Summary of Contents for Perfect Flame 730-0335
- Page 1 STAINLESS STEEL NATURAL GAS GRILL MODEL NO.: 730-0335 ITEM NO: 25415 ® FOR OUTDOOR USE ONLY PLEASE CONTACT 1-800-554-5799 FOR ASSISTANCE DO NOT RETURN TO PLACE OF PURCHASE...
-
Page 2: Table Of Contents
TABLE OF CONTENTS SECTION ONE SECTION FOUR Safety Instructions…………………………… Operating Instructions…………………… Placement of the Grill ……………………… Lighting Instructions……………………… Lighting Illustrations ………………… SECTION TWO To Match Light the Grill …………………… Assembly Instructions……………………….. Using the Side Burner…………………… Caster Assembly……………………………… Care & Maintenance of Grill……………. Side Panel Assembly &... -
Page 3: Safety Instructions
SAFETY INSTRUCTIONS RECOGNIZED SAFETY SYMBOLS, WORDS AND LABELS WARNING WARNING Do not try lighting this appliance without first reading the “LIGHTING INSTRUCTIONS” section of this manual. WARNING – Hazards or unsafe practices which COULD result in severe personal injury or death. WARNING Spiders and insects can nest inside the burners of CAUTION... - Page 4 SAFETY INSTRUCTIONS CAUTION WARNING When using a match to light the grill make Do not use the grill if the odor of gas is sure to use the attached lighting rod. present. Contact customer service at 1- 800-554-5799. CAUTION Before cleaning, make sure the gas supply WARNING and control knobs are in the “OFF”...
- Page 5 SAFETY INSTRUCTIONS USING THE SIDE BURNER WARNING Inspect the gas supply hose prior to turning on Do not attempt to light the grill if gas odor is the gas. If there is evidence of cuts, wear or present. Contact customer service at 1-800-554- abrasion, it must be replaced prior to use.
- Page 6 SAFETY INSTRUCTIONS The grill is not intended to be installed in or on WARNING recreational vehicles and/or boats. Do not try lighting this appliance without first reading the “LIGHTING INSTRUCTIONS” section Children should not be left alone or unattended in of this manual.
-
Page 7: Placement Of The Grill
Do not use briquettes of any kind in the grill. Clean the grill with caution. To avoid steam burns, The 730-0335 natural gas grill is designed for do not use a wet sponge or cloth to clean the grill optimum performance without the use of briquettes. -
Page 8: Assembly Instructions
ASSEMBLY INSTRUCTIONS Please read the instructions thoroughly and follow step by step. HARDWARE PACK DESCRIPTION SPECIFICATION QUANTITY FLAT SCREW 5/32” X 10 MM 12 pcs TRUSS HEAD SCREW 5/32” X 10 MM 27 pcs SPLIT LOCK 5/32” 19 pcs TRUSS HEAD SCREW 1/4”... -
Page 9: Caster Assembly
CASTER ASSEMBLY Take out bottom panel and four caster from the carton, Use 16 pcs of 1/4” X 12mm truss head screws and 16 pcs of 1/4” split locks (Pack C) to lock two casters which in the right of bottom panel and two casters with brake which in the left of bottom panel as shown figure below. -
Page 10: Assembly
SIDE PANEL ASSEMBLY Use 4 pcs of 5/32” X 10mm truss head screws and 4 pcs of 5/32” split locks (Pack B), to screw the left and light side panels to the bottom panel as shown figure below. When installing the right and left panel, the flat side must face outside. -
Page 11: Back Panel Assembly
BACK PANEL ASSEMBLY A: Assembly back panel to bottom panel with 3 pcs of 5/32” X 10mm truss head screws and 3 pcs 5/32” split locks(Pack B)as shown figure A. B:Use 2 pcs of 5/32” X 10mm truss head screws with 5/32” split locks (Pack B) and 4 pcs of 1/4”... -
Page 12: Drawer Heat Shield Assembly
DRAWER HEAT SHIELD ASSEMBLY Assembly the drawer heat shield with 3 pcs 5/32” X 10mm truss head screws and 3 pcs of 5/32” split locks (Pack B) to the cart clapboard as shown figure A and with 2 pcs 5/32” X 10mm truss head screws and 2 pcs of 5/32”... -
Page 13: Cart Frame Assembly
CART FRAME ASSEMBLY Assembly the cart frame with 4 pcs 1/4” X 10mm truss head screws and 4 pcs of 1/4’’split locks (Pack C) to the side panels and use 1 pc 5/32” X 10mm truss head screw and 1 pc of 5/32”... -
Page 14: Drawer Assembly
DRAWER ASSEMBLY Take one drawer into the cart as shown figure below. And take out another drawer as last step. -
Page 15: Door Handle Assembly & Door Assembly
DOOR HANDLE ASSEMBLY Assembly the door handle with 6 pcs of 5/32” X 10mm flat screws (Pack A) as shown figure below. Pack A DOOR ASSEMBLY Assembly the door: To insert the door in the hold of extended metal piece at the grill bottom: Press the hinge on the top of the door to insert it into the hole on upper extended metal piece : Use a pc of 5/32”... -
Page 16: Cart Grill Head Assembly
CART GRILL HEAD ASSEMBLY Insert the upper portion of grill onto the cart from top as shown figure A. Then use 4 pcs of 1/4” X 10mm truss head screws and 4 pcs 1/4” split locks (pack D) to the side panels as shown figure B. -
Page 17: Panel Assembly
SIDE SHELF FRONT PANEL Assembly the side shelf front panel with 4 pcs 5/32” X 10mm truss head (Pack B) to the side left shelf as shown figure below. Pack B SIDE BURNER CONTROL PANEL ASSEMBLY Use 4 pcs of 5/32” X 10mm truss head screws (Pack B) to screw the side burner control panel to the side burner bowl assembly. -
Page 18: Side Shelf Assembly
SIDE SHELF ASSEMBLY A: Assembly the side shelf with 4 pcs of 1/4” X 10mm truss head screws, 4 pcs of 1/4’’ flat washers and 4 pcs of 1/4’’ split locks (Pack D) to the left panel. B: Assembly the side burner with 4 pcs of 1/4” X 10mm truss head screws, 4 pcs of 1/4’’flat washers and 4 pcs of 1/4’’split locks (Pack D) to the right panel. -
Page 19: Installation Of Side Burner Hose & Ng Regulator
INSTALLATION OF SIDE BURNER HOSE AND NG REGULATOR Hang up the side burner hose into the side shelf hook up as shown A . Insert the NG regulator into the hole in the side panel as shown B. -
Page 20: Side Burner Flex Gas Line Assembly
SIDE BURNER FLEX GAS LINE ASSEMBLY Insert the side burner flex gas line with side burner orifice through the hole of the side burner base and then push the nut until it forward to lock the the side burner orifice. Caution: After you finished last step you need to connect the side burner igniter line... -
Page 21: Installation Of Natural Gas Regulator
INSTALLATION OF NATURAL GAS REGULATOR Take out gas tank retention bolt from pack G. Turn the retention bolt clockwise to tighten the gas cylinder. 1. Connect the PVC Natural Gas Hose to the house gas supply line using the quick-connect fitting as show in the figure A. -
Page 22: Gas Hook Up
12,000 BTU/Hr. Total 89,000 BTU/Hr. Total gas consumption (per hour) of the 730-0335 Natural Gas Grill with all burners set on “HI”: The installation of this appliance must conform with local codes or, in the absence of local codes, to the National Fuel Gas Code, ANSI Z223. -
Page 23: Warning
INSTALLER FINAL CHECK Specified clearance maintained of 24 inches The unit has been tested and is free of leaks. from combustible materials/constructions. The gas supply shut off valve has been All internal packaging has been removed. located. The hose and regulator are properly All burners are factory installed. -
Page 24: Operating Instructions
OPERATING INSTRUCTIONS GENERAL USE OF THE GRILL AND ROTISSERIE Each main burner is rated at 15,000 BTU/Hr. The After its first use, the stainless steel adjacent to the main grill burners encompass the entire cooking rotisserie burner will most likely turn dark blue. This area and are side ported to minimize blockage from is a normal property of the non-rusting type falling grease and debris. -
Page 25: Lighting Instructions
NOTE Adjust the counter balance weight to balance the It is normal for the skewer to flex when larger cuts heavier side of the meat and avoid lopsided rotation of meat are being cooked. of the rotisserie motor. If the meat scrapes on the cooking grids during any CAUTION part of the rotation, the cooking grids must be When using the rotisserie burner, remove the... -
Page 26: Lighting Illustrations
LIGHTING ILLUSTRATIONS MAIN, SIDE & ROTISSERIE BURNER LIGHTING 1. Open the top cover or lid. 2. Push and turn the main, side, or rotisserie burner control knobs to the “HI” setting. Push the control knob until the burner ignites. The burner should ignite within 4 seconds (if burner does not ignite follow match lighting instructions on Page 25). -
Page 27: To Match Light The Grill
TO MATCH LIGHT THE GRILL If the burner will not light after several attempts using the control knobs, the burner may be lit with a match. 1. If you have already attempted to light the burner with the igniter, allow 5 minutes for any accumulated gas to dissipate. -
Page 28: Using The Side Burner
USING THE SIDE BURNER 4. If the smell of gas is detected and the igniter Inspect the gas supply hose prior to turning on is not functioning, immediately turn the control the gas. If there is evidence of cuts, wear or knob to the “OFF”... -
Page 29: Care & Maintenance Of The Grill
CARE & MAINTENANCE OF THE GRILL GRILL BURNERS STAINLESS STEEL Extreme care should be taken when moving a Grease specks can gather and bake onto the burner. It must be correctly centered on the surfaces of the stainless steel, giving the orifice before any attempt is made to relight the appearance of rust. -
Page 30: Troubleshooting
TROUBLESHOOTING WHEN TO LOOK FOR SPIDERS You should inspect the burners at least twice a WARNING year or immediately after any of the following Spiders and insects can nest inside the burners conditions occur: of the grill and disrupt gas flow. This very dangerous condition could cause a fire behind 1. -
Page 31: Exploded View
EXPLODED VIEW MODEL 730-0335... -
Page 32: Parts List
PARTS LIST Model No. 730-0335 DESCRIPTION DESCRIPTION Temperature Gauge Side Panel, Left Side Lid Front Trim Panel, Left Main Lid Swivel Caster 3 ” X 1 3/4” Logo Bottom Panel Main Lid Heat Insulating Spacer Cart Clapboard Main Lid Handle Heat Insulating... - Page 33 DESCRIPTION DESCRIPTION Side Shelf Trim Panel, Right Side Burner Orifice Connector Side Burner Lid Handle Side Burner Control Panel Side Burner Lid Hinge Rod Side Burner Gas V alve Side Burner LId Side Burner Manifold Side Burner Cooking Grate Side Burner Flex G as Line Side Burner Bowl Assembly Back Pie Cart Corner Fra...
-
Page 34: Grilling Hints
GRILLING HINTS The preparation of meat, whether rare, medium, To get the juiciest meat, add seasoning or salt or well done, is affected to a large degree by the after cooking is finished and turn the meat only thickness of the cut. once during cooking. - Page 35 FOOD WEIGHT FLAME APPROXIMATE SPECIAL OR THICKNESS SIZE TIME INSTRUCTIONS AND TIPS MEATS BEEF Hamburgers 1/2 to 3/4 inch Medium 10 to 18 minutes Grill, turning once when juices rise to the surface. Do not leave hamburgers unattended. A flare-up could occur quickly.
- Page 36 FOOD WEIGHT FLAME APPROXIMATE SPECIAL OR THICKNESS SIZE TIME INSTRUCTIONS AND TIPS Breasts Medium 30 to 45 minutes Marinate with Italian dressing well-done FISH AND SEAFOOD Steaks Grill, turning once. Brush with Halibut 3/4 to 1 inch Medium to 8 to 15 minutes Melted butter, margarine or oil Salmon High...
-
Page 37: Grill Recipe Suggestions
GRILL RECIPES seafood. Toss to coat. Cover, BARBECUED LONDON BROIL refrigerate 2 hours. 4 to 6 servings ¾ c. Italian dressing BBQ SALMON 2 large salmon steaks 2 tbs. oil Half-hour before cooking, turn the Salt & pepper burner to the grill on high. Drain 1tsp. - Page 38 overnight or a t least 6 to 8 hours. Wrap Strip off the skin and c hop eggplant PORK ROAST tortillas in foil. Remove meat from finely. Add all the seas onings. Chill Apple cider vinegar basting sauce: marinade. Cook on a pre-heate d gas grill thoroughly and serve on toast.
-
Page 39: Limited Warranty
LIMITED WARRANTY MODEL #730-0335 STAINLESS STEEL OUTDOOR GAS GRILL Nexgrill Industries, Inc. warrants to the original consumer-purchaser of each Jenn-Air Outdoor Gas Grill that when subject to normal residential use, it is free from defects in workmanship and materials for the periods specified below.
