Specifications - StarTech.com MPEXUSB3S2 Instruction Manual

Specifications

PCI Express Mini Card
Host Interface
specification 1.2
Full Length Mini PCIe
Form Factor
Full/Low Profile Card Bracket
Chipset ID
NEC uPD720200
External Connectors
2 x USB 3.0 type A female
Internal Connectors
1 x SP4 power male
USB 3.0 revision 1.0
Supported Standards
Intel xHCI revision 0.96
Maximum Data Transfer Rate USB 3.0: 5 Gbps
Operating Temperature
0°C ~ 85°C (32°F ~ 185°F)
Storage Temperature
-65°C ~ 125°C (-85°F ~ 257°F)
Dimensions (LxWxH)
50.0mm x 30.0mm x 3.0mm
Weight
70.4g
Windows 2000/XP/Server
Compatible Operating
2003/Vista/Server 2008 R2/7
Systems
(32/64-bit)
4
