PCX924e & PCX924e-Mic, PCX22e

REQUIREMENTS

Minimum hardware requirements

PC with one free PCI EXPRESS
CPU power and memory required depend on the operating system and on the
audio application used.

Software requirements

To use your PCX924e, PCX924e-Mic or PCX22e, install the driver from the
np Runtime HR package version 1.70 or higher.
This package includes:
•
a Digigram np driver enabling OEM applications to best capitalize on the
boards
•
a WDM DirectSound driver
•
an ASIO driver (32 bits, installation optional)
•
a Wave driver

Supported operating systems

PCX924e, PCX924e-Mic, and PCX22e cards run under Windows XP, Server
2003, Windows Vista, Server 2008, and Windows 7.

HARDWARE INSTALLATION

Due to the reduced length of the PCI EXPRESS
and the resulting lack of mechanical stability, we strongly advise
against transporting the card(s) installed in a computer, unless its
chassis or case provides a dedicated support to keep the card
securely in place in order to avoid physical damage.
The card has to be installed in the computer prior to installing its driver.

Installing the card

Gently plug the card in a free PCIe
firmly. Tighten the screw.

Interrupt and memory address

Hardware interrupt and addresses are automatically set up at start-up by the
PCI PnP BIOS.
∗
Windows XP and Server 2003 only
TM
(PCIe
∗
(32 bits, installation optional)
®
) slot (x1, x2, x4, x8, x16 or x32).
®
slot and press it down to position it
User manual
TM
bus connector
9
