Specifications
Bus Interface
PCI Express rev 1.1
Chipset ID
PLX OXPCIe952
Serial UART
16C950
2 x DB9 male
Connectors
(via external ribbon cable)
Serial Protocol
RS232
Maximum Data Transfer Rate
460Kbps
Operating Temperature
-20°C ~ 85°C (-4°F ~ 185°F)
Storage Temperature
-40°C ~ 85°C (-40°F ~ 185°F)
Humidity
5 ~ 85% RH
Dimensions
50.0mm x 30.0mm
Weight
6g
Windows 2000/XP/Server 2003/
Compatible Operating
Vista/Server 2008 R2/7 (32/64-
Systems
bit), Linux kernel 2.4 or later
5
