Aruba 110 Series Access Points
AruBA 110 series Access Points
Optimize client performance in high-density Wi-Fi environments
Multifunctional and affordable 110 series wireless access
points (APs) maximize mobile device performance in high-
density Wi-Fi environments while minimizing interference
from LTE cellular networks.
These high-performance 802.11n APs deliver wireless data rates
up to 450 Mbps per radio and employ three spatial streams to
support 50% more throughput and mobile devices than previous-
generation APs.
The AP-115 and IAP-115 APs feature a 2.4-GHz and a 5-GHz radio,
each with 3x3:3 MIMO and three integrated omni-directional downtilt
antennas. The AP-114 and IAP-114 models feature the same radios
with three combined and diplexed external antenna connectors.
AdvAnced cellulAr coexistence (Acc)
The 110 series Advanced Cellular Coexistence (ACC) feature enables
Aruba WLANs to perform at peak efficiency by minimizing
interference from 3G/4G LTE networks, distributed antenna systems
and commercial small-cell/femtocell equipment.
Wi-Fi client oPtiMiZAtion
To eliminate sticky client behavior while users roam, the 110 series
features patented ClientMatch™ technology, which continuously
gathers session performance metrics from mobile devices.
If a mobile device moves out of range of an AP or if RF interference
impedes performance, ClientMatch automatically steers the device
to a better AP.
Best-in-clAss rF MAnAGeMent
All Aruba APs include Adaptive Radio Management™ technology,
which is essential to creating the most reliable, high-performance
WLANs. ARM™ manages the 2.4-GHz and 5-GHz radio bands to
optimize Wi-Fi client performance and ensures that Aps stay clear
of RF interference.
The 110 series can be configured to provide part-time or
dedicated air monitoring for spectrum analysis and wireless
intrusion protection, VPN tunnels to extend remote locations to
corporate resources, and wireless mesh connections where
Ethernet drops are not available.
cHoose Your oPerAtinG Mode
The 110 series of APs offers a choice of operating modes to meet
your unique management and deployment requirements.
Controller-managed mode. When managed by Aruba Mobility
Controllers, 110 series APs offer centralized configuration, data
encryption, policy enforcement and network services, as well as
distributed and centralized traffic forwarding. Please refer to the
Aruba
Mobility Controller
data sheets for more details.
Aruba Instant™ mode. In Aruba Instant mode, a single AP
automatically distributes the network configuration to other
Instant APs in the WLAN. Simply power-up one Instant AP,
configure it over the air, and plug in the other APs – the entire
process takes about five minutes.
For large installations across multiple sites, the Aruba Activate™
service significantly reduces deployment time by automating
device provisioning, firmware upgrades, and inventory
management. With Aruba Activate, Instant APs are factory-shipped
to any site and configure themselves when powered up.
If WLAN and network requirements change, a built-in migration
path allows 110 series Instant APs to become part of a WLAN that
is centrally managed by a Mobility Controller.

oPerAtinG Modes

802.11a/b/g/n controllerless Aruba Instant AP
802.11a/b/g/n Mobility Controller-managed AP
Remote AP (RAP)
Spectrum analysis identifies sources of RF interference
Air monitor provides wireless intrusion protection
Hybrid AP serves Wi-Fi clients and provides wireless intrusion
protection and spectrum analysis
Secure enterprise mesh
securitY
With an
OpenDNS
service subscription, Aruba Instant RAPs
deliver integrated web filtering, malware and botnet protection to
every device connected to the WLAN
Integrated Trusted Platform Module (TPM) for secure storage of
credentials and keys
SecureJack-capable for secure tunneling of wired Ethernet traffic
