Multi-Link ATX-300 Supplementary Manual

PROGRAMMABLE FEATURES

This insert addresses the programming of Device Selection Codes and Factory
Settings for the 6 port Versa-Link ATX-300/6. All other user-selectable
and functions are the same as the ATX-300 3-port model. Please retain this insert,
along with your manual, for future reference
7.2 Proarammlna Device Selection Codes
Your ATX-300/6 analyzes incoming calls for (DTMF) touch-tones and detects both
pulse-dial and touch-tone device selection codes transmitted from either end of the
telephone line. Device selection codes are programmable and can be from 2 to 7
digits long using any combination of digits 0 to 9 and the symbols * and #.
Using the symbols * and # in the device selection code is a good way to
avoid unwanted transfers when dialing out to another number. If your telephone is
pulse-dial only, you should not use these symbols in your code because the pulse-
dial phone will not transmit when these symbols are punched on your keypad.
The device selection codes are programmed by pressing keys on a tone or pulse-
dial phone connected to one of the DEVICE ports on the rear panel of the ATX-
300/6. You should connect the incoming phone line to the port labeled LINE, also
at the rear of the unit.
To avoid dialing through to a number while programming a device selection code,
we suggest that you either establish a local call before programming (dial one of
your other lines if you have one) or hang up the line between each device code
program.
NOTE: If at any point in the programming process you are unsure and would like
to start again, unplug the AC power cord and reconnect it. The ATX-300/6 will
enter its start-up mode and you can start over with step 1.
1) HOLD the front panel push button in for about 3 seconds until the STBY light
starts to "blink" in a steady cadence. RELEASE the push button. The STBY
LED will continue to blink. (Go to step 2)
2)
At this time, you can enter a device code for DEVICE 1 on your telephone key-
pad. If no code is entered at this point, the existing code will remain in effect.
(Go to step 3)
3)
PRESS AND IMMEDIATELY RELEASE the push button. The SEMI light will
now be blinking in a steady cadence. At this time, you can enter the device
code for the DEVICE 2 on your telephone keypad. If no code is entered at this
point, the existing code will remain in effect. (Go to step 4)
4) PRESS AND IMMEDIATELY RELEASE the push button. THE AUTO light will
now be blinking in a steady cadence. At this time, you can enter a device code
for DEVICE 3. If no code is entered at this point, the existing code will remain
in effect. (Go to step 5)
5)
PRESS AND IMMEDIATELY RELEASE the push button. The STBY light will
now emit a "blink-blink" cadence. You can now enter the device code for
DEVICE 4 on your telephone keypad. If no code is entered, the old code
remains in effect. (Go to step 6)
