Summary of Contents for Levana BABYVIEW20

  • Page 2 USA 14305 Warranty Terms 1. LEVANA products are guaranteed for a period of one year from the date of purchase against defects in workmanship and materials. This warranty is limited to the repair, replacement or refund of the purchase price at LEVANA’s option.
  • Page 3: Table Of Contents

    INTRODUCTION Interference Free Digital Wireless Video Baby Monitor w/ Night Light Lullaby Camera Congratulations! You’ve just taken a step to help ensure your child’s safety and enjoy more of your child’s special moments. Please take a few minutes to read this manual so you can use this monitor to its full potential.
  • Page 4: General Care And Maintenance

    CAUTION AND WARNINGS CAUTION RISK OF ELECTRIC SHOCK, DO NOT OPEN TO REDUCE THE RISK OF ELECTRIC SHOCK, DO NOT REMOVE THE COVER (BACK). NO USER SERVICEABLE PARTS INSIDE. REFER SERVICING TO QUALIFIED SERVICE PERSONNEL. Graphic Symbol Explanation The lightning flash with arrowhead symbol, within an equilateral triangle, is intended to alert the user to the presence of insinuated “dangerous voltage”...
  • Page 5: Whats Included

    • 24/7 Lifetime Customer Support AVOIDING SIGNAL DISRUPTION Your BABYVIEW20 uses digital transmission to ensure a clear and consistent picture. The signal also passes easily through interior walls. However, buildings with metal frames or placing the camera near large metal objects may cause signal degradation. If reception is poor, moving the camera or receiver may fix this problem.
  • Page 6: Knowing Your Baby Monitor

    KNOWING YOUR BABY MONITOR Monitor: 1. LCD screen 2. Antenna 3. Music selection buttons 4. VOX: Voice Operated Transmission button 5. Power indicator LED 6. Link indicator LED 7. Volume indicator LED 8. Speaker 9. VOX (Voice Operated Transmission) indicator LED 10.
  • Page 7: Camera Setup

    CAMERA SETUP CAMERA SETUP You have the option to use either the supplied AC adapter or 4 AAA-batteries (not included) to power your camera. BEFORE STARTING, make sure the power switch on the camera is in the OFF position. If using batteries: Note: Use new batteries.
  • Page 8: Mounting The Camera

    CAMERA SETUP If plugging into a wall outlet: 1. Plug one end of the provided power adapter into a wall outlet (both camera and monitor power adapters are interchangeable). 2. Connect the other end of the power adapter into the power input on the camera. This is located under the ON/OFF switch.
  • Page 9: Using The Night Light

    CAMERA SETUP Option 2: Using the Camera Mount (for mounting directly on your baby’s crib) 1. Remove the camera from the magnetic desk mount. The camera’s mounting hole is located on the bottom of the camera. 2. Place the camera on the top of the camera mount’s screw and line up the camera’s mounting hole to the screw.
  • Page 10: Night Vision

    CAMERA SETUP Using Night Vision The camera has nine night vision LEDs so it can see in the dark. This night vision uses the power of infrared light, which is 100% safe for babies. The camera has a light sensor and will activate the night vision only when it gets dark.
  • Page 11 MONITOR SETUP Note: The monitor will also charge if it is turned on. If the monitor is turned on while charging, the power LED will turn purple while charging and RED when the charge is complete. Note: The battery does not need to be inserted to operate the monitor from a wall outlet. However, keeping the battery in the unit will ensure that it is charged when you need to unplug it from the wall.
  • Page 12: Adjusting The Monitor Brightness

    Sound Activation (VOX) The BABYVIEW20 system lets you turn off the monitor while you are sleeping, and will automatically turn back on if your child starts to cry or make noise. 1. Press the “VOX” button on the left side of the monitor. This will turn off the screen but the “VOX” LED on the front of the monitor will glow blue.
  • Page 13: Lullaby Sounds

    MONITOR SETUP Lullaby Sounds The camera plays a selection of lullabies that you can control with the monitor. With a push of a button you can start playing music, change the song, and stop the music remotely when your baby is asleep. There are 3 different chiming melodies that can sooth your baby to sleep.
  • Page 14: Range

    RANGE SYNCING CAMERA AND MONITOR The Monitor is capable of going approximately 450 feet (150 meters) away from the camera and still be within range to communicate, hear and view the camera. This will depend on environmental factors that may increase or decrease the maximum wireless range. The link LED will be green when the monitor and camera are paired and red when they are not paired.
  • Page 15: Troubleshooting

    TROUBLESHOOTING Troubleshooting If you are not getting any signal at all: • Make sure the camera and the monitor are turned on • Make sure the power plugs are pushed all the way in • If the camera/monitor is powered by batteries, replace all batteries with new ones If the signal is poor, or there is interference: • If there is a microwave oven in use in the path between the camera and monitor, turn off the microwave • Make sure the camera and the monitor are within range of each other (optimal range of approximately 100 ft;...
  • Page 16: Lithium Battery Tips

    LITHIUM BATTERY TIPS Lithium Battery Tips The rechargeable battery of the handheld monitor is a built-in lithium-polymer battery. Before using the monitor with battery power, please read the following in order to use the battery properly. 1. Under normal temperatures the battery can be recharged at least 300 times. 2.
  • Page 17: National Center For Missing And Exploited Children

    HELP SUPPORT THE NATIONAL CENTER FOR MISSING & EXPLOITED CHILDREN Levana is a proud supporter of the National Center for Missing & Exploited Children. This non-profit organiza- tion was established in 1984 to help prevent child abduction and sexual exploitation; help find missing children;...
