FS-8704-14 EtherNet/IP Manual
4.2

Client Side Connection Descriptions

Section Title
Adapter
Column Title
Adapter
Protocol
Example
// Client Side Connections
Adapters
Adapter
N1
4.3

Client Side Node Descriptors

Section Title
Nodes
Column Title Function
Node_Name Provide name for node
IP_Address Address of Server
Protocol Specify protocol used
Adapter Specify port Adapter used
Example
// Client Side Nodes
Nodes
Node_Name ,IP_Address
PLC 1 ,192.168.1.174
2
Not all ports shown are necessarily supported by the hardware. Consult the appropriate Instruction manual for details of the ports available
on specific hardware.
3
Only one explicit connection is created per node. All explicit Map Descriptors attached to that node will use the same explicit connection.
FieldServer Technologies 1991 Tarob Court Milpitas, California 95035 USA Web: www.fieldserver.com
Tel: (408) 262 2299 Fax: (408) 262 2269 Toll Free: (888) 509 1970 email: support@fieldserver.com
Function
Adapter Name
Specify protocol used
,Protocol
,EtherNet/IP
3
,Adapter ,Protocol
,N1 ,EtherNet/IP
Legal Values
2
N1, N2
EtherNet/IP
Legal Values
Up to 32 alphanumeric characters
Any valid address on subnet
EtherNet/IP
2
N1, N2
Page 7 of 30
