Microweb PRO SERIES User Manual page 70

Other
networking
problems
The Power Faulty power
LED is not supply
constantly lit
The Network
Faulty cabling
LED is off
The Operating Faulty
Status LED is connection
off
The camera Firewall
works protection
locally, but not Default routers
externally required The
Internet site's
too heavily
loaded
A series of The CCD
broad, sensor
vertical white becomes
lines appears overloaded
across the when the light
image is too bright, as
with reflected
sunlight
Bad focus Focus has not
been correctly
adjusted
your camera match the first 3 of your workstation.
If not, your camera may be on a different subnet and the
IP address cannot be set from this workstation. You
must set the IP address for the camera from a
workstation on the same subnet.
Trying replacing your network cable. Test the network
interface of the product by connecting a local computer
to the unit, using a standard crossover (hub-to-hub)
cable. If the above actions don't resolve the problem, the
camera maybe faulty. In this case, try to localize the
problem by connecting the camera to the serial port of a
local computer, using the RS-232 cable.
Verify that you are using the provided power supply.
1. To verify that the cables are functional, PING the
address of a known existing unit on your network.
2. If the cabling is okay and your network is reachable,
you should receive a reply similar to this: . . . bytes = 32
time = 2 ms,
Verify that the power source is properly connected.
Check the Internet firewall with your system manager.
Check if you need to configure the default router
settings. Configure the camera to upload your video
images to an FTP server or an ISP.
Direct exposure to extreme sunlight or halogen light may
cause serious damage to the CCD sensor. Re-position
your camera into a more shaded location immediately.
NOTE: Damage caused to a Pro Series Network
Camera through over-exposure to direct sunlight or
halogen light is not covered under the product warranty.
Adjust the camera manually until the image appears
clear.
