Strong SRT 5006 User Manual

Digital free-to-air terrestrial receiver
Hide thumbs Also See for SRT 5006:
Table of Contents

Advertisement

Quick Links

Download this manual See also: User Manual
Digital Free-To-Air Terrestrial
Receiver SRT 5006
User Manual

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the SRT 5006 and is the answer not in the manual?

Questions and answers

Related Manuals for Strong SRT 5006

Summary of Contents for Strong SRT 5006

  • Page 1 Digital Free-To-Air Terrestrial Receiver SRT 5006 User Manual...

  • Page 4: Environmental Issues

    ENVIRONMENTAL ISSUES Strong is committed to reducing the impact of its products on the environment. Electronic product recycling Packaging Do not dispose of this product with your When disposing of this domestic rubbish. product packaging, please ensure that it is recycled.

  • Page 5: Table Of Contents

    PART 1 • English TABLE OF CONTENTS 1.0 INSTRUCTION 1.1 Safety Instructions 1.2 Storage 1.3 Equipment Set-up 1.4 Features & Accessories 2.0 CONNECTION 2.1 Connecting to Terrestrial Antenna 2.2 Connecting to TV and VCR with SCART cable 2.3 Connecting to a Digital Audio Amplifier 2.4 Connecting to PC 3.0 YOUR RECEIVER 3.1 Front Panel...

  • Page 6: Instruction

    PART 1 • English 1.0 INSTRUCTION 1.1 Safety Instructions DO NOT INSTALL YOUR RECEIVER: In a closed or poorly ventilated cabinet; directly on top of or under any another equipment; on a surface which might obstruct the ventilation slots DO NOT EXPOSE THE RECEIVER OR ITS ACCESSORIES: To direct sunlight or near any other equipment that generates heat;...

  • Page 7: Storage

    PART 1 • English 1.2 Storage Your receiver and its accessories are stored and delivered in a packaging, protected against electric damage and moisture. When unpacking, make sure all parts are included. Keep packaging away from children. For transportation from one place to another or if you are returning the receiver under warranty make sure it is repacked in its original packaging with all accessories.

  • Page 8: Features & Accessories

    PART 1 • English 1.4 Features & Accessories For all digital Free-To-Air TV and Radio programmes (with outdoor or indoor terrestrial antenna) DVB-T compliant, Digital UHF/ VHF Tuner with Loop-through function Set-up support for first time installation Quick and easy installation & user-friendly menu Multi-lingual support on screen Excellent Audio and Video quality Digital audio output through coaxial S/PDIF...

  • Page 9: Connection

    PART 1 • English 2.0 CONNECTION 2.1 Connecting to Terrestrial Antenna To receive the broadcast signal, the terrestrial antenna cable should be connected to the ANT IN connector at the back of the receiver. (FIGURE 1) 2.2 Connecting to TV and VCR with SCART cable The TV set should be connected with the receiver through a SCART cable (fig.

  • Page 10: Your Receiver

    PART 1 • English 3.0 YOUR RECEIVER 3.1 Front Panel Figure 4 Mode indicator The RED light indicates that the receiver is in STAND-BY mode. The GREEN light indicates that the receiver is in AWAKE mode. Power ON/OFF button Up/Down buttons 3.2 Rear Panel Figure 5 1.

  • Page 11: Remote Control

    PART 1 • English 3.3 Remote Control Turns the receiver On/Standby Mutes audio output of the receiver Toggle between TV and AV mode 0 ~ 9 Channel selection Toggle Favourite mode ON / OFF TV/R Toggle between TV or RADIO mode MENU Opens the main menu INFO...

  • Page 12: First Time Installation

    PART 1 • English 4.0 FIRST TIME INSTALLATION Make sure your terrestrial receiver is connected correctly to your TV and terrestrial antenna and the signal quality is good enough. Confirm the power plug of the receiver is plugged into the wall outlet. Turn on the receiver.

  • Page 13: Main Menu

    PART 1 • English 5.0 MAIN MENU All the important settings and features of your receiver can be operated in Main Menu. With Menu off, press MENU key. The MAIN MENU screen will appear. It consists of five sub-menus: “Channel Organiser”, “Channel Search”, “Installation”, “Timer” and “Game”. 5.1 Channel Organiser In MAIN MENU screen, press UP/DOWN to move the cursor to Channel Organiser, and press OK to enter the Channel Organiser menu.

  • Page 14: Installation

    PART 1 • English 5.2.1 Automatic Search Press OK over the Automatic Search. The warning message “Do you want to start Automatic Search?” will appear. Press LEFT/RIGHT to move the cursor and OK to continue. The message “Do you want to erase your previous channel list?” will appear.

  • Page 15: Antenna Power

    PART 1 • English TV Format Press OK/RIGHT to select 4:3 or 16:9, and OK to confirm. Video Output Press OK/RIGHT to select CVBS or RGB, and OK to confirm 5.3.1.3 Country Press OK/RIGHT to select your country, press OK to confirm. If your country is not in the list, select Other.

  • Page 16: Parental Control

    PART 1 • English 5.3.3 Parental Control In this menu, you can set Channel Lock status (ON or OFF), the Menu Lock status, Parental Setting and change the PIN Code. The default PIN code is 0000. 5.3.3.1 Channel Lock Set the system Channel Lock to ON or OFF. If the channel lock is ON, the parental PIN code has to be entered correctly before watching the locked channel.

  • Page 17: Timer

    PART 1 • English 3. When the status displays “detecting slave STB”, power on slave STB, after the master STB detects the slave, the master starts transmission and burns. 4. While transmitting and burning, it is very important to avoid other operations such as power off because this may cause destruction of the data in the FLASH memory and the receiver will need to be repaired.

  • Page 18: Game

    PART 1 • English You can select from the following functions: “Power On”: The receiver powers on at the designated date and time. “Time interval”: The receiver switches on at the designated date and time, displays the channel and then switches off at the designated date and time (The value set at the end time). “Power Off”: The receiver powers off at the designated date and time.

  • Page 19: Other Operations

    PART 1 • English 6.0 OTHER OPERATIONS 6.1 Mosaic In no-menu state, press MOSAIC button. Screen will be divided into nine pictures. Press UP / DOWN/ LEFT / RIGHT keys to choose one of current programs. Press P+ / P- keys to view another nine programs. Press OK key to return to normal play state and play the selected program.

  • Page 20: Troubleshooting

    PART 1 • English A.1 TROUBLESHOOTING Before requesting service, please check the table for a possible cause of the problem. Some simple checks or minor adjustments may restore proper operation. The most common problems are related to cable connections, please disconnect and connect all cables again. If none of the below indicated remedies solve the problem, consult your vendor.
  • Page 21 PART 1 • English Symptom Remedy Electronic Program Guide (EPG) EPG empty The selected program does not support EPG. The local time is incorrect. Set the correct local time Audio & video issues TV Picture changes This may happen after a power-cut or disconnection from the power colour source.

  • Page 22: Specifications

    PART 1 • English A.2 SPECIFICATIONS Demodulator Demodulator: COFDM; 16 QAM / 64 QAM Transmission mode: 2 K ~ 8 K Video Decoder Profile level: MPEG-2 MP@ML Video resolution: 720 x 576 pixels (PAL), 720 x 480 (NTSC) Decoding & Video Out: PAL &...

  • Page 23: Glossary Of Terms

    PART 1 • English General Data Supply Voltage: 90 ~ 240 V AC (SMPS), 50/60 Hz Power Consumption (max): 20 W Standby Power Consumption: < 10 W Operating Temperature: 0 °C ~ 40 °C Storage Temperature: -30 °C ~ 80 °C Operating Humidity Range: 10 ~ 85 %, RH, Non-condensing Net-weight:...
