Installation

Location

When installing the DIN-Rail Industrial Fiber Media Converter, ensure that
the chosen location has a temperature between -10° and 60° Celsius and
a relative humidity less than 95%, non-condensing.

Physical Installation

To install the DIN-Rail Industrial Fiber Media Converter onto a DIN rail,
lower the converter onto the DIN rail from above using the slot. Push the
front of the converter toward the mounting surface until it audibly snaps
into place. Once the converter is in place, connect a DC power adapter to
the DC terminal on the rear of the converter, then plug the adapter into a
standard DC outlet.

Network Connection

When connecting the
network, ensure that both the converter and the devices being connected
to it are powered off and that all connecting cables are available. The fol-
lowing chart dictates the correct cable for each speed and distance:
Speed
10Base-T
100Base-TX
100Base-FX
100Base-FX
Instruction Manual
DIN-Rail Industrial Fiber Media Converter to the
Port Speed
Connector
RJ-45 10/20 Mbps
RJ-45
SC, ST
SC, ST
Half/Full
Duplex
2-pair UTP/STP
100/200
Mbps
100/200
Mbps
100/200
SMF (9 or 10μm)
Mbps
2
Cable
Cat. 3, 4, 5
2-pair UTP/
STP Cat. 5
MMF
(50 or 62.5μm)
Max.
Distance
100 m
100 m
2 km
15, 40,
75km
