Pcx924E, Pcx924E-Mic, And Pcx22E Main Software Features - Digigram PCX924e User Manual

•
1 AES/EBU
(Always plays the digital version of the analog outputs 1 and 2)
•
1 LTC (Linear Time Code) input
•
1 mini jack stereo headphone output
(This output is in parallel of the analog outputs 1 and 2)
•
2 General Purpose inputs and 2 outputs (GPIOs)
PCX924e, PCX924e-Mic, and PCX22e
Main software features
•
Real-time, simultaneous record and playback in PCM (8, 16 and 24 bits)
as well as in MPEG Audio Layer I, Layer II and Layer III , Float IEEE754
conversion supported (with 24-bit fixed-point dynamic range)
•
When using the np SDK, real-time mixing of several PCM and MPEG
audio streams, direct monitoring, level adjustment, panning, cross-fades,
punch-in/punch-out, scrubbing, time-stretching, pitch-shifting, 3-band
parametric equalizer, maximizer, format and frequency conversions
•
Low latency DirectSound, ASIO, and Wave
and ASIO, the cards operate in PCM mode only (nevertheless, an
application can integrate coders/decoders on the host PC). Under Wave,
the boards can operate in both PCM and MPEG (layer 1 and layer 2).
MPEG Layer III play-only on DSP;
MPEG Layer III recording on the host computer is available through
Digigram's PC Codec option using the np SDK
Note: the HR Runtime package for Windows Vista does not include a Wave driver.
In case your audio application explicitly requires a Wave interface, a Wave
driver is available on request. In this case, please contact Digigram.
∗
can be used as S/PDIF interface as well
∗∗
Windows XP and Server 2003 only
8
∗
stereo output
∗∗
drivers. Under DirectSound
