Ordering Information - Interlogix TruVision Line Specifications

Megapixel
IP Cameras
1.3 CCD or 2 CMOS MPX
Progressive Scan IP Cameras

Ordering Information

Cameras
TVC-M1120-1-N TruVision
TruVision 2.0MPX Prog. Scan CMOS Box, 720P 15FPS, Elec. D/N, POE/12VDC/24VAC, NTSC
TVC-M2110-1-N
TruVision 1.3MPX Prog. Scan CCD IP66 Vandal Dome, 720P 24FPS, True D/N, VF 3.3-12MM,
TVD-M1120V-3-N
POE/12VDC/24VAC, NTSC
TruVision 2.0MPX Prog. Scan CMOS IP66 Vandal Dome, 720P 15FPS, Elec. D/N, VF 3-9MM,
TVD-M2110V-3-N
POE/12VDC/24VAC, NTSC
TVD-M2110-2-N TruVision 2.0MPX Prog. Scan CMOS Dome, 720P 15FPS, Elec. D/N, VF 2.8-11MM, POE/12VDC/24VAC, NTSC
Note: For PAL Models, replace the "N" at the end of the Part Number. Example: TVC-M1120-1-P
Dimensional Diagrams
TVC-M1120-1-N
2.71 in.
(68mm)
2.57 in.
(65mm)
TVD-M1120V-3-N, TVD-M2110V-3-N
6.30 in.
(160mm)
3.95 in.
(100.3mm)
Specifications subject to change without notice.
© 2011 Interlogix, A UTC Fire & Security Company
All rights reserved.
102-3396 2011/06 (65150)
North America
T 888-437-3287
1.3MPX Prog. Scan CCD Box, 720P 24FPS, True D/N, POE/12VDC/24VAC, NTSC
™
6.25 in.
(158mm)
5.79 in.
(147mm)
G
3-MO5
5.13 in.
(130.4mm)
Asia Australia
T 852-2907-8108 T 61-3-9239-1200
F 852-2142-5063 F 61-3-9239-1299
TVC-M2110-1-N
2.57 in.
(65mm)
TVD-M2110-2-N
6.25 in.
(158mm)
3
4
4.25 in.
(108mm)
Europe Latin America
T 32-2-725-11-20 T 561-998-6100
T 32-2-721-40-47 T 561-994-6572
6.25 in.
(158mm)
5.79 in.
(147mm)
4.72 in.
(120mm)
