FCC Information
This equipment has been tested and found
to comply with the limits for a Class A digital
device, pursuant to Part 15 of the FCC Rules.
These limits are designed to provide
reasonable protection against harmful
interference when the equipment is operated
in a commercial environment. This
equipment generates, uses and can radiate
radio frequency energy and if not installed
and used in accordance with the instruction
manual, may cause harmful interference to
radio communications. Operation of this
equipment in a residential area may cause
harmful interference in which case the user
will be required to correct the interference at
one's own expense.
IMPORTANT SAFETY INFORMATION
CONSIGNES DE SÉCURITÉ IMPORTANTES
1. Read these instructions.
Lisez ces instructions.
2. Keep these instructions.
Conservez ces instructions.
3. Heed all warnings.
Respectez tous les avertissements.
4. Follow all instructions.
Suivez toutes les instructions.
5. Do not use this apparatus near water.
Ne pas utiliser cet appareil près de l'eau.
6. Clean only with dry cloth.
Nettoyer avec un chiffon sec.
7. Do not block any ventilation openings. Install in accordance with the manufacturer's
instructions.
Ne pas bloquer les ouvertures de ventilation. Installer formément aux instructions du
fabricant.
8. Do not install near any heat sources such as radiators, heat registers, stoves or other
apparatus (including amplifiers) that produce heat.
Ne pas installer à proximité de sources de chaleur telles que radiateurs, registres de
chaleur, poêles ou autres appareils (y compris les amplificateurs) produisant de la chaleur.
9. Do not defeat the safety purpose of the polarized or grounding-type plug. A polarized plug
has two blades with one wider than the other. A grounding type plug has two blades and a
third grounding prong. The wide blade and the third prong are provided for your safety. If
the provided plug does not fit into your outlet consult an electrician for replacement of the
obsolete outlet.
Ne pas contourner le dispositif de sécurité de la fiche polarisée ou de mise à la terre. Une
fiche polarisée possède deux lames dont une plus large que l'autre. Une fiche de terre a
deux lames et une troisième broche de mise à la terre. La lame large et la troisième
broche sont fournies pour votre sécurité. Si la fiche fournie ne rentre pas dans votre prise,
veuillez consulter un électricien pour le remplacement de la prise obsolète.
10.Protect the power cord from being walked on or pinched particularly at plugs, convenience
receptacles and the point where they exit from the apparatus.
11.Only use attachments/accessories specified by the manufacturer.
N'utilisez que des fixations / accessoires spécifiés par le fabricant.
12. Use only with the cart, stand, tripod, bracket or table specified
by the manufacturer or sold with the apparatus. When a cart is
used, use caution when moving the cart/apparatus combination
to avoid injury from tip-over.
Utilisez uniquement avec le chariot, stand, trépied, support ou table spécifié par le
fabricant ou vendu avec l'appareil. Quand un chariot est utilisé, Soyez prudent lorsque
vous déplacez l'ensemble chariot / appareil pour éviter des blessures dues au
renversement.
13. Unplug this apparatus during lightning storms or when unused for a long period of time.
Débranchez cet appareil pendant les orages ou lorsqu'il n'est pas utilisé pendant une
longue période de temps.
14. Refer all servicing to qualified service personnel. Servicing is required when the
apparatus has been damaged in any way. Such as when the power supply cord or plug is
damaged, liquid has been spilled, objects have fallen into the apparatus or the
apparatus has been exposed to rain or moisture and does not operate normally or has
been dropped.
Confiez toute réparation à un personnel qualifié. Une réparation est nécessaire lorsque
l'appareil a été endommagé de quelque façon. Par exemple lorsque le cordon
d'alimentation ou la fiche est endommagé, du liquide a été renversé, si des objets sont
tombés dans l'appareil ou le appareil a été exposé à la pluie ou à l'humidité et ne
fonctionne pas normalement ou s'il est tombé.
INSTALLATION
Mounting
The VIP-142 is shipped with the mounting base
attached to the horn with screws. Remove the
screws and save them for reassembly. Pull the
metal base away from the horn to separate
them. The base can be mounted to a single-
gang or double-gang electrical box, directly to a
surface (wall) or clamped to a structural I-beam.
When mounting vertically, note the "UP"
indicator on the base to orient it correctly. The
horn is mounted to the base after the base is
properly secured. Gaskets and grommets are
provided to enhance weather resistance.
Wall or Surface Mounting
Install the network ethernet cabling to the
mounting location. If using the call switch input
and/or relay output of the VIP-142, install the
cabling for those connections. Route the cables
through the large gasket (if used) and then
through the back of the mounting base. Install a
split grommet around the ethernet cable and call
switch/relay wiring and press into the mounting
base holes. If not using the call switch/relay
wiring, use the solid grommet plug to fill the
extra hole. See Figures 1 and 2.
If using the relay or call switch, make wiring
connections to the screw terminals on the
mounting base. The terminals are labeled for
the Relay Normally Open (NO) and Common
(COM) and the Call Switch In and Ground.
For mounting to an electrical box, use the four
#6-32 screws (included) to attach the mounting
base to the box, as shown in Figure 3.
For mounting to a solid surface, such as a wall,
use appropriate hardware to attach the
mounting bracket to the surface. See Figure 4.
I-Beam Mounting
A C Clamp is provided for mounting to the
flange of an I-Beam. Attach the C Clamp to the
metal mounting base using the ¼-20 x 3/8"
machine screw through the hole in the center of
the base. Install network ethernet cabling and
call switch/relay connections as noted in the
Wall or Surface Mounting instructions above.
Attach the base to the I-Beam by sliding the C
Clamp over the I-Beam flange and tightening
the screw securely. See Figure 5.
If not using the C Clamp, a rubber plug is
provided to fill the hole in the base.
