Page 1 PCX 22 P r o f e s s i o n a l A u d i o C a r d User’s manual...
Page 2 Digigram. The copyright protection claimed here includes photocopying, translation and/or reformatting of the information contained in this manual. Digigram is not responsible for errors and omissions and reserves the right to make improvements or changes without prior notice. Digigram and Xtrack are registered trademarks of Digigram. PCXpocket, PCXtools and PCX Designer Kit are trademarks of Digigram.
Page 3 PCX 22 User’s Manual INFORMATION FOR THE USER This device complies with part 15 of FCC rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) This device must accept any interference received, including interference that may cause undesired operation.
Page 4 • One digital sync input. Hardware requirements • One card slot, PCI 2.1 compliant. • One available IRQ line. Software requirements • Digigram npRuntime version 5.31 or higher (includes Wave driver). Available options • Analog breakout cable • Digital breakout cable Hardware installation Installing the card Check for a free PCI expansion slot and gently insert the card.
Page 5 PCX 22 User’s Manual SPECIFICATIONS Audio outputs Analog outputs • 2 balanced analog outputs (can be used as unbalanced). • maximum level: +22dBu (software adjustable) • output impedance < 100Ohms. • 24 bit digital to analog converters (64 x oversampling delta-sigma).
Page 6 LAYOUT AND CONNECTIONS Layout Connectors J1 - Headphone (3.5 mm TRS female jack) Contact Signal sleeve ground left channel ring right channel J2 - Analog Audio connector. (sub-D 15, female) pin # Signal pin # Signal R Out + R Out – L Out + LOut –...
Page 7 PCX 22 User’s Manual J3 - Digital connector (Sub-D15 high density, female) pin # Signal pin # Signal AES/EBU SYNC – AES/EBU SYNC + AES/EBU OUT+ AES/EBU OUT – Switches All switches are factory set to “on”. To insure a proper use of this card, they must not be changed.
Page 8 Digigram S.A France E-mail : info@digigram.com Digigram Inc. USA E-mail : input@digigram.com Digigram Asia Pte Ltd E-mail : info_asia@digigram.com www.digigram.com DU 145800101 IS=B...
