TECHNICAL
SPECIFICATIONS
Input power requirements:
At AC Transformer: 110 - 125 Volts AC Only; 50-60 Hz
At power jack on ATX-250: 12-15 Volts AC only
Power consumption Idle: 3 Watts
Ringing a device: 6-11 Watts
CO Interface: Ren 1 . 1 B
DOC (Canada) Load No . 83
Input ring detection: 40-150 Volts AC; 15-68 Hz
DEVICE Interface:
Battery: Nominal - 45 .5 Volt DC to devices 1 and 2
Off-hook detection: 3-150 ma
Ringer frequency: 33 Hz Pseudo-sinewave
Ringing no load: Approximately 145 .6 Volts AC
Ringing 8000 ohm impedance
(REN 1.O): Approximately 116 VAC
Ringing 4000 ohm impedance
(REN 2.0): Approximately 98 VAC
Ringing 2667 ohm impedance
(REN) 3.0): Approximately 83 VAC
Ringing short circuit: current limited to 110 ma with ring trip . (impedances less than
SERVICE INFORMATION
Your machine has been registered with the Federal Communications Commission, and
under this program, in the event of equipment malfunction, all repairs will be performed by
Multi-Link, Inc . or a warranty repair center that we have authorized . The owner is restricted
from performing any maintenance operation other than those specified within this instruction
manual .
If you require service, please contact your Versa-Link dealer or Multi-Link, Inc .
VERSA-LINK ATX-250
2667 ohms not recommended)
Multi-Link, Inc .
225 Industry Road
Nicholasville, KY 40356
(859) 885-6363
FAX (859) 885-6619
www .multi-link .net
24
