FS-8704-14 EtherNet/IP Manual

4.4.6 Map Descriptor Example 1: Unconnected Messages

// Client Side Map Descriptors
Map_Descriptors
Map_Descriptor_Name ,Scan_Interval ,Data_Array_Name
CMD_PRO_03 ,0s ,DA_AI_01
CMD_PRO_02 ,0s ,DA_AI_01

4.4.7 Map Descriptor Example 2: Data Table Messages

// Client Side Map Descriptors
Map_Descriptors
Map_Descriptor_Name ,Scan_Interval ,Data_Array_Name
Cmd_Pro_09 ,0s ,DA_AI_05
Cmd_Pro_10 ,0s ,DA_AI_06

4.4.8 Map Descriptor Example 3: PCCC Messages

// Client Side Map Descriptors
Map_Descriptors
Map_Descriptor_Name ,Data_Array_Name
CMD_01 ,DA_F_01
FieldServer Technologies 1991 Tarob Court Milpitas, California 95035 USA Web: www.fieldserver.com
Tel: (408) 262 2299 Fax: (408) 262 2269 Toll Free: (888) 509 1970 email: support@fieldserver.com
,Data_Array_Offset ,Function
,0 ,Rdbc
,1 ,Rdbc
,Data_Array_Offset ,EIP_Con_Typ
,0 ,Explicit
,0 ,Explicit
,Data_Array_Offset, ,Function ,EIP_Con_Typ
,0, ,Rdbc ,Explicit
Page 11 of 30
,EIP_Con_Typ ,Node_Name ,EIP_Class ,Address
,Unconnected ,EIP_01 ,10 ,1
,Unconnected ,EIP_01 ,10 , ,2
,Node_Name ,Function ,EIP_Service
,EIP_01 ,Rdbc ,Data_Table_Read
,EIP_01 ,Rdbc ,Data_Table_Read
,Node_Name ,EIP_Service ,EIP_Path
,EIP_01 ,Exec_PCCC ,1 0
,EIP_Attribute ,EIP_Service ,Length
,3 ,Get_Attrib ,1
,3 ,Get_Attrib ,1
,EIP_Path ,EIP_Tag_Name ,Length
,1 1 ,analog_in_3 ,2
,1 1 ,analog_in_4 ,2
,File_Type File_Number ,Address ,Length
,F 8, ,30 ,10
