INSTALLATION
FCC Information
This equipment has been tested and found to
comply with the limits for a Class A digital
device, pursuant to Part 15 of the FCC Rules.
These limits are designed to provide reasonable
protection against harmful interference when
the equipment is operated in a commercial
environment. This equipment generates, uses
and can radiate radio frequency energy and if
not installed and used in accordance with the
instruction manual, may cause harmful
interference to radio communications.
Operation of this equipment in a residential area
may cause harmful interference in which case
the user will be required to correct the
interference at his own expense.
Precautionary Designations
CAUTION
RISK OF ELECTRIC SHOCK
DO NOT OPEN
CAUTION: To reduce the risk of electric shock,
Do not remove cover.
No user serviceable parts inside.
Refer servicing to qualified service personnel.
This symbol indicates that dangerous
voltage constituting a risk of electric
shock is present within this unit.
This symbol indicates that there are
important operating and maintenance
instructions in the literature accompanying
this unit.
Mounting (VIP-LLE)
The VIP-LLE Network Extender is designed for wall
or shelf mounting and must be within 300 feet of the
network switch.
Shelf: Provided with the VIP-LLE Network Extender
are four rubber stick on pads. Peel pads off their
carrier backing and place at the four corners of the
bottom of the unit.
Wall: Using the brackets and wood screws
provided, secure the VIP-LLE Network Extender
to the wall.
Mounting (horn)
FLUSH MOUNT
The cardboard packing material in which the horn is
shipped also serves as the template for flush
mounting. Using the template, draw the speaker
outline on the wall to be cut. Make appropriate
wiring connections and test the speaker for
operation. Using appropriate mounting screws
(not furnished) drill and mount the flange as
shown.
UNIVERSAL BRACKET
Loosen or separate the universal bracket leaves
by loosening or removing the handle and
hardware. Using the back leaf as a template,
mark the wall through the mounting holes. Drill
and mount to the wall using appropriate screws
(not furnished) or mount directly to a junction box.
Mount the T-bracket to the back of the horn as
shown using the (2) ½ inch screws provided.
"C" CLAMP FOR "I" BEAM MOUNTING
A "C" clamp is provided with the horn to allow
mounting to a beam. Attach the "C" clamp to the
back of the horn as shown using the (2) ½ inch
screws provided. Place the bolt through the hole
in the bottom of the base to secure the "C" clamp
to the beam. It is suggested that the horn be
mounted to the underside of the "I" beam to
provide maximum positioning adjustments.
Interconnections
The only method of powering a VIP-480L IP
Paging Horn is via a Power over Ethernet (PoE)
switch or power injector meeting the 802.3af
specification.
Make all required signal connections before
connecting to Ethernet switch or power injector
meeting the 802.3af specification. Power is
supplied to the horn assembly via the
VIP-LLE Network Extender.
Network Connection
As shown in Figure 1, the LLE Network Extender
has one RJ-45 network connector on the front
panel. Use a standard Ethernet patch cable to
connect the NETWORK connector of the LLE
Network Extender to a 802.3af compliant PoE port
(300 feet maximum distance).
Signal Connections
As shown in Figure 1 and 2, audio output
connections are made on the rear panel of the
LLE Network Extender. Versions of the LLE
Network Extender with the color-coded, 8-pin
screw connector will connect standard CAT-5
twisted-pair cable from the rear panel color coded
connector of the LLE Network Extender to the
supplied VM-186 RJ-45 connector (900 feet
maximum distance). Connect RJ-45 connector
of horn to VM-186 RJ-45 socket.
