- Page 1 DE: Bedienungsanleitung - de.startech.com FR: Guide de l'utilisateur - fr.startech.com ES: Guía del usuario - es.startech.com IT: Guida per l'uso - it.startech.com NL: Gebruiksaanwijzing - nl.startech.com PT: Guia do usuário - pt.startech.com For the most up-to-date information, please visit: www.startech.com Manual Revision: 08/28/2012...
-
Page 2: Fcc Compliance Statement
StarTech.com. Where they occur these references are for illustrative purposes only and do not represent an endorsement of a product or service by StarTech.com, or an endorsement of the product(s) to which this manual applies by the third-party company in question. Regardless of any direct acknowledgement elsewhere in the body of this document, StarTech.com hereby... -
Page 3: Table Of Contents
Table of Contents Introduction ....................1 Packaging Contents ..........................1 System Requirements ..........................1 Installation ....................3 3.5in Hard Drive Setup ..........................3 2.5in Hard Drive Setup ..........................5 Specifications ..................6 Technical Support ..................7 Warranty Information ................7 Instruction Manual... -
Page 4: Introduction
Introduction The SAT2IDEADP SATA to IDE hard drive adapter enables you to use your 2.5-inch/3.5- inch IDE-based (PATA) hard drives in most StarTech.com SATA-based HDD docking stations and drive duplicators. The SATA-IDE adapter features all-metal construction that ensures maximum durability, and is fully compatible with IDE hard drives up to ATA-133 (133MBps). - Page 5 Instruction Manual...
-
Page 6: Installation
1. If connecting a 3.5in (40-pin) IDE hard drive, connect the 40-pin IDE ribbon cable to the 40-pin connector on the inside of the SAT2IDEADP. 2. Connect the large 4-pin LP4 power cable to the small 4-pin SP4 floppy power connector on the inside of the SAT2IDEADP. - Page 7 3. Connect the ribbon cable and power cable to the connectors on the IDE hard drive. 4. Place the IDE drive onto the back plate of the SAT2IDEADP adapter and fold/tuck the cables into the opening of the adapter. Slide the IDE drive towards the connectors until the mounting holes on the bottom of the drive line up with the mounting points on the back plate of the adapter.
-
Page 8: In Hard Drive Setup
3. Connect the IDE hard drive to the 44-pin connector on the ribbon cable. 4. Place the IDE drive onto the back plate of the SAT2IDEADP adapter and fold/tuck the cables into the opening of the adapter. Slide the IDE drive towards the connectors until the mounting holes on the bottom of the drive line up with the mounting points on the back plate of the adapter. -
Page 9: Specifications
Specifications Host Interface SATA revision 1.0 1 x 40-pin IDE male Connectors 1 x SP4 Power male 2.5in and 3.5in PATA (IDE) 66/100/133 Compatible Hard Drives hard drive LBA Support 48-bit Enclosure Material Metal Operating Temperature 5°C ~ 80°C (41°F ~ 176°F) -40°C ~ 70°C Storage Temperature (-40°F ~ 158°F) -
Page 10: Technical Support
Limitation of Liability In no event shall the liability of StarTech.com Ltd. and StarTech.com USA LLP (or their officers, directors, employees or agents) for any damages (whether direct or indirect, special, punitive, incidental, consequential, or otherwise), loss of profits, loss of business, or any pecuniary loss, arising out of or related to the use of the product exceed the actual price paid for the product. - Page 11 StarTech.com is an ISO 9001 Registered manufacturer of connectivity and technology parts. StarTech.com was founded in 1985 and has operations in the United States, Canada, the United Kingdom and Taiwan servicing a worldwide market.
