G.SHDSL Four-Wire Ethernet Network Extender Kit
Extend Ethernet with full-duplex transmission
up to 10.8 Mbps over two pairs of copper.
Complies with ITU-T Rec. G.991.2 G.shdsl.bis standards.
Reaches distances up to 22,500 feet over 26 AWG twisted-pair cable.
Rate adaptive from 192 kbps to 4.608 Mbps on one pair or 384 kbps
to 9.216 Mbps on two pairs.
Has two RJ-45 connectors for 10BASE-T/100BASE-TX Ethernet ports
for combining two separate Ethernet data streams over the same
G.SHDSL link.
Includes console port for network management configuration.
Order toll-free in the U.S.: Call 877-877-BBOX (outside U.S. call 724-746-5500) •
Customer
FREE technical support 24 hours a day, 7 days a week: Call 724-746-5500 or fax 724-746-0746 •
Support
Mailing address: Black Box Corporation, 1000 Park Drive, Lawrence, PA 15055-1018 •
Information
Web site: www.blackbox.com • E-mail: info@blackbox.com •¶
BLACK BOX
LR0202A-KIT
®
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Black Box LR0202A-KIT
Summary of Contents for Black Box LR0202A-KIT
-
Page 1: Black Box
Order toll-free in the U.S.: Call 877-877-BBOX (outside U.S. call 724-746-5500) • Customer FREE technical support 24 hours a day, 7 days a week: Call 724-746-5500 or fax 724-746-0746 • Support Mailing address: Black Box Corporation, 1000 Park Drive, Lawrence, PA 15055-1018 • Information Web site: www.blackbox.com • E-mail: info@blackbox.com •¶... - Page 2 G.SHDSL Four-Wire Ethernet Network Extender Kit Trademarks Used in this Manual Black Box and the Double Diamond logo are registered trademarks of BB Technologies, Inc. Any other trademarks mentioned in this manual are acknowledged to be the property of the trademark owners.
- Page 3 FCC and IC RFI Statements Federal Communications Commission and Industry Canada Radio Frequency Interference Statements This equipment generates, uses, and can radiate radio-frequency energy, and if not installed and used properly, that is, in strict accordance with the manufacturer’s instructions, may cause inter ference to radio communication. It has been tested and found to comply with the limits for a Class A computing device in accordance with the specifications in Subpart J of Part 15 of FCC rules, which are designed to provide reasonable protection against such interference when the equipment is operated in a commercial environment.
- Page 4 G.SHDSL Four-Wire Ethernet Network Extender Kit Normas Oficiales Mexicanas (NOM) Electrical Safety Statement INSTRUCCIONES DE SEGURIDAD 1. Todas las instrucciones de seguridad y operación deberán ser leídas antes de que el aparato eléctrico sea operado. 2. Las instrucciones de seguridad y operación deberán ser guardadas para referencia futura. 3.
- Page 5 CE Statement European Community (CE) Electromagnetic Compatibility Directive This equipment has been tested and found to comply with the protection requirements of European Emission Standard EN55022/EN61000-3 and the Generic European Immunity Standard EN55024. EMC: EN55022(2003)/CISPR-2( 2002): Class A IEC61000-4-2 (2001): 4 KV CD, 8 KV AD IEC61000-4-3( 2002): 3 V/m IEC61000-4-4(2001): 1 KV (power line), 0.5 KV (signal line) Page 5...
-
Page 6: Table Of Contents
G.SHDSL Four-Wire Ethernet Network Extender Kit 1. Specifications ......................................7 2. Overview ......................................8 2.1 Introduction ....................................8 2.2 Features ......................................8 2.3 Application ..................................... 9 2.4 What’s Included ..................................... 9 2.5 LED Descriptions ..................................... 9 2.6 Front and Back Panels ..................................10 3. -
Page 7: Specifications
Chapter 1: Specifications 1. Specifications Standards: ITU-T G.991.2 Compliance, TCPAM-16 Level Line Code, IEEE 802.3/IEEE 802.3u, EMI emissions standard, FCC Part 15 Class A, CE Mark Adaptive Data Rate: 1-pair SHDSL mode: 4.608 Mbps to 192 kbps; 2-pair SHDSL mode: 9.216 Mbps to 384 kbps Fixed Data Rate: 1-pair SHDSL mode: 64 kbps to 5.696 Mbps;... -
Page 8: Overview
VoIP applications over two twisted pairs. Over one pair of 26 AWG (0.5 mm) copper twisted-pair wire, the LR0202A-KIT sends data up to 12,000 feet (2.3 miles, about |3.7 km) at 2.304 Mbps and 4500 feet (about 0.8 miles, 1.3 km) at the maximum rate of 10.8 Mbps. It can also reach 5500 feet (1 mile, 1.6 km) at 9.216 Mbps over two pairs of 26 AWG (0.5 mm) copper twisted-pair wire, and go 22,500 feet (about 6.8 km) -
Page 9: Application
Internet Figure 2-1. Sample application. 2.4 What’s Included Your package should include the following items. If anything is missing or damaged, please contact Black Box Technical Support at 724-746-5500. • (2) G.SHDSL Four-Wire Ethernet Network Extenders • (2) Power cords •... -
Page 10: Front And Back Panels
G.SHDSL Four-Wire Ethernet Network Extender Kit 2.6 Front and Back Panels LED Indicators RS-232 Console Port Figure 2-2. Front panel. Power Input RJ-48 Connector RJ-45 Connectors Power Switch Figure 2-3. Rear panel. 724-746-5500 | blackbox.com Page 10... -
Page 11: Installation
6. Both G.SHDSL Four-Wire Ethernet Network Extenders will automatically connect with each other. NOTE: Turn on the power switch, and the LR0202A-KIT will then run self-test routines. There will be two or more handshaking cycles when adaptive rate is selected. The system will automatically adapt to the maximum rate according to the loop distances. -
Page 12: Console Configuration
G.SHDSL Four-Wire Ethernet Network Extender Kit 4. Console Configuration The LR0202A-KIT provides an RS-232C console port for user to monitor the OA&M status through a VT100 terminal. This section covers the operating procedures and settings for all screen selections. Connect the RS-232 cable to the computer’s COM port as shown in Figure 4-1. Set the personal computer to VT100 or VT102 type through HyperTerminal. -
Page 13: Main Menu
Chapter 4: Console Configuration 4.1. Main Menu The Main Menu screen enables you to access the LR0202A-KIT unit’s Configuration and Status screens. For details, refer to Figure 4-2. Welcome to G. Shdsl Ethernet Network Extender User Interface Main Menu 1. Configuration 2. -
Page 14: Configuration Screen
G.SHDSL Four-Wire Ethernet Network Extender Kit 4.2. Configuration Screen The Configuration screen will display the LR0202A-KIT unit’s connection selections. The screen includes three settings selections: DSL Mode, DSL Speed, and Default Configuration. Configuration 1. DSL Mode 2. DSL Speed 3. Default Configuration... -
Page 15: Dsl Speed Screen
Extenders, set one unit to STU-C (CO Site) and the other unit to STU-R (Remote Site). 2P/1P: 2P/1P has 2 options: 1 Pair and 2 Pairs. LR0202A-KIT supports both 1-pair and 2-pair SHDSL applications. To establish a successful connection for LR0202A-KIT, set the two units to the same selection. -
Page 16: Default Configuration Screen
When Default Configuration is selected, all the settings of the LR0202A-KIT will go back to default settings. In the screen shown in Figure 4-7, the setting is finished. Press the <ESC> key to go back to the previous screen. The LR0202A-KIT’s default set-... -
Page 17: Status Screen
Chapter 4: Console Configuration 4.3. Status Screen The Status screen shows the LR0202A-KIT’s connection status. The screen covers two selections: System Information and System Status. Status 1. System Information 2. System Status Select (1-2): [ENTER] select [ESC] quit Figure 4-8. Status screen. -
Page 18: System Status Screen
G.SHDSL Four-Wire Ethernet Network Extender Kit 4.3.2. System Status Screen DSL mode: Indicates the current DSL mode setting. Speed setting: Indicates the current DSL speed setting. Speed actual (kbps): Indicates the actual DSL speed in kilobits per second. Link status of Pair #1: Indicates the DSL connection status (either up or down) for Pair #1. Link status of Pair #2: Indicates the DSL connection status (either up or down) for Pair #2. - Page 19 NOTES 724-746-5500 | blackbox.com Page 19...
- Page 20 About Black Box Black Box Network Services is your source for an extensive range of networking and infrastructure products. You’ll find everything from cabinets and racks and power and surge protection products to media converters and Ethernet switches all supported by free, live 24/7 Tech support available in 30 seconds or less.
