USER SELECTABLE
FEATURES
6.2 CALL OPTI-MIZER
CALL OPTI-MIZER is useful if you want
all incoming calls to go to DEVICE 2
when your office is unattended . See
section 4 .2 .3 for a detailed description .
When using CALL OPTI-MIZER, there
are three choices for the parameters
that determine when a call is sent to DE-
VICE 2 . CALL OPTI-MIZER can also be
completely disabled . Set the configuration
switches 3 and 4 according to the follow-
ing table:
Remember to unplug and re-connect the
AC power after changing the configuration
switches .
VERSA-LINK ATX-250
6.3 PROTECTED HOOK
6.3 FLASH
Some key tone telephone systems do not
allow tone generation on an inbound call .
On these systems, manual transfers can
still be accomplished by fooling the
telephone system into thinking it is
making an outbound call . This is done by
pressing the "FLASH" key on the
telephone, and then dialing the device
code for DEVICE 2 .
For example, if your FAX is connected to
DEVICE 2, and the device selection code
for DEVICE 2 is
manually transferred to the FAX by
pressing FLASH and then
To prevent the caller from being hung up
when the FLASH key is pressed, you will
want to activate Protected Hook Flash .
This will place the call on hold while the
flash button momentarily disconnects the
line . Protected Hook Flash cannot be
used if your phone is pulse-dial or if this
line has "call waiting" .
Configuration switch 5 is used to select
Protected Hook Flash . Remember to
unplug and re-connect the AC power
after changing the configuration switch .
, calls can be
*
2
*
2
.
PROTECTED
HOOK FLASH
