LevelOne GSW-5150 Brochure & Specs

48-Port 10/100 Rackmount Switch + 2 Gigabit
Fast connections and fiber distances
GSW-5150 is a 48-port Fast Ethernet Switch (10/100 Mbps) that gives you
a high-performance, low-cost, easy-to-use, solution to expand your network
reach. With 2 Gigabit ports, you're able to connect to other networks giving you
flexible and powerful deployment options. And the 1 SFP port (you can link up
with other offices up to 70km away. (SFP module sold separately.)
Bandwidth hungry? Not a problem.
What happens when you have several users accessing multimedia applications
all at the same time? No need to worry as GSW-5150 allows you to move large
files faster and easier. Transfer your CGI, CAD, video, or other large multimedia
files over the network instantly and without lag. And with the fiber connection
option, you can even share these files to remote offices up to 70km away.
Standards-based
GSW-5150 features a non-blocking switching architecture that forwards and filters
packets at full wire-speed for maximum throughput. With MAC address auto-
learning and auto-aging, IEEE802.3x flow control for full-duplex mode and
backpressure for half-duplex mode, you have powerful features sending your
data throughout the network.
Plug and Play, Flexible and Easy
GSW-5150 is plug-and-play so no configuration is required. Providing auto
MDI/MDI-X cable detection on all ports eliminates the need for crossover cables
or Uplink ports. Each port can be used as general ports or Uplink ports, and any
port can be simply plugged into a server, a hub, a router or a switch, using a
straight cable or crossover cable. Diagnostic LEDs which display link status and
activity, allowing you to quickly detect and correct problems on the network.

Key Features

• 48 10/100 Mbps , 2 10/100/1000Mbps Half/Full
Duplex, Switched RJ-45 Ports
• 1SFP Port Provides Fiber Connectivity for
extended distance
• Supports Auto-negotiation and Auto-MDI/MDI-X
on all ports
• Supports full-duplex IEEE 802.3x flow control
• Store-and-forward switching architecture
Digital Data Communications GmbH.
Zeche-Norm St. 25, 44319, Dortmund, Germany
All mentioned brand names are registered trademarks and property of their owners.
Technical specifications are subject to change without notice.
© 2008 All Rights Reserved
For more information, please contact your LevelOne representative, or visit www.level1.com
All technical specifications are subject to change without notice.
All mentioned brand names are registered trademarks and property of their owners
www.level1.com

Ethernet Switch

GSW-5150
Ports + 1 SFP Port
•
•
•
•
•
GSW-5150

Front View

Back View

Complies with IEEE 802.3, 802.3u and
802.3ab, 802.3z standards
Wire-speed packet filtering and forwarding
rate
8K MAC Address and 128KB buffer memory
Large 20 G switching bandwidth
19-inch rack-mountable
H/W Ver.1.0
