The commands in Figure 8.1 in order of appearance (Audit Report fields shown in
bold).
&&??&%
&%STFPASSWORD$
&%SMCP0001$
&%SAR$
&%STP10001$
&%STP00200$
&%1B26...3358$
&%SQ1200$200
&%1B$(s1p16v0s3b4148T
&%1B$(3@
&%SQ6October 5, 2005$
&%SMF$2014.44~
&%1B$(s0p12h10v1s0b4099T
&%1B$(3@
&%SQ4$2104.44~
&%SQ3Vendor Systems $
&%1B$(200X!
Source Technologies, LLC
Hex transfer enable.
Password command.
MICR definition command with the count set to one.
Activates Audit Report recording.
Unlock flash resource number 10001.
Unlock flash resource number 200.
PCL sequence in hex which sets the page format and
enables macro number 10001.
Stores the vendor number 200 in the first position of
the Audit Report. Note that this field will not be sent to
the page to be printed. Here we send the field again so
that it will print.
PCL sequence which changes the font to Univers 16
point. After the check serial numbers prints (100), the
printer is returned to its default font with the following
command.
PCL command to return to default font.
Stores the date in the sixth position of the Audit
Report.
Prints Secure Font command. NOTE: Tilde (~) is
command terminator.
PCL command to change the font to Courier 12 pitch
Italic. See print PCL Fonts on the Front Panel under
the test menu for a printout with the call commands.
PCL command to return to the default font.
Stores the amount in the fourth position of the Audit
Report.
Stores the payee, Vendor Systems, in the third
position of the Audit Trail report.
PCL command to print font number 200. In this
example font 200 is a signature previously loaded into
