PARTS LIST

EACH PRECAUTION IN THIS MANUAL SHOULD BE FOLLOWED DURING SERVICING. COMPONENTS IDENTIFIED WITH THE IEC
SYMBOL IN THE PARTS LIST AND THE SCHEMATIC DIAGRAM DESIGNATED COMPONENTS IN WHICH SAFETY CAN BE OF
! ! !
SPECIAL SIGNIFICANCE. WHEN REPLACING A COMPONENT IDENTIFIED BY
OR PARTS WITH THE SAME RATINGS OF RESISTANCE, WATTAGE OR VOLTAGE THAT ARE DESIGNATED IN THE PARTS LIST
IN THIS MANUAL. LEAKAGE-CURRENT OR RESISTANCE MEASUREMENTS MUST BE MADE TO DETERMINE THAT EXPOSED
PARTS ARE ACCEPTABLY INSULATED FROM THE SUPPLY CIRCUIT BEFORE RETURNING THE PRODUCT TO THE CUSTOMER.
:
CAUTION Regular type resistors and capacitors are not listed. To know those values, refer to the schematic diagram.
Regular type resistors are less than 1/4 W carbon type and 0 ohm chip resistors.
Regular type capacitors are less than 50 V and less than 1000 µF type of Ceramic type and Electrical type.
N.S.P : Not available as service parts.
PACKING & ACCESSORIES
REF.NO. PART NO.
614 310 7293 CARTON CASE,INNER SLEEVE
614 309 5217 CUSHION,FRONT
614 309 5224 CUSHION,BACK
614 310 7118 INSTRUCTION MANUAL
614 313 3513 INSTRUCTION MANUAL(GREEK)
645 041 1533 POLY SHEET-0750X0500*NC,SET
645 040 9943 BATTERY COVER,SERVICE PARTS
645 005 1227 ASSY,ANTENNA,LOOP
614 229 4635 ANTENNA,FM
or 614 308 5515 ANTENNA,FM
645 040 1923 REMOCON,RB-M3RD
645 040 1787 ASSY,CABLE,SYSTEM 19P
614 311 5090 ASSY,BOX,SPEAKER
614 311 5106 ASSY,GRILLE
CABINET & CHASSIS
REF.NO. PART NO.
1 614 309 4586 ASSY,CABINET,FRONT
2 614 310 5336 KNOB,VOLUME,MULTI JOG
3 614 309 5095 KNOB,ROTARY,VOLUME
5 614 309 4715 BUTTON,POWER
6 614 302 0530 DEC,WINDOW LED,POWER
7 614 309 4739 BUTTON,PLAY
8 614 309 4722 BUTTON,OPEN/CLOSE
9 614 309 4678 BUTTON,LEFT,BAND/TUNE MODE
10 614 309 4692 BUTTON,RIGHT,INPUT/SUPER BASS
11 614 309 4975 DEC,WINDOW,LED,LIGHTING
12 614 309 5088 HOLDER,LED,LIGHTING
13 614 309 4531 ASSY,CABINET,AFTER BENDING
15 614 309 5071 HOLDER,PWB,SUB TRANS PWB
16 614 309 4982 DEC,ESCUTCHEON,CD TRAY
17 614 309 5064 HOLDER,TRANS/HEAT SINK/S-T-PWB
18 614 312 0223 MOUNTING,POWER IC
19 614 310 8887 SPACER,RUBBER,POWER IC
20 614 310 7668 HEAT SINK,POWER IC, REGURATOR
21 614 309 4616 ASSY,CABINET,BOTTOM
23 614 309 5149 PANEL,REAR
24 614 310 7194 ASSY,COVER
614 129 1901 FIXER,AC CORD
614 284 1884 FIXER,AC CORD
614 129 9136 LUG,FOR CD-TU WIRE
FIXING PARTS
REF.NO. PART NO.
Y01 411 021 3503 SCR S-TPG BIN 3X10,
Y02 411 021 1202 SCR S-TPG BIN 2X8,DEC WINDOW LED
Y03 411 021 3503 SCR S-TPG BIN 3X10,FRONT PWB FIX
Y04 411 021 3701 SCR S-TPG BIN 3X10,CABINET

PRODUCT SAFETY NOTICE

DESCRIPTION
DESCRIPTION
DESCRIPTION
FRONT-BOTTOM FIX
, USE ONLY THE REPLACEMENT PARTS DESIGNATED,
! ! !
REF.NO. PART NO.
Y05 411 021 3503 SCR S-TPG BIN 3X10,
Y06 411 021 3503 SCR S-TPG BIN 3X10,HOLDER PWB
Y07 411 098 4403 SCR S-TPG BIN 3X25,
Y08 411 122 3709 SCR S-TPG BIN 3X35,
Y09 411 021 3503 SCR S-TPG BIN 3X10,
Y10 411 021 3503 SCR S-TPG BIN 3X10,MAIN PWB
Y11 411 021 5705 SCR S-TPG BIN 3X6,
Y13 411 001 4209 SCR S-TPG BIN 4X8,TRANS
Y14 411 021 3503 SCR S-TPG BIN 3X10,POWER-IC
Y15 411 021 3503 SCR S-TPG BIN 3X10,+MB, +12V REG
Y16 411 021 3503 SCR S-TPG BIN 3X10,HEAT SINK
Y17 411 021 3503 SCR S-TPG BIN 3X10,TUNER PWB
Y18 411 021 3701 SCR S-TPG BIN 3X10,BOTTOM-REAR
Y19 411 021 3701 SCR S-TPG BIN 3X10,
Y20 411 021 3701 SCR S-TPG BIN 3X10,COVER FIX
ELECTRICAL PARTS
REF.NO. PART NO.
51 423 016 9803 FUSE 250V 0.63A FU499
! ! !
52 645 040 0902 TRANS,POWER
! ! !
53 645 016 9939 CORD,POWER-1.74MK
! ! !
or 614 255 2513 POWER CORD
! ! !
54 645 037 3060 CORE,CLAMP,LINE-NOISE
55 645 013 6498 CORE,FERRITE,AC-EMC
56 614 310 8900 PWB,DRESSING,DRESSING(N.S.P)
! ! !
57 614 312 7031 PWB,INSULATOR,INSULATOR(N.S.P)
! ! !
CN135 614 309 4159 ASSY,WIRE,CD-TUNER(OPT OUT)
CN191 645 041 1786 FLEXIBLE FLAT CABLE,PICK UP
CN691 645 040 1770 FLEXIBLE FLAT CABLE,FRONT-PRE
LED P.W.BOARD ASSY
REF.NO. PART NO.
71 614 309 4272 ASSY,PWB,
CN651 614 035 4911 SOCKET,DIP 2P,LED
or 645 012 7786 SOCKET,DIP 2P,LED
D6501 407 212 8907 LED HLMP-BB01-J0B00
- 8 -
DESCRIPTION
SUB TRANS PWB
CD MECHA FIX FRONT
CD MECHA FIX BACK
CD MECHA-CD PWB
HOLDER TRANS-BOTTOM
REAR-ELECT PARTS
DESCRIPTION
DESCRIPTION
ILLUMINATION (Only Initial)
