Specifications
Mechanical Dimensions & Weight
Connectors & Fasteners
Operating Temperatures
Humidity
Certifications
Switching the GSM modem on/off
Voltage Range
Parameters
Input average supply current in
comm. mode at P
Input average supply current in idle
mode
Multi-Tech Systems, Inc. MultiModem® GPRS with USB User Guide
General Specifications
4.3" w x 2.4" h x 0.94" d; 3.6 oz.
(11 cm x 6.1 cm x 2.4 cm; 102 g)
Antenna Connection type: SMA jack
Data/Power Connector: USB Series A receptacle
Phone Handset: Modular Handset Jack
SIM receptacle:
0 to +50°C
Relative humidity 20% to 90% noncondensing
CE Mark
EMC: FCC Part 2, 15, 22, 24, EN 55022 & EN 55024
Safety: UL 60950, EN 60950
Electrical Characteristics
The device is permanently powered (when connected to the
power supply).
Voltage range : 5 to 32V DC
GND : 0V
Current Requirements
GSM/GPRS 850/900 GSM/GPRS 1800/1900
max
Chapter 1 – Description & Specifications
(standard)
Typ.
Typ.
360
300
30
30
Unit
mA
mA
10
