PARTS LIST
FRONT P.W.BOARD ASSY
REF.NO.
PART NO.
72
614 309 0625 ASSY,PWB,FRONT (Only Initial)
BR601
614 305 2241 HOLDER,FL,FL_MOUNT
C6093
403 304 4802 DL-ELECT 0.047F Z 5.5V
or
403 262 8607 DL-ELECT 0.047F Z 5.5V
CN479
645 012 0008 JACK,PHONE D3.6,HEADPHONE
CN488
614 273 3905 CORD,1P CONNECTOR,
CN489
614 020 1246 SOCKET,5P
CN499
614 309 6184 ASSY,WIRE,HEADPHONE
CN601
645 012 5553 SOCKET,FPC 22P,FRONT-AMP
CN602
614 035 4959 SOCKET,DIP 6P,FRONT-TU
or
645 012 7823 SOCKET,DIP 6P,FRONT-TU
CN603
614 035 5017 SOCKET,DIP 12P,FRONT-CD
or
645 012 7885 SOCKET,DIP 12P,FRONT-CD
CN604
614 035 4911 SOCKET,DIP 2P,LED
or
645 012 7786 SOCKET,DIP 2P,LED
CN612
614 297 8856 CORD,6P CONNECTOR,FRONT-TU
or
614 309 4135 ASSY,WIRE,FRONT-TU
CN613
614 309 4111 ASSY,WIRE,FRONT-CD
D6001
407 012 4406 DIODE 1SS133
D6002
407 099 4603 ZENER DIODE MTZJ3.9B
D6004
408 032 5404 LED SLP-9118C-51H-S-T1
D6011
407 012 4406 DIODE 1SS133
D6091
407 012 4406 DIODE 1SS133
DS601
407 217 1101 PHOTO DIODE SPS-442-1G,IR
FL601
645 040 1794 FLOURESCENT TUBE,FL
IC601
410 384 0808 IC M38B57MCH-B252FP,
L4790
645 001 4550 INDUCTOR,10U K
L4791
645 001 4550 INDUCTOR,10U K
L4891
645 001 4550 INDUCTOR,10U K
L6091
645 001 4550 INDUCTOR,10U K
or
645 031 7835 INDUCTOR,10U K
Q6001
405 143 8706 TR KTC3199-GR
or
405 017 9600 TR 2SC3330-T
or
405 017 9709 TR 2SC3330-U
or
405 019 3705 TR 2SC536-G-AUD-SPA
or
405 011 8500 TR 2SC1740S-R
or
405 011 8609 TR 2SC1740S-S
or
405 020 7402 TR 2SC945A-P
or
405 020 7204 TR 2SC945A-K
Q6002
405 143 6504 TR KTA1267-GR
or
405 004 4601 TR 2SA608-F-SPA
or
405 004 5103 TR 2SA608-G-SPA
or
405 006 1806 TR 2SA933S-R
or
405 006 1905 TR 2SA933S-S
Q6003
405 141 3505 TR KTA1266-Y
or
405 141 3406 TR KTA1266-GR
or
405 004 4502 TR 2SA608-F-NP
or
405 004 5004 TR 2SA608-G-NP
or
405 006 3909 TR 2SA952-K
or
405 006 4005 TR 2SA952-L
Q6004
405 143 8706 TR KTC3199-GR
or
405 017 9600 TR 2SC3330-T
or
405 017 9709 TR 2SC3330-U
or
405 019 3705 TR 2SC536-G-AUD-SPA
or
405 011 8500 TR 2SC1740S-R
or
405 011 8609 TR 2SC1740S-S
or
405 020 7402 TR 2SC945A-P
or
405 020 7204 TR 2SC945A-K
Q6005
405 143 8706 TR KTC3199-GR
or
405 017 9600 TR 2SC3330-T
or
405 017 9709 TR 2SC3330-U
or
405 019 3705 TR 2SC536-G-AUD-SPA
or
405 011 8500 TR 2SC1740S-R
DESCRIPTION
FRONT-CHASSIS
MICRO-CONTROLER
REF.NO.
PART NO.
or
405 011 8609 TR 2SC1740S-S
or
405 020 7402 TR 2SC945A-P
or
405 020 7204 TR 2SC945A-K
Q6006
405 143 8706 TR KTC3199-GR
or
405 017 9600 TR 2SC3330-T
or
405 017 9709 TR 2SC3330-U
or
405 019 3705 TR 2SC536-G-AUD-SPA
or
405 011 8500 TR 2SC1740S-R
or
405 011 8609 TR 2SC1740S-S
or
405 020 7402 TR 2SC945A-P
or
405 020 7204 TR 2SC945A-K
Q6007
405 141 3505 TR KTA1266-Y
or
405 141 3406 TR KTA1266-GR
or
405 004 4502 TR 2SA608-F-NP
or
405 004 5004 TR 2SA608-G-NP
or
405 006 3909 TR 2SA952-K
or
405 006 4005 TR 2SA952-L
Q6008
405 000 6104 TR DTC144ES
or
405 146 1209 TR KRC104M
Q6009
405 000 6104 TR DTC144ES
or
405 146 1209 TR KRC104M
Q6010
405 000 2205 TR DTA144ES
or
405 146 1308 TR KRA104M
Q6011
405 000 6104 TR DTC144ES
or
405 146 1209 TR KRC104M
R4790
401 009 5605 CARBON 330 JA 1/2W
R4890
401 009 5605 CARBON 330 JA 1/2W
S6001
645 026 4771 SWITCH,ROTARY(ENCODER),
S6002
645 040 1763 SWITCH,ROTARY(ENCODER),
S6091
614 215 9828 SWITCH,TACT,RESETSW
S6101
614 240 1002 SWITCH,TACT
or
645 006 5958 SWITCH,PUSH 1P-1T
or
614 220 5471 SWITCH,TACT
S6102
614 240 1002 SWITCH,TACT
or
645 006 5958 SWITCH,PUSH 1P-1T
or
614 220 5471 SWITCH,TACT
S6103
614 240 1002 SWITCH,TACT
or
645 006 5958 SWITCH,PUSH 1P-1T
or
614 220 5471 SWITCH,TACT
S6104
614 240 1002 SWITCH,TACT
or
645 006 5958 SWITCH,PUSH 1P-1T
or
614 220 5471 SWITCH,TACT
S6105
614 240 1002 SWITCH,TACT
or
645 006 5958 SWITCH,PUSH 1P-1T
or
614 220 5471 SWITCH,TACT
S6106
614 240 1002 SWITCH,TACT
or
645 006 5958 SWITCH,PUSH 1P-1T
or
614 220 5471 SWITCH,TACT
S6107
614 240 1002 SWITCH,TACT
or
645 006 5958 SWITCH,PUSH 1P-1T
or
614 220 5471 SWITCH,TACT
S6108
614 240 1002 SWITCH,TACT
or
645 006 5958 SWITCH,PUSH 1P-1T
or
614 220 5471 SWITCH,TACT
S6109
614 240 1002 SWITCH,TACT
or
645 006 5958 SWITCH,PUSH 1P-1T
or
614 220 5471 SWITCH,TACT
S6110
614 240 1002 SWITCH,TACT
or
645 006 5958 SWITCH,PUSH 1P-1T
or
614 220 5471 SWITCH,TACT
S6111
614 240 1002 SWITCH,TACT
or
645 006 5958 SWITCH,PUSH 1P-1T
or
614 220 5471 SWITCH,TACT
S6114
614 240 1002 SWITCH,TACT
- 9 -
DESCRIPTION
VOLUME
MULTIJOG
