PARTS LIST
REGULATOR 2 P.W.BOARD ASSY
REF.NO.
PART NO.
78
614 311 4901 ASSY,PWB,VOL REG2
CN417
614 035 4928 SOCKET,DIP 3P
or
614 237 9769 SOCKET
CN427
614 309 9482 ASSY,WIRE
Q4170
405 138 6403 TR KTD2058Y
! ! !
AUDIO TERMINAL P.W.BOARD ASSY
REF.NO.
PART NO.
79
614 309 3121 ASSY,PWB,VIDEO IN(Only Initial)
CN452
645 040 5105 JACK,RCA-2,VIDEODVDIN
CN453
645 033 3057 JACK,RCA,WOOFEROUT
CN462
614 310 0157 ASSY,WIRE
LG462
614 129 9082 LUG
TUNER P.W.BOARD ASSY
REF.NO.
PART NO.
80
614 309 3114 ASSY,PWB,TUNER (Only Initial)
C2457
403 259 0508 NP-ELECT 1U M 50V
CN168
645 005 8226 PLUG,3P
or
645 009 6433 PLUG,3P
CN169
614 240 5703 OPTO CONNECTOR
CN201
614 255 5750 TERMINAL
or
645 032 6394 TERMINAL
CN241
645 006 0922 PLUG,5P
or
645 009 6457 PLUG,5P
CN242
645 006 0939 PLUG,6P
or
645 009 6464 PLUG,6P
D2151
407 012 4406 DIODE 1SS133
D2301
407 063 9108 ZENER DIODE MTZJ6.8B
D2451
407 012 4406 DIODE 1SS133
D2452
407 153 7502 ZENER DIODE GZS3.0B
D2453
407 012 4406 DIODE 1SS133
D2454
407 012 4406 DIODE 1SS133
D2466
407 012 4406 DIODE 1SS133
D2467
407 012 4406 DIODE 1SS133
IC231
409 474 3201 IC LA1844ML
IC241
409 439 4502 IC LC72121M-D
IC251
409 447 3900 IC LC72722
L2151
645 023 0127 TUNER
L2451
645 001 4581 INDUCTOR,100U K
or
645 031 7842 INDUCTOR,100U K
L2501
645 001 4581 INDUCTOR,100U K
or
645 031 7842 INDUCTOR,100U K
L2502
645 001 4581 INDUCTOR,100U K
or
645 031 7842 INDUCTOR,100U K
LG201
645 023 8987 FIXER
Q2140
405 143 8706 TR KTC3199-GR
or
405 017 9600 TR 2SC3330-T
or
405 017 9709 TR 2SC3330-U
or
405 019 3705 TR 2SC536-G-AUD-SPA
or
405 011 8500 TR 2SC1740S-R
or
405 011 8609 TR 2SC1740S-S
or
405 020 7402 TR 2SC945A-P
or
405 020 7204 TR 2SC945A-K
Q2201
405 151 4202 TR KTC3193-O
or
405 151 4103 TR KTC3193-Y
or
405 016 0806 TR 2SC2839-E
DESCRIPTION
(Only Initial)
DESCRIPTION
DESCRIPTION
REF.NO.
PART NO.
Q2310
405 143 8706 TR KTC3199-GR
or
405 017 9600 TR 2SC3330-T
or
405 017 9709 TR 2SC3330-U
or
405 019 3705 TR 2SC536-G-AUD-SPA
or
405 011 8500 TR 2SC1740S-R
or
405 011 8609 TR 2SC1740S-S
or
405 020 7402 TR 2SC945A-P
or
405 020 7204 TR 2SC945A-K
Q2451
405 151 5209 TR KRA107M
or
405 000 0904 TR DTA114YS
or
405 078 2404 TR BN1A4P
or
405 036 3702 TR 2SA1564
Q2502
405 151 5209 TR KRA107M
or
405 000 0904 TR DTA114YS
or
405 078 2404 TR BN1A4P
or
405 036 3702 TR 2SA1564
Q2701
405 143 8706 TR KTC3199-GR
or
405 017 9600 TR 2SC3330-T
or
405 017 9709 TR 2SC3330-U
or
405 019 3705 TR 2SC536-G-AUD-SPA
or
405 011 8500 TR 2SC1740S-R
or
405 011 8609 TR 2SC1740S-S
or
405 020 7402 TR 2SC945A-P
or
405 020 7204 TR 2SC945A-K
Q2801
405 143 8706 TR KTC3199-GR
or
405 017 9600 TR 2SC3330-T
or
405 017 9709 TR 2SC3330-U
or
405 019 3705 TR 2SC536-G-AUD-SPA
or
405 011 8500 TR 2SC1740S-R
or
405 011 8609 TR 2SC1740S-S
or
405 020 7402 TR 2SC945A-P
or
405 020 7204 TR 2SC945A-K
R2301
401 017 0708 CARBON 270 JA 1/4W
! ! !
R2311
401 017 0708 CARBON 270 JA 1/4W
! ! !
SH202
614 310 3400 SHIELD
U2101
645 033 5327 TUNER,FM
X2451
645 023 4965 OSC,CRYSTAL 7.2MHZ
X2501
645 035 8326 OSC,CRYSTAL 4.332MHZ
XF221
614 240 2917 FILTER,CERAM
or
645 010 0079 CERAMIC FILTER 10.70MHZ
or
614 254 3214 FILTER
XF222
614 240 2917 FILTER,CERAM
or
645 010 0079 CERAMIC FILTER 10.70MHZ
or
614 254 3214 FILTER
XF231
614 246 0849 FILTER
XF233
645 039 9923 TRANS,IF 10.7MHZ
- 12 -
