Installing The Pci Card; Installing The Drivers; Instruction - StarTech.com PCISAT2IDE1 Instruction Manual

I I n n s s t t a a l l l l a a t t i i o o n n

Installing the PCI Card

1. Make sure that your system is unplugged and you are grounded.
2. Remove the cover of your system (see your computer's user manual for details, if
necessary) and gently turn your computer onto its side, so that the PCI expansion slot
openings on the motherboard are facing upwards.
3. Locate an empty PCI slot (usually white in color) and remove the metal plate that
covers the corresponding rear bracket. You may need a Phillips screwdriver to perform
this step. Retain the screw! You will need it to secure the card later.
4. Gently insert the card into the empty slot, making sure it is firmly seated.
5. Secure the card in place using the screw you removed in Step 3.
6. Replace and secure the computer cover.

Installing the Drivers

Windows 2000 / XP / 2003 Server:
Following card installation, Windows will detect the presence of the card and initiate the
software installation process.
1. After rebooting, the Add New Hardware Wizard will launch. Select Install from a list
or specific location (Advanced) and click Next to continue setup:
Instruction Manual
2
