INSTALLATION
If you are not using FAX, choose the data
device that most of your incoming calls
should go to . Attach this device to the
DEVICE 1 connector on the back of your
ATX-250 . Attach the other data device to
the DEVICE 2 connector .
If you are not using FAX, or if your FAX is
attached to DEVICE 1, you should disable
auto FAX detection . Set the configuration
switch position 6 to the "down" position .
Unplug the power cord from your ATX-
250 for about 2 seconds and re-connect
it to activate the new switch settings .
5.4.4 ADDING AN
ANSWERING MACHINE
If you use an answering machine, attach
it to the same connector that your
telephone system is attached to . You may
either connect your telephone system
through your answering machine, if a
connector is provided on the answering
machine for that purpose, or you may
need to use a multi-outlet Y-adapter .
You may also want to leave instructions
on the outgoing message to instruct
callers on how to access your data
equipment . If you have a FAX attached to
DEVICE 2, remember to give out your
device selection code for access to your
VERSA-LINK ATX-250
FAX, so that callers with manually dialed
FAX machines can send you messages
while you are not there . A sample
message might be:
"Hello, this is _______________. If you
would like to leave a FAX message,
press star-two to ring our FAX
machine. If you would like to leave a
voice message, please begin speaking
after the tone. Thank you for calling."
5.5 CONFIGURING THE
5.5 ATX-250 TO YOUR
5.5 APPLICATION
Depending on your application, you may
want to change the factory settings of the
configuration switches or change the
device selection codes .
For a detailed description of all the opera-
tional features, and step-by-step informa-
tion on how to select them, see section 6,
USER SELECTABLE FEATURES .
5.6 GENERAL RULES OF
5.6 INSTALLATION
When installing your ATX-250 there are
three general principles to keep in mind:
5.6.
Your ATX-250 must be the only device
directly connected to the telephone
company's incoming line.
There cannot be any extensions or data
devices connected in parallel with your
ATX-250 on this line . All extensions and
data devices must be connected to one
of the DEVICE ports on the back of your
ATX-250 .
