copyright Copyright © 1994 Adaptec, Inc. All rights reserved. No part of this publication may be reproduced, stored in a retrieval system, or transmitted in any form or by any means, electronic, mechanical, photocopying, recording or otherwise, without the prior written consent of Adaptec, Inc., 691 South Milpitas Blvd., Milpitas, CA 95035.
- Page 5 Ordering Software and Cables To order Adaptec software and SCSI cables, call 800-442-SCSI (7274), M–F: 6:00 a.m. to 5:00 p.m., Pacific Time. If you are calling from outside the U.S. and Canada, the num- ber is 408-957-SCSI (7274). Literature Hotline To request additional documentation for Adaptec products, call 800-934-2766, M–F: 5:00 a.m.
- Page 6 AAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAA Document Name Stock Number: 510600-00, Rev. A Page: iv Print Spec Number: 492707-00 Current Date: 8/24/94 ECN Date: 08/30/94 AAAA AAAA AAAA AAAA AAAA AAAA AAAA AAAA AAAA AAAA AAAA AAAA AAAA AAAA AAAA AAAA AAAA AAAA AAAA AAAA AAAA AAAA AAAA AAAA AAAA AAAA...
-
Page 7: Table Of Contents
Inserting the Host Adapter in a PCI Slot 2-5 Connecting SCSI Cables and Devices 2-7 Choosing SCSI Cables 2-7 Maximum Cable Lengths 2-7 AAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAA AHA-3940/3940W User’s Guide Stock Number: 510600-00, Rev. A Page: v Print Spec Number: 492707-00 Current Date: 8/24/94... - Page 8 AHA-3940/3940W User’s Guide Connecting Internal SCSI Devices 2-8 Connecting External SCSI Devices 2-11 Terminating the SCSI Bus 2-13 Terminating SCSI Devices 2-13 Terminating the Host Adapter 2-13 Terminating SCSI Channel A 2-14 Terminating SCSI Channel B 2-15 Setting SCSI IDs 2-15...
- Page 9 When to Use Extended Translation C-4 Drives With Mixed Partitions C-4 Using Fdisk C-4 Extended Translation Questions and Answers C-4 Glossary Index AAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAA AHA-3940/3940W User’s Guide Stock Number: 510600-00, Rev. A Page: vii Print Spec Number: 492707-00 Current Date: 8/24/94 ECN Date: 08/30/94 AAAA AAAA...
- Page 10 AAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAA AHA-3940/3940W User’s Guide Stock Number: 510600-00, Rev. A Page: viii Print Spec Number: 492707-00 Current Date: 8/24/94 ECN Date: 08/30/94 AAAA AAAA AAAA AAAA AAAA AAAA AAAA AAAA AAAA AAAA AAAA AAAA AAAA AAAA AAAA AAAA AAAA AAAA AAAA AAAA...
-
Page 11: List Of Figures
List of Figures Figure AHA-3940 Layout 2-4 AHA-3940W Layout 2-4 Inserting the Host Adapter 2-6 50-pin-to-68-pin Converter 2-8 Internal SCSI Ribbon Cable to Host Adapter 2-9 Internal SCSI Ribbon Cable to Internal SCSI Device 2-10 Connecting a Second Internal SCSI Device 2-10... - Page 12 SCSI Device Configuration Screen for AHA-3940W 3-12 3-11 Advanced Configuration Options Screen 3-16 3-12 SCSI Disk Utilities Screen for AHA-3940 3-19 3-13 SCSI Disk Utilities Screen for AHA-3940W 3-19 SCSI Devices Shared by Two Computers A-3 AAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAA AHA-3940/3940W User’s Guide Stock Number: 510600-00, Rev.
-
Page 13: Preface
SCSI Devices explains how to physically install the host adapter, including connecting the SCSI cables. Configuring Your Host Adapter Chapter 3 lists the default AHA-3940/3940W settings and explains how to change the configuration with the SCSISelect™ utility. Troubleshooting Chapter 4... -
Page 14: Conventions
AHA-3940/3940W User’s Guide Support for Large Disk Drives Appendix C describes Adaptec’s extended BIOS translation fea- ture, which allows you to use SCSI disk drives as large as 8 GBytes. Conventions The following typographic conventions are used in this User's Guide: bold Used for keystrokes (…... -
Page 15: Advisories
Advisories in this document can only cover the proce- dures contained here, and not all situations may have been addressed. Adaptec does not claim to have included every condition or situation that might require a Caution or Warning. You must refer to the... - Page 16 AAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAA AHA-3940/3940W User’s Guide Stock Number: 510600-00, Rev. A Page: xiv Print Spec Number: 492707-00 Current Date: 8/24/94 ECN Date: 08/30/94 AAAA AAAA AAAA AAAA AAAA AAAA AAAA AAAA AAAA AAAA AAAA AAAA AAAA AAAA AAAA AAAA AAAA AAAA AAAA AAAA...
-
Page 17: Introduction
Introduction About This Chapter Read this chapter to find out General information about AHA-3940/ 3940W host adapters Product features of AHA-3940/3940W host adapters Where to call if you need customer support AAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAA AHA-3940/3940W User’s Guide Stock Number: 510600-00, Rev. A... - Page 18 AAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAA AHA-3940/3940W User’s Guide Stock Number: 510600-00, Rev. A Page: 1-2 Print Spec Number: 492707-00 Current Date: 8/24/94 ECN Date: 08/30/94 AAAA AAAA AAAA AAAA AAAA AAAA AAAA AAAA AAAA AAAA AAAA AAAA AAAA AAAA AAAA AAAA AAAA AAAA AAAA AAAA...
-
Page 19: Host Adapter Overview
Channel A has both an internal and an external SCSI connec- tor; Channel B has only an internal SCSI connector. With the AHA-3940, you can connect up to seven 8-bit SCSI devices per channel. With the AHA-3940W, you can connect up to fifteen 16-bit (Wide) SCSI devices per channel. -
Page 20: Pci Bus Interface
It also automates SCSI command processing and significantly reduces interrupts and command over- head. Onboard BIOS allows AHA-3940/3940W host adapters to be used in place of, or together with, a standard hard disk controller. AHA-3940/3940W host adapters are capable of 32-bit bus master data transfers, including PCI enhanced data transfer commands. -
Page 21: Fast Data Transfer Rates
Concurrent support for 8-bit and 16-bit SCSI devices (AHA-3940W only) Single-ended output Scatter/Gather Disconnect/Reconnect Fully multitasking/multithreading AAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAA AHA-3940/3940W User’s Guide Stock Number: 510600-00, Rev. A Page: 1-5 Print Spec Number: 492707-00 Current Date: 8/24/94 ECN Date: 08/30/94 AAAA AAAA AAAA AAAA... -
Page 22: Multiple Device Support
Parity handling in Data, Message, Status, Selection/ Reselection, and Command phases Active negation Multiple Device Support AHA-3940 supports up to seven SCSI devices per channel (14 devices total) AHA-3940W supports up to 15 SCSI devices per channel (30 devices total) ®... -
Page 23: Adaptec Ez-Scsi
To install support for other kinds of SCSI devices such as optical disks, check the hardware documentation for those devices. If the device requires ASPI support, you first need to run Adaptec EZ-SCSI to install an ASPI manager, and then install any other soft- ware provided with the device. -
Page 24: Other Operating Systems
® OS/2, Windows NT, SCO UNIX , and USL UNIX (Unixware) operating systems. Contact Adaptec or your operating system ven- dor for information on operating system support. Support and Information Services AHA-3940/3940W host adapters are designed for easy installation and use. We have tried to make this document and our other docu- mentation complete and clear. -
Page 25: Installing Your Host Adapter And Scsi Devices
SCSI Devices About This Chapter Read this chapter to find out How to identify major components on AHA-3940/3940W host adapters How to install AHA-3940/3940W host adapters in your computer How to connect devices How to terminate the SCSI bus AAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAA AHA-3940/3940W User’s Guide... - Page 26 AAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAA AHA-3940/3940W User’s Guide Stock Number: 510600-00, Rev. A Page: 2-2 Print Spec Number: 492707-00 Current Date: 8/24/94 ECN Date: 08/30/94 AAAA AAAA AAAA AAAA AAAA AAAA AAAA AAAA AAAA AAAA AAAA AAAA AAAA AAAA AAAA AAAA AAAA AAAA AAAA AAAA...
-
Page 27: Overview
Your Host Adapter. You can install multiple AHA-3940/3940W host adapters in your computer if enough PCI bus slots are available. Each AHA-3940/ 3940W host adapter has two separate SCSI channels. If you install multiple AHA-3940/3940W host adapters in your computer, you can enable the onboard BIOS on just one host adapter or on more than one of the host adapters. -
Page 28: Host Adapter Layout
AHA-3940/3940W User’s Guide Host Adapter Layout Figures 2-1 identifies the major AHA-3940 components. Figure 2-2 identifies the major AHA-3940W components. The following table describes these components. Figure 2-1. AHA-3940 Layout Figure 2-2. AHA-3940W Layout Location Description Internal SCSI connector - Channel A... -
Page 29: Inserting The Host Adapter In A Pci Slot
Some computers have both bus master and non-bus master PCI slots. Read your computer documentation if you are not sure which kind of PCI slots your computer has. AAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAA AHA-3940/3940W User’s Guide Stock Number: 510600-00, Rev. A Page: 2-5 Print Spec Number: 492707-00... -
Page 30: Inserting The Host Adapter
AHA-3940/3940W User’s Guide Position the host adapter directly over the PCI slot and insert the end of the board in the card guide. Carefully press the bus connector on the bottom of the host adapter down into the slot, as shown in Figure 2-3. Be sure the metal contacts on the bottom of the host adapter are securely seated in the slot. -
Page 31: Connecting Scsi Cables And Devices
Adaptec sells high-quality internal and external SCSI-2 cables and 16-bit Wide SCSI cables. If your reseller does not stock these cables, call Adaptec directly at the number listed on page iii. Maximum Cable Lengths To assure reliable operation, the total length of the SCSI bus, includ- ing both internal and external cabling, should not exceed 6 meters (19.7 feet) if you are using asynchronous or synchronous data trans-... -
Page 32: Connecting Internal Scsi Devices
A 50-connector SCSI ribbon cable with a 50-pin connector for the AHA-3940 host adapter. (Or two cables if you are using both internal SCSI connectors.) A 68-connector SCSI ribbon cable with a 68-pin connector for the AHA-3940W host adapter. -
Page 33: Internal Scsi Ribbon Cable To Host Adapter
This is called maintaining proper pin-1 orientation. Maintain pin-1 orientation throughout the SCSI bus, or your SCSI devices will not work properly. AAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAA AHA-3940/3940W User’s Guide Stock Number: 510600-00, Rev. A Page: 2-9 Print Spec Number: 492707-00 Current Date: 8/24/94... -
Page 34: Internal Scsi Ribbon Cable To Internal Scsi Device
AHA-3940/3940W User’s Guide Plug the last connector on the ribbon cable into the SCSI con- nector on the internal SCSI device, as shown in Figure 2-6. Pin 1 Colored Stripe Internal SCSI Device Figure 2-6. Internal SCSI Ribbon Cable to Internal SCSI Device... -
Page 35: Connecting External Scsi Devices
Connecting External SCSI Devices You can daisy chain up to seven external SCSI devices to Channel A of the AHA-3940 and up to fifteen external SCSI devices to Channel A of the AHA-3940W. Daisy-chaining means that multiple devices can be connected using more than one cable. For example, a cable runs from the external SCSI connector to the first external device. -
Page 36: External Cable To External Scsi Device
AHA-3940/3940W User’s Guide Attach the connector at the other end of the external cable to either one of the SCSI connectors on the external SCSI device, as shown in Figure 2-9. External External SCSI Device SCSI Cable Figure 2-9. External Cable to External SCSI Device... -
Page 37: Terminating The Scsi Bus
Terminating the SCSI Bus SCSI termination must be enabled on the first and last physical devices on SCSI Channels A and B of your AHA-3940/3940W host adapter; otherwise, the devices will not operate properly. You may need to change the termination setting on some SCSI devices when you install them. -
Page 38: Terminating Scsi Channel A
AHA-3940/3940W User’s Guide Terminating SCSI Channel A SCSI Channel A has an external connector and an internal connector, as shown in Figures 2-1 and 2-2 on page 2-4. You can attach SCSI devices to one of the two connectors or to both connectors. -
Page 39: Terminating Scsi Channel B
You can change the ID(s) using SCSISelect, if necessary, but we recommend that you leave the ID for both channels at 7. 2-15 AAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAA AHA-3940/3940W User’s Guide Stock Number: 510600-00, Rev. A Page: 2-15 Print Spec Number: 492707-00 Current Date: 8/24/94... -
Page 40: Scsi Bus Activity Led Connector
SCSI IDs, preferably IDs 7 and 6. Note: The computer in which the AHA-3940/3940W host adapter is installed can share external SCSI devices with another computer. To do this, you must install a jumper before you install the host adapter. -
Page 41: Completing Installation
Internal SCSI devices are firmly connected to the host adapter and pin-1 orientation is correct External SCSI devices are firmly connected to the host adapter 2-17 AAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAA AHA-3940/3940W User’s Guide Stock Number: 510600-00, Rev. A Page: 2-17 Print Spec Number: 492707-00 Current Date: 8/24/94... -
Page 42: Running The Computer's Setup Program
Running the Computer’s Setup Program Normally, PCI-bus computers automatically configure the AHA-3940/3940W IRQ, port address, and BIOS address. In some cases, depending on what kind of motherboard BIOS your computer uses, you may need to run the computer’s Setup program to enable the PCI bus parameters before your computer can recognize the host adapter. -
Page 43: Configuring Your Host Adapter
Host Adapter About This Chapter Read this chapter to find out The default configuration settings for the channels on your AHA-3940/3940W host adapter When and how to change the configuration of the channels with the SCSISelect utility How to use the SCSISelect SCSI disk utilities... - Page 44 AAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAA AHA-3940/3940W User’s Guide Stock Number: 510600-00, Rev. A Page: 3-2 Print Spec Number: 492707-00 Current Date: 8/24/94 ECN Date: 08/30/94 AAAA AAAA AAAA AAAA AAAA AAAA AAAA AAAA AAAA AAAA AAAA AAAA AAAA AAAA AAAA AAAA AAAA AAAA AAAA AAAA...
-
Page 45: The Scsiselect Configuration Utility
Configuring Your Host Adapter The SCSISelect Configuration Utility AHA-3940/3940W host adapters include an onboard SCSISelect con- figuration utility that lets you change host adapter settings without opening the computer or handling the host adapter. SCSISelect also provides utilities for formatting SCSI disk devices and scanning them for defects. -
Page 46: When To Use Scsiselect
SCSI device connected to the host adapter. Download the executable version of SCSISelect from the Adaptec BBS by calling the phone number listed on page ii at the front of this User’s Guide. Then run the program by typing the file name at the DOS prompt and pressing Enter. -
Page 47: Selecting A Scsi Channel
Arrow keys to move cursor, <Enter> to select option, <Esc> to exit ( * =default) Figure 3-2. Selecting a SCSI Channel If there are two or three AHA-3940/3940W host adapters in your computer, this screen lists the channels on all the host adapters. For example, if you have two host adapters, you will see additional entries for Bus2:ChA and Bus2:ChB. -
Page 48: Using The Options Menu
Figure 3-3. Adaptec AHA-3940/3940W SCSISelect(TM) Utility v1.00 AHA-3940/3940W at Bus:Channel 01:A Would you like to configure the PCI device or run the SCSI disk utilities? Select the option and press <Enter>. Press <F5> to switch between color and monochrome modes. -
Page 49: Configure/View Host Adapter Settings
SCSI Parity Checking: Enable or disable parity checking. Host Adapter SCSI Termination: Enable or disable channel termination. Adaptec AHA-3940/3940W SCSISelect(TM) Utility v1.00 AHA-3940/3940W at Bus:Channel 01:A Configuration SCSI Channel Interface Definitions Host Adapter SCSI ID ........SCSI Parity Checking ........Enabled Host Adapter SCSI Termination ....... -
Page 50: Host Adapter Scsi Id
(the device having the higher ID has higher priority). The Host Adapter SCSI ID option on the Configuration menu allows you to change the channel SCSI ID. Figure 3-5 shows the available IDs (0 through 7) for each channel on the AHA-3940. Adaptec AHA-3940/3940W SCSISelect(TM) Utility v1.00... -
Page 51: Host Adapter Scsi Id Selection Screen For
SCSI bus. We recommend that you keep this setting. Adaptec AHA-3940/3940W SCSISelect(TM) Utility v1.00 AHA-3940/3940W at Bus:Channel 01:A Configuration SCSI Channel Interface Definitions Host Adapter SCSI ID ........Enabled SCSI Parity Checking ........ -
Page 52: Scsi Parity Checking
Highlight SCSI Parity Checking, then press Enter. The pop-up menu shown in Figure 3-7 appears. Highlight Enabled or Disabled, then press Enter. Adaptec AHA-3940/3940W SCSISelect(TM) Utility v1.00 AHA-3940/3940W at Bus:Channel 01:A Configuration SCSI Channel Interface Definitions Host Adapter SCSI ID ........SCSI Parity Checking ........Enabled Host Adapter SCSI Termination ...... -
Page 53: Host Adapter Scsi Termination
Advanced Configuration Options ..... Press <Enter> <F6> - Reset to Host Adapter Defaults Arrow keys to move cursor, <Enter> to select option, <Esc> to exit ( * =default) Figure 3-8. Host Adapter SCSI Termination Selection for AHA-3940/3940W 3-11 AAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAA AHA-3940/3940W User’s Guide Stock Number: 510600-00, Rev. -
Page 54: Scsi Device Configuration
This option allows you to configure certain parameters of each SCSI device on the SCSI bus. When you choose this option, a screen simi- lar to Figure 3-9 appears if you have an AHA-3940. If you have an AHA-3940W, a screen similar to Figure 3-10 appears. - Page 55 8.0 MBytes/sec 16 MBytes/sec 6.7 MBytes/sec 13.4 MBytes/sec 5.0 MBytes/sec 10.0 MBytes/sec 3-13 AAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAA AHA-3940/3940W User’s Guide Stock Number: 510600-00, Rev. A Page: 3-13 Print Spec Number: 492707-00 Current Date: 8/24/94 ECN Date: 08/30/94 AAAA AAAA AAAA AAAA AAAA AAAA...
- Page 56 AHA-3940/3940W User’s Guide In most cases, you can use the maximum value of 10.0. If the channel is set not to negotiate for synchronous data transfer (i.e., Initiate Sync Negotiation is set to no), then the value selected here is the maxi- mum rate that the channel accepts from the device during negotia- tion.
- Page 57 Scan feature to exclude the Channel A drives from the BIOS scan. Otherwise the host adapter BIOS will attempt to boot from the first 3-15 AAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAA AHA-3940/3940W User’s Guide Stock Number: 510600-00, Rev. A Page: 3-15 Print Spec Number: 492707-00...
-
Page 58: Advanced Configuration Options
Figure 3-11 appears. Do not change these five settings unless you fully understand what they mean. Adaptec AHA-3940/3940W SCSISelect(TM) Utility v1.00 AHA-3940/3940W at Bus:Channel 01:A Configuration Host Adapter Interface Definitions Advanced Configuration Options Host Adapter Interrupt <IRQ> Channel .... - Page 59 Channel BIOS This setting enables or disables the host adapter BIOS. The default setting is Enabled. Each AHA-3940/3940W host adapter has one BIOS, which operates on both SCSI channels. The BIOS must be enabled if you want the computer to boot from a SCSI hard disk drive connected to either channel of the host adapter.
-
Page 60: Saving Configuration Changes
AHA-3940/3940W User’s Guide Extended BIOS Translation for DOS Drives > 1 GByte This setting enables or disables extended translation for SCSI hard disks with a capacity greater than 1 GByte. The setting is valid only if the channel BIOS is enabled. The default setting is Enabled. -
Page 61: Scsi Disk Utilities
SCSI Disk Utilities When you select SCSI Disk Utilities from the Options menu, SCSISelect scans the SCSI bus and lists all installed SCSI devices. If you have an AHA-3940, a screen similar to Figure 3-12 appears. Adaptec AHA-3940/3940W SCSISelect(TM) Utility v1.00 AHA-3940/3940W at Bus:Channel 01:A Select SCSI Disk and press <Enter>... -
Page 62: Format Disk
MS-DOS fdisk and format . Most SCSI disk devices are preformatted and do not need to be for- matted again. The Adaptec Format Disk utility is compatible with most SCSI disk drives. Run it on hard disk drives or removable- media drives that were previously used with a non-Adaptec host adapter. -
Page 63: Configuring Multiple Host Adapters
Refer to your computer documentation to learn how to deter- mine the PCI slot number and slot number order. If you are booting from a drive connected to an AHA-3940/ 3940W and you are using ISA/EISA-based host adapters as secondary devices, disable the BIOS on all ISA/EISA-based host adapters. - Page 64 AAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAA AHA-3940/3940W User’s Guide Stock Number: 510600-00, Rev. A Page: 3-22 Print Spec Number: 492707-00 Current Date: 8/24/94 ECN Date: 08/30/94 AAAA AAAA AAAA AAAA AAAA AAAA AAAA AAAA AAAA AAAA AAAA AAAA AAAA AAAA AAAA AAAA AAAA AAAA AAAA AAAA...
-
Page 65: Troubleshooting
Troubleshooting About This Chapter Read this chapter to find out How to diagnose problems that may occur when you install an AHA-3940/3940W host adapter in your computer How to fix these problems AAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAA AHA-3940/3940W User’s Guide Stock Number: 510600-00, Rev. A... - Page 66 AAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAA AHA-3940/3940W User’s Guide Stock Number: 510600-00, Rev. A Page: 4-2 Print Spec Number: 492707-00 Current Date: 9/8/94 ECN Date: 08/30/94 AAAA AAAA AAAA AAAA AAAA AAAA AAAA AAAA AAAA AAAA AAAA AAAA AAAA AAAA AAAA AAAA AAAA AAAA AAAA AAAA...
-
Page 67: Scsi Troubleshooting Checklist
Troubleshooting SCSI Troubleshooting Checklist AHA-3940/3940W host adapters have been tested for compatibility with a wide range of SCSI devices. Most problems that occur during installation result from errors in preparing and connecting devices on the SCSI bus. If you need more assistance after reading this trou- bleshooting information, see Adaptec Technical Support on page ii. -
Page 68: Bios Startup Messages
AHA-3940/3940W User’s Guide BIOS Startup Messages After you install your host adapter, the host adapter BIOS displays a message when you boot your computer. Normally, this message lists the SCSI ID, manufacturer, model number, and other information for each SCSI device that the BIOS detects. If initialization fails, how- ever, the host adapter BIOS displays a specific error message fol- lowed by a BIOS Installation Failure message. - Page 69 Host adapter configuration error. The motherboard BIOS did not assign an IRQ to the host adapter. Run the CMOS Setup program and check the IRQ assignments. AAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAA AHA-3940/3940W User’s Guide Stock Number: 510600-00, Rev. A Page: 4-5 Print Spec Number: 492707-00...
-
Page 70: Disk Drive Configuration Problems
AHA-3940/3940W User’s Guide Disk Drive Configuration Problems This section describes situations that may occur if your computer has multiple disk drives, including combinations of standard disk drives and SCSI disk drives. Standard hard disk drives can be set to installed or not installed by the Setup program supplied with the host computer. -
Page 71: Using A Standard Drive As C And A Scsi Drive As D
Be sure that the disk is formatted and has a DOS partition. Run the Format Disk utility accessible through SCSISelect. See SCSI Disk Utilities on page 3-19. Check cable connections and pin-1 orientation. AAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAA AHA-3940/3940W User’s Guide Stock Number: 510600-00, Rev. A Page: 4-7 Print Spec Number: 492707-00 Current Date: 9/8/94... -
Page 72: Using Scsi Drives As C And D
AHA-3940/3940W User’s Guide Using SCSI Drives as C and D Make sure your computer's CMOS Setup program is set to No Drives Installed, as is required for SCSI host adapters. Be sure that the SCSI drive to be used as drive C is set to SCSI ID 0. -
Page 73: Other Problems And Solutions
04h - Hardware error The disk drive may be defective. Read the hardware documen- tation and contact the manufacturer. 05h - Illegal request The Adaptec formatting utility does not support a low-level AAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAA AHA-3940/3940W User’s Guide Stock Number: 510600-00, Rev. A... - Page 74 AHA-3940/3940W User’s Guide format of this device; however, the device may already be low- level formatted by the manufacturer. (This error rarely occurs.) 06h - Unit attention The removable media may be write-protected. Disable write protection and run the utility again.
-
Page 75: A Multiple Computer Configuration
Multiple Computer Configuration About This Appendix Read this appendix to find out How to configure an AHA-3940/3940W host adapter for use on a SCSI bus with two computers AAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAA AHA-3940/3940W User’s Guide Stock Number: 510600-00, Rev. A Page: A-1 Print Spec Number: 492707-00... - Page 76 AAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAA AHA-3940/3940W User’s Guide Stock Number: 510600-00, Rev. A Page: A-2 Print Spec Number: 492707-00 Current Date: 8/24/94 ECN Date: 08/30/94 AAAA AAAA AAAA AAAA AAAA AAAA AAAA AAAA AAAA AAAA AAAA AAAA AAAA AAAA AAAA AAAA AAAA AAAA AAAA AAAA...
-
Page 77: Overview
To allow computers to share SCSI devices, install a jumper shunt on the J5 (for Channel B) or J6 (for Channel A) termination jumper of your AHA-3940/3940W host adapter. Then connect the AHA-3940/ 3940W channel, the SCSI peripherals, and the host adapter in the second computer. -
Page 78: Restrictions And Requirements
The Adaptec host adapter in the second computer does not have to be an AHA-3940/3940W, but it must be capable of active termination when it is turned off. Most Adaptec host adapters can be actively terminated. Read the host adapter documentation to find out about this. -
Page 79: B Optimizing Performance
Optimizing Performance About This Appendix Read this appendix to find out How to optimize your computer’s perfor- mance after installing the AHA-3940/ 3940W host adapter AAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAA AHA-3940/3940W User’s Guide Stock Number: 510600-00, Rev. A Page: B-1 Print Spec Number: 492707-00... - Page 80 AAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAA AHA-3940/3940W User’s Guide Stock Number: 510600-00, Rev. A Page: B-2 Print Spec Number: 492707-00 Current Date: 8/24/94 ECN Date: 08/30/94 AAAA AAAA AAAA AAAA AAAA AAAA AAAA AAAA AAAA AAAA AAAA AAAA AAAA AAAA AAAA AAAA AAAA AAAA AAAA AAAA...
-
Page 81: Performance Tips
Optimizing Performance Performance Tips These tips will help you take full advantage of the AHA-3940/ 3940W advanced design features. Enabling Synchronous Negotiation Synchronous negotiation is a SCSI feature that allows the SCSI channel and its attached SCSI peripheral devices to negotiate for the transfer of data in synchronous mode on the SCSI bus. -
Page 82: Enabling Scsi Parity Checking
AHA-3940/3940W User’s Guide Enabling SCSI Parity Checking SCSI parity checking, which is enabled by default, verifies the accu- racy of data transfer on the SCSI channel. To use this option most effectively, be sure that it is enabled on each SCSI device, as well as on the SCSI channel. -
Page 83: C Support For Large Disk Drives
About extended translation and the DOS 1 GByte limit When to use the extended translation feature Answers to questions about extended translation AAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAA AHA-3940/3940W User’s Guide Stock Number: 510600-00, Rev. A Page: C-1 Print Spec Number: 492707-00 Current Date: 8/24/94 ECN Date: 08/30/94 AAAA AAAA... - Page 84 AAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAA AHA-3940/3940W User’s Guide Stock Number: 510600-00, Rev. A Page: C-2 Print Spec Number: 492707-00 Current Date: 8/24/94 ECN Date: 08/30/94 AAAA AAAA AAAA AAAA AAAA AAAA AAAA AAAA AAAA AAAA AAAA AAAA AAAA AAAA AAAA AAAA AAAA AAAA AAAA AAAA...
-
Page 85: Extended Translation (Using Ms-Dos 5.0
Support for Large Disk Drives Extended Translation (Using MS-DOS 5.0) Adaptec host adapters have always supported the full range of disk drive capacities under all major operating systems. As disk drives have recently grown beyond 1 GByte in formatted capacity, they have run up against the DOS 1024-cylinder limit. -
Page 86: When To Use Extended Translation
What if more than two hard disk drives are connected to the host adapter channel? Under MS-DOS 5.0 or above, each AHA-3940/3940W host adapter can support up to eight drives without additional software. To do this you must enable BIOS Support for More Than 2 Drives in SCSISelect. - Page 87 16-bit (Wide) SCSI bus, transfer and is not affected by external timing constraints, and the AHA-3940 is used with such as cable length and circuit an 8-bit SCSI bus. These two host adapter models are response time.
-
Page 88: Stock Number: 510600-00, Rev. A Page
AHA-3940/3940W User’s Guide used to boot and control the fer in multitasking operating computer. Most Adaptec host systems, such as Windows NT adapters include an onboard and OS/2. BIOS that initializes the SCSI Byte bus, runs boot-up diagnostics, An 8-bit unit of data. A byte is and performs other functions. -
Page 89: Stock Number: 510600-00, Rev. A Page
DOS is used on most per- tances than single-ended signals. sonal computers. Glossary-3 AAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAA AHA-3940/3940W User’s Guide Stock Number: 510600-00, Rev. A Page: Glossary-3 Print Spec Number: 492707-00 Current Date: 8/24/94 ECN Date: 08/30/94... - Page 90 AHA-3940/3940W User’s Guide DOS Partition EISA A section of a disk storage Extended Industry Standard device, created by the DOS fdisk Architecture. A kind of com- program, in which data and/or puter bus. EISA, an extension of software programs are stored.
- Page 91 ISA systems only. Industry Standard Architecture High Memory See Upper Memory Block. See ISA. Glossary-5 AAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAA AHA-3940/3940W User’s Guide Stock Number: 510600-00, Rev. A Page: Glossary-5 Print Spec Number: 492707-00 Current Date: 8/24/94 ECN Date: 08/30/94 AAAA AAAA...
- Page 92 AHA-3940/3940W User’s Guide Initiator sockets in the computer mother- A SCSI device that requests an board. ISA is sometimes called operation to be performed by the AT bus, because it was first another SCSI device (the target). used in the IBM PC/AT.
- Page 93 A term used to describe the puter. Examples are MS-DOS, AHA-3940/3940W and other UNIX, and Netware. Adaptec host adapters that have two or more independent SCSI channels. Parity Checking Multitasking Operation The execution of commands in...
- Page 94 PCI tion of internal SCSI cables. buses to communicate with each other. PPB enables AHA-3940/ 3940W host adapters to support See Programmed Input/Output. two PCI buses on one add-in card. The computer’s mother-...
- Page 95 SCSI fer can access many segments of interface standard and is Glossary-9 AAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAA AHA-3940/3940W User’s Guide Stock Number: 510600-00, Rev. A Page: Glossary-9 Print Spec Number: 492707-00 Current Date: 8/24/94 ECN Date: 08/30/94...
- Page 96 AHA-3940/3940W User’s Guide attached to a SCSI bus cable. The components. Most SCSI devices device may be an initiator, a tar- use single-ended grounding. get, or capable of both types of Single-ended is less expensive operation. than differential SCSI and allows...
- Page 97 Glossary Termination computer you can load software programs such as Adaptec’s A physical requirement of the ASPI managers and ASPI mod- SCSI bus. The devices at the physical ends of the SCSI bus ules in upper memory blocks. must have terminating resistors This frees up more conventional either installed or enabled;...
- Page 98 AAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAA AHA-3940/3940W User’s Guide Stock Number: 510600-00, Rev. A Page: Glossary-12 Print Spec Number: 492707-00 Current Date: 8/24/94 ECN Date: 08/30/94 AAAA AAAA AAAA AAAA AAAA AAAA AAAA AAAA AAAA AAAA AAAA AAAA AAAA AAAA AAAA AAAA AAAA AAAA AAAA AAAA...
- Page 99 C-3 support 3-17 startup messages 4-4 fdisk command C-4 Index-1 AAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAA AHA-3940/3940W User’s Guide Stock Number: 510600-00, Rev. A Page: -1 Print Spec Number: 492707-00 Current Date: 8/24/94 ECN Date: 08/30/94 AAAA AAAA AAAA AAAA...
- Page 100 AHA-3940/3940W User’s Guide Enable Disconnection 3-3, 3-14, B-4 I/O Operating Environment 1-6 Extended Translation 3-3, 3-18, 4-4, I/O, Multithreaded 1-4 C-3, C-4 External SCSI Device See SCSI ID using with multiple Information Services 1-8 computers A-4 Initiate Sync Negotiation 3-3, 3-13,...
- Page 101 Index SCSI ID for AHA-3940/3940W 3-3, 3-8 Parity Checking 3-3, 3-10, B-4 conflicts with 4-6 Partitions 4-7, C-4 for peripheral devices 3-13 PCI Bus purpose of 2-15 automatic configuration 2-18 setting 2-15 interface 1-4 SCSI-2 PCI Slot cable standards 2-7...
- Page 102 AHA-3940/3940W User’s Guide USL UNIX 1-8 Utilities format disk 3-20, 4-4 verify disk media 3-20 Verify Disk Media 3-20 Wide Negotiation 3-3 Windows 1-6 Windows NT 1-8 Index-4 AAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAA AHA-3940/3940W User’s Guide Stock Number: 510600-00, Rev. A Page: -4 Print Spec Number: 492707-00...
