Introduction This Rack Mountable USB KVM Switch supports high resolution video applications (up to 1920x1440 pixels supported) and audio switching between connected computers, and provides an integrated USB 2.0 hub that lets the selected computer have access shared high speed USB peripherals. Providing control of up to four computers from a single USB keyboard and mouse peripheral set, the switch features a sturdy all metal chassis and can be rackmounted in a server rack/cabinet using an optional Rackmount Bracket kit (SV431RACK) -... -
Page 5: Installation
2. In PNP AND PCI SETUP, set PNP OS INSTALLED to YES and set the USB IRQ to ENABLED. Please Note: SV431USBAE is capable of switching between computers while maintaining USB mouse and keyboard control. If you plan to share other peripherals such as a CCD camera, printer or scanner, you must shut down the corresponding driver on the computer from which KVM control is being switched. -
Page 6: Connecting Slave Computers
Connecting Slave Computers 1. Connect the VGA port located on the rear panel of SV431USBAE to the VGA port provided by the video connection on the desired computer, using an HDB15 male to female cable. Please note the PC Port number, for steps 2 and 3. -
Page 7: Operation
Operation Front Panel 1. Online and Selected LEDs: When the LED turns green, the connected computer is powered on. When a computer is selected, the corresponding (red) LED will illuminate. 2. Pushbuttons: Each computer has a button associated with it on the front panel for selection Auto Scan Auto Scan automatically scans through the connected computers individually, in a... -
Page 8: Optional: Rack Mount Installation
Optional: Rack Mount Installation The following illustration depicts how to attach optional mount brackets and cable support for rack mounting SV431USBAE. To do so, you may wish to use SV431RACK (please see Accessory Products from StarTech.com for further information). To the Rack Cabinet... -
Page 9: Specifications
Specifications Computers Supported Front Panel Push Buttons Hot Plug-and-Play Supported Automatic Scan Interval 3, 8, 15, 30 seconds Cable Length (Max) 30M (100ft) for VGA 5M (15ft) for USB Computer ON-LINE LED Computer Selected LED Resolution Supported 1920 x 1440, DDC2B USB Type B x 4 Computer Peripheral Connector HDB-15 Male x 4... -
Page 10: Technical Support
