Page 1: User Manual
LevelOne User Manual GSW-0509 / GSW-0809 5/8-Port Gigabit Switch w/ Internal Power V1.0... -
Page 2: Fcc Certifications
FCC Certifications This Equipment has been tested and found to comply with the limits for a Class A digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference when the equipment is operated in a commercial environment. - Page 3 The switch is plug-n-play without any software to configure and also fully compliant with all kinds of network protocols. Before you start to install the switch, check the following contents in this package： GSW-0509/GSW-0809 Switch One power cord User’s manual...
-
Page 4: Led Definition
Link/ACT Blinking Green The port is transmitting/receiving data Rear Panel The rear panel of the GSW-0509/GSW-0809 switch consists of a DC power connector and 5/8 10/100/1000Mbps RJ45 Ports. The following figure shows the rear panel of the Switch. GSW-0509 GSW-0809... - Page 5 Stations Connection Connect each station to the switch by twisted-pair cable. Plug one RJ-45 connector into a RJ-45 port of the switch, and plug the other RJ-45 connector into the station’s network adapter. Power on the switch and then system is ready. For cable selection, refer to the following table.
- Page 6 5/8 * 10/100/1000Mbps RJ-45 Gigabit Ethernet Ports (GSW-0509/GSW-0809) NWay Protocol 10Mbps: Full/Half duplex Support 100Mbps: Full/Half duplex 1000Mbps: Full duplex only MAC Address 1K MAC Address entries (GSW-0509) Table 4K MAC Address entries (GSW-0809) Buffer Memory 104KBytes (GSW-0509) 128KBytes (GSW-0809) Jumbo Frame 9K Byte (GSW-0509/GSW-0809)
-
Page 7: Technical Support
Technical Support Thank you for selecting LevelOne products. LeveOne’s website contains the latest user documentation and soft-ware updates for LevelOne products. Please contact LevelOne Technical Support through our website. World Wide Web http://global.level1.com/...
