Chapter 2: Installation
Mechanical Mounting
To mount the Wireless MultiModem, do the following:
1. Obtain mounting screws (two are needed) that are appropriate for the surface on which you will
mount the MultiModem. For example, one might use two 6-32 self-tapping screws 5/8" in length
to mount the unit in a truck to the wall of the cab behind the passenger's seat.
2. Typically, the unit is mounted against a flat surface into which holes can be drilled. The
mounting holes (center-to-center) must be separated by 125mm or 4 -15/16 inches.
Drill the mounting holes at the desired mounting location (if applicable).
Spacing of Mounting Screws
125 mm
or 4
Mounting Bracket Locations (2)
15
inches
16
Chapter 2 – Installation
