- Page 1 S252U2ERR Instruction Manual SATA Hard Drive Enclosure 2.5” Black eSATA and USB to Dual Removable SATA Hard Drive Enclosure with RAID...
- Page 2 StarTech.com. Where they occur these references are for illustrative purposes only and do not represent an endorsement of a product or service by StarTech.com, or an endorsement of the product(s) to which this manual applies by the third-party company in question.
-
Page 3: Table Of Contents
Table of Contents Introduction ..............1 Packaging Contents..............1 System Requirements ..............1 Front View ..................2 Rear View ..................2 Installation ............... 3 Hardware Installation ..............3 Driver Installation .................4 How to Configure ............4 Operating Modes .................4 Using the Storage Device ..........5 Specifications .............. -
Page 4: Introduction
Introduction The StarTech.com S252U2ERR Dual Removable 2.5” SATA External Hard Drive Enclosure provides a complete, hardware-based external RAID storage solution for laptop or desktop computers. Accommodating two 2.5” SATA 1.5/3.0Gbps hard drives, this compact HDD enclosure supports RAID configurations including JBOD (Single), Spanning (BIG/Concatenated), RAID 0 (Fast) and RAID 1 (Safe). -
Page 5: Front View
Front View Power/Activity Door Latch Door Twist Lock Rear View Power eSATA connector connector Reset switch ON/OFF RAID Mode switch connector switch... -
Page 6: Installation
Installation WARNING: Hard drives require careful handling, especially when being transported. If you are not careful with your hard disk, lost data may result. Always handle your hard drive and storage device with caution. Hardware Installation Make sure the power switch on the enclosure is set to OFF and the power adapter is unplugged from the enclosure. -
Page 7: Driver Installation
Driver Installation No driver installation is required for these operating systems, as this enclosure is natively supported, so the drivers are already installed. How to Configure Operating Modes Mode Description RAID 0 Striping combines multiple disk into a single large (Striping) disk array. -
Page 8: Using The Storage Device
Using the Storage Device Windows 2000/XP/Vista/7 If you are using a brand new hard drive that does not contain any data, then you will first need to prepare the hard drive for use. From the main desktop, right-click on “My Computer” (“Computer” in Vista/7), then select Manage. - Page 9 The New Partition Wizard will appear. Follow the instructions in the wizard to complete setting up the drive. Once complete, the Disk should show up as “Healthy” with a drive letter assigned (i.e. E:). This drive letter should now appear within My Computer. If you are installing a hard drive that already has data on it, then after plugging it in, the drive should automatically show up with a drive letter assigned within My Computer.
-
Page 10: Specifications
Specifications USB 2.0 Bus Interface SATA 3.0Gb/s Chipset ID Silicon Image SiI5744 1 x eSATA* Connectors 1 x USB mini-B 1 x DC Power LEDs 2 x Power/Activity 2.5” SATA 1.5/3.0Gbps, height up Compatible Hard Drives to 9.5mm, up to 500GB capacity eSATA: 3.0Gbps Maximum Data Transfer Rate USB2.0: 480Mbps... -
Page 11: Technical Support
Limitation of Liability In no event shall the liability of StarTech.com Ltd. and StarTech.com USA LLP (or their officers, directors, employees or agents) for any damages (whether direct or indirect, special, punitive, incidental, consequential, or... - Page 12 StarTech.com has been making “hard-to-find easy” since 1985, providing high quality solutions to a diverse IT and A/V customer base that spans many channels, including government, education and industrial facilities to name just a few. We offer an unmatched selection of computer parts, cables, A/V products, KVM and Server...
