USER'S MANUAL
MODEL NUMBER: PG-50506SRLA-SC
CUSTOMER SERVICE: (888)-287-0735
DANGER
If you smell gas:
1.
Shut off gas to the appliance.
2.
Extinguish any open flame.
3.
Open lid.
4.
If odor continues, keep away from the
appliance and immediately call your gas
supplier or your fire department.
FOR OUTDOOR USE ONLY
WARNING
1.
Do not store or use gasoline or other
flammable liquids or vapors in the
vicinity of this or any other appliance.
2.
An LP cylinder not connected for use
shall not be stored in the vicinity of this
TM
or any other appliance.

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the PG-50506SRLA-SC and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for PERMASTEEL PG-50506SRLA-SC

Summary of Contents for PERMASTEEL PG-50506SRLA-SC

  • Page 1 FOR OUTDOOR USE ONLY USER’S MANUAL MODEL NUMBER: PG-50506SRLA-SC CUSTOMER SERVICE: (888)-287-0735 DANGER WARNING If you smell gas: Do not store or use gasoline or other Shut off gas to the appliance. flammable liquids or vapors in the Extinguish any open flame.
  • Page 2 Product, use contrary to this User’s Manual, or alteration by any one other than Permasteel Inc. All warranty coverage is void if this grill is ever used for commercial or rental purposes; this warranty is valid only in the USA.

  • Page 3: Table Of Contents

    TABLE OF CONTENTS BEFORE YOU BEGIN MESSAGE TO OUR USERS PAGE 1 SAFETY SYMBOLS PAGE 1 INSTALLATION & SAFETY PRECAUTIONS PAGE 2 PROPANE & GAS WARNING PAGE 2 ASSEMBLY PARTS PAGE 3 STEP I PAGE 6 STEP II & STEP III PAGE 7 STEP IV &...

  • Page 4: Message To Our Users

    MESSAGE TO OUR USERS Thank you for your purchase of our Stainless Steel BBQ Gas Grill. We sincerely wish you will enjoy using our fine products. Please read this User’s Manual in its entirety before using the grill. Please contact our customer service at (888)-287-0735 if you have any questions. Please read this User’s Manual carefully.

  • Page 5: Installation/Safety Precautions

    This grill is safety certified for use in the United States and Canada only. Never modify to use in other places. Modification may cause serious bodily injury or property damage. PermaSteel is not responsible for any modifications, and all warranties will be void.

  • Page 6: Parts

    GRILL PARTS DIAGRAM...
  • Page 7 GRILL PARTS LIST REF# DESCRIPTION Q’TY REF# DESCRIPTION Q’TY Double-layer Lid Clapboard Temp. Gauge Seat Lid Rotote Pin Nut Temp. Gauge Lid Rotate Pin Clip Rings Back Panel Name Plate NG hose Hole Bushing Handle Seat Firebox Handle Warming Rack Grease Tray Cooking Grids Knobs...
  • Page 8 GRILL PARTS DIAGRAM REF# Parts of Left Cabinet Left CounterTop Back Panel Cross Bar Magnets Outside Side Panel Drawer Brackets Sliding Bars Drawer Seat Drawer Transom Inside Side Panel Drawer Front Panel Drawer Handle Upper Door Hinge Left Door Handle Left Door Door Transom Bottom Panel...

  • Page 9: Step Ipage

    ASSEMBLY INSTRUCTIONS STEP I: Take out grill body and the cabinets from packing carton, and remove all the packing materials.

  • Page 10: Step Ii & Step

    ASSEMBLY INSTRUCTIONS STEP II: Remove packing material from flame tamers, cooking grids, warming rack, then place them in the proper positions shown below. STEP III : When the grill is in the desired location, lock the caster brakes, this will keep the grill unit in place for safe operation.
  • Page 11 ASSEMBLY INSTRUCTIONS STEP IV : Place the side cabinets close to grill, make them on the same line. STEP VII: When the grill island is in the desired location, lock the caster brakes of cabinets, this will keep them in place for safe operation.

  • Page 12: Safety Notice

    ASSEMBLY INSTRUCTIONS Safety Notice: The regulator hose should go through the U shaped bracket, in order to prevent the hose from lifting up and touching the hot firebox. Note: if replacing regulator please make sure to put regulator hose through U shape bracket.

  • Page 13: Gas Connection

    GAS CONNECTION ONLY USE THE REGULATOR AND HOSE ASSEMBLY PROVIDED WITH THIS GRILL. REPLACEMENT PRESSURE REGULATORS AND HOSE ASSEMBLIES MUST BE THOSE SUPPLIED BY THE MANUFACTURER This is a LP (Liquefied Petroleum Gas) configured grill. Do not attempt to use a natural gas supply unless the grill has been reconfigured for natural gas use.
  • Page 14 GAS CONNECTION CONNECT THE REGULATOR TO THE LP TANK VERY IMPORTANT: - THE REGULATOR SHALL NOT BE IN A LOCATION THAT WILL ATTAIN A TEMPERATURE ABOVE 140℉（60℃）. - THE REGULATOR SHALL INCORPORATE A PRESSURE RELIEF VALVE OR OVERPRESSURE DEVICE. - THE INLET OF THE PRESSURE REGULATOR SHALL BE FITTED TO CONNECT THE TYPE I CONNECTION OF THE TANK VALVE PER ANSIZ21.81.
  • Page 15 GAS CONNECTION WARNING Never insert any foreign objects into the valve outlet. It may damage the valve and cause leak, leaking gas may result in fire, explosion, heavy body injury, or even death. Do not connect this grill to the self-contained LP gas system of a motor home or camper trailer.

  • Page 16: Leak Testing

    LEAK TESTING GENERAL Although all gas connections on the grill are leak tested at the factory prior to shipment, a complete gas tightness check must be performed at the installation site due to, possible mishandling in shipment, or excessive pressure unknowingly being applied to the unit.

  • Page 17: Final Installation Checklist

    LEAK TESTING SAFETY TIPS: 1) ALWAYS CHECK FOR LEAKS AFTER EVERY LP TANK CHANGE. 2) ALWAYS CHECK FOR LEAKS BEFORE EACH USE. 3) USE LONG BBQ TOOL TO AVOID BURNS. 4) CHECK ALL GAS SUPPLY FITTINGS FOR LEAKS BEFORE EACH USE. IT IS HANDY TO KEEP A SPRAY BOTTLE OF SOAPY WATER NEAR THE SHUT-OFF VALVE OF THE GAS SUPPLY LINE.

  • Page 18: Grill Lighting Instruction

    GRILL LIGHTING INSTRUCTION VERY IMPORTANT: ALWAYS INSPECT THE HOSE PRIOR TO EACH USE. BEFORE LIGHTING: Inspect the gas supply hose before turning the gas “ON”. If there is evidence of cuts, wear, or abrasion, it must be replaced before use. The replacement hose assembly must be that specified by the manufacturer.
  • Page 19 GRILL LIGHTING INSTRUCTION FLAME CHARACTERISTICS: 1) Check for proper burner flame characteristics. Each burner is adjusted prior to shipment; however, variations in the local gas supply may take subtle necessary adjustments. 2) Burner flames should be blue and stable with small yellow tips, no excessive noise, or lifting.

  • Page 20: Operating Instruction

    OPERATING INSTRUCTION CAUTION Clean the grill often. A grease fire that may damage the grill may occur if the grill has not been cleaned frequently. NEVER leave the grill unattended while using. Do not use water to extinguish the grease fire, it may cause body injury. Turn knobs off and LP tank off in case grease fire occurs.
  • Page 21 OPERATING INSTRUCTION TOTAL GAS CONSUMPTION: Total gas consumption (per hour) of PG-50506SRLA-SC grill with all burners on “HI”: Main burners 60,000 Btu/hr Total 60,000 Btu/hr GENERAL USE OF THE GRILL: The grill burners encompass the entire cooking area and are side ported to minimize blockage from falling grease and debris.

  • Page 22: Care & Maintenance

    CARE & MAINTENANCE MAINTENANCE 1) Keep the grill area clear and free from combustible materials, gasoline and other flammable vapors and liquids. 2) Keep the holes in the three sides of the cart clear and free from debris, thus ensure the flow of combustion and ventilation air is unobstructed. 3) Visually check burner flames as following: - Remove cooking grids and flame tamers.

  • Page 23: Trouble Shooting

    TROUBLE SHOOTING SPIDER AND INSECT WARNING Spiders and insects can nest in the burners after storing. These nests can cause fires inside the tube or beneath the grill. This is a very dangerous condition. So always clean the burners before use. WHEN TO LOOK FOR SPIDERS Inspect the burners at least once a year or immediately if any of the following conditions occur:...

  • Page 24: Food Safety

    FOOD SAFETY FOOD SAFETY: 1) Always follow the following tips to enjoy safe and healthy outdoor grilling. 2) Always use hot soapy water to wash hands, surfaces & utensils after processing raw meat. 3) Always separate raw meat from cooked foods to avoid cross-contamination. 4) Always use clean utensils to handle the food.

  • Page 25: Product Registration

    Product Registration form and (1) fax the form and a copy of your receipt to FAX # 909-287-0733, or (2) mail the form and a copy of your receipt to PermaSteel Inc, 14231 Fern Ave, Building 10, Chino, CA 91710.
  • Page 26 PERMASTEEL, INC. 14231 Fern Ave, Building 10 CHINO, CA 91710 TEL: (888)-287-0735 FAX: (909)-287-0733 EMAIL: SERVICE@PERMASTEEL.NET...
