- Page 1 GIGABIT E E THERNET ADAPTER 10/100/1000 Mbits/sec PCI Gigabit Ethernet Adapter ST1000BT32 ST1000BT64 Instruction Guide * ST1000BT32 shown * Actual product may vary from photo The Professionals’ Source For Hard-to-Find Computer Parts...
- Page 2 FCC COMPLIANCE STATEMENT This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications.
-
Page 3: Table Of Contents
Table of Contents Introduction ............2 Installation . -
Page 4: Introduction
The ST1000BT64 is compliant with both 64-bit and 32-bit PCI specifications. The ST1000BT32 is compliant with 32-bit PCI specifications. Features • Supports 64/32-bit (ST1000BT64) or 32-bit (ST1000BT32) 66/33 MHz PCI Local Bus Master Version 2.2/2.1 • Complies with IEEE 802.3, IEEE 802.3u, and IEEE 802.3ab specifications •... -
Page 5: Installation
Installation This section will guide you through the installation of your card and the related software. Please read through the instructions carefully and complete each step in the order listed. Installing the Card 1. Make sure that your computer power cord is unplugged and you are grounded. 2. - Page 6 Windows 95B 1. Windows will automatically detect the new hardware. Select “Driver from disk provided by hardware manufacturer” and click OK. 2. Insert the driver disk into the disk drive. Browse to the Win95B folder on the driver disk and click OK. You may be required to provide your Windows 95 installation disk.
- Page 7 Ethernet cable. If you are unsure of the type of cable required for your device, consult your device manufacturer. NOTE: StarTech.com carries a wide range of Cat. 5e and Cat. 6 Ethernet cables in various colors and lengths. For more information on these products, as well as tips and ideas for setting up and running your network, visit http://www.startech.com and click on the...
- Page 8 Windows Me/98/95 1. Click on Start, then Settings, then Control Panel. 2. Double-click on Network. NOTE: If you need to add any of the following components, check your Windows documentation for details. Make sure all your computers are on the same workgroup To be able to communicate properly with each other, each computer must be located on the same workgroup.
- Page 9 Technical Specifications Connector RJ-45 Standard IEEE 802.3 10BaseT IEEE 802.3u 100BaseTx IEEE 802.3ab 1000BaseT Transmission Rate 10/20 (half/full duplex) (Mbits/sec) 100/200 (half/full duplex) 1000/2000 (half/full duplex) IRQ Line Assigned by system I/O Address Assigned by system Drivers Windows 95 OSR2/98/NT/Me/2000/XP, Netware Server 5.x, Linux LEDs 10 Mbits/sec Link/Activity...
-
Page 10: Technical Support
Limitation of Liability In no event shall the liability to StarTech.com Ltd. (or its officers, directors, employees or agents) for any damages (whether direct or indirect, special, punitive incidental, consequential, or otherwise), loss of profits, loss of business, or any pecuniary loss, arising out of related to the use of the product exceed the actual price paid for the product. - Page 11 Revised: May 26, 2003...
