PERMASTEEL PG-50410S0LB User Manual

Gas grill
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
GAS GRILL USER'S MANUAL
MODEL NUMBER: PG-50410S0LB
CUSTOMER SERVICE: (888)-287-0735
DANGER
If you smell gas:
1.
Shut off gas to the appliance.
2.
Extinguish any open flame.
3.
Open lid.
4.
If odor continues, keep away from the
appliance and immediately call your gas
supplier or your fire department.
FOR OUTDOOR USE ONLY
WARNING
1.
Do not store or use gasoline or other
flammable liquids or vapors in the
vicinity of this or any other appliance.
2.
An LP cylinder not connected for use
shall not be stored in the vicinity of this
TM
or any other appliance.

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the PG-50410S0LB and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for PERMASTEEL PG-50410S0LB

Summary of Contents for PERMASTEEL PG-50410S0LB

  • Page 1 FOR OUTDOOR USE ONLY GAS GRILL USER’S MANUAL MODEL NUMBER: PG-50410S0LB CUSTOMER SERVICE: (888)-287-0735 DANGER WARNING If you smell gas: Do not store or use gasoline or other Shut off gas to the appliance. flammable liquids or vapors in the Extinguish any open flame.
  • Page 2 Product. If your Product is defective or otherwise requires service or parts, please first call PermaSteel Customer Service toll-free at (888)-287-0735, between 8:00 a.m. and 5:00 p.m., PST. Please tell us which model you purchased, the date of purchase, and the problem with your Product.

  • Page 3: Table Of Contents

    TABLE OF CONTENTS BEFORE YOU BEGIN MESSAGE TO OUR USERS PAGE 1 SAFETY SYMBOLS PAGE 1 INSTALLATION & SAFETY PRECAUTIONS PAGE 2 ASSEMBLY PARTS PAGE 3 STEP I PAGE 5 STEP II & STEP III PAGE 6 STEP IV & STEP V PAGE 7 STEP VI &...

  • Page 4: Message To Our Users

    MESSAGE TO OUR USERS Thank you for your purchase of our Stainless Steel BBQ Gas Grill. We sincerely wish you will enjoy using our fine products. Please read this User’s Manual in its entirety before using the grill. Please contact our customer service at (888)-287-0735 if you have any questions. Please read this User’s Manual carefully.

  • Page 5: Installation/Safety Precautions

    This grill is safety certified for use in the United States and Canada only. Never modify to use in other places. Modification may cause serious bodily injury or property damage. PermaSteel is not responsible for any modifications, and all warranties will be void.

  • Page 6: Parts

    GRILL PARTS DIAGRAM Notice: This part list is for your reference only, some parts will be different, please subject to the actual appliance in carton.
  • Page 7 GRILL PARTS LIST REF# DESCRIPTION Q'TY REF# DESCRIPTION Q'TY Motor Temp. Gauge Seat Motor Bracket Temp. Gauge Left Side Shelf Name Plate Left Side Shelf Bracket Clip Rings Towel Rack Heat Insulation Seats Lid Hinge, Side Burner Left Handle Seat Side Burner Lid Right Handle Seat Cooking Grid, Side Burner...

  • Page 8: Step Ipage

    ASSEMBLY INSTRUCTIONS Tools Required: #2 Philips head screwdriver (not provided) Hexagon/Allen wrench (provided). The following hardware is provided: wheItem Description Specification Quantity Truss head screw 1/4-20x5/8” 16 pcs (With Split lock And Gasket) Truss head screw 1/4-20x1/2” 32 pcs (With Split lock And Gasket) Truss head screw 5/32-32x1/2”...

  • Page 9: Step Ii & Step

    ASSEMBLY INSTRUCTIONS STEP II: Use 2 pcs of 5/32"-32x1/2” screws to attach the door magnet on the bottom. Use 2 pcs of 1/4”-20x1/2” screws to attach the back panel on the bottom. Use 3 pcs of 1/4”-20x1/2” screws to attach the left side panel on the bottom. Use 3 pcs of 1/4”-20x1/2”...

  • Page 10: Step Vi & Step

    ASSEMBLY INSTRUCTIONS STEP IV : Use 2 pcs of 5/32"-32x3/8” screws to attach the tank baffle on the left side panel. Use 2 pcs of 1/4"-20x1/2” screws to attach the 2 small tank holder brackets which fix tank holder on right side panel. Hook one end of tank strap to tank holder. STEP V : Place door hinge rods through door spine holes, align upper side of door hinges with holes on door bracket, then insert bottom end of door hinges(flared end) into...

  • Page 11: Step Vii

    ASSEMBLY INSTRUCTIONS STEP VI: Take out grill head from carton, and place it onto the cart. Use 2 pcs of 1/4-20x1-1/2” screws to screw grill head on cart. Use 6 pcs of 1/4-20x1-1/2” screws to screw grill head to cart from bottom of firebox, going through holes on side panels.
  • Page 12 ASSEMBLY INSTRUCTIONS STEP VIII: Take out left side shelf carton from firebox, remove packing materials. Use two 1/4-20 x 1/2” screws to attach left side shelf from inside of firebox. Use one 1/4-20 x 1/2” screws to attach left side shelf from outside of firebox. Use one 5/32-32 x2/5”...

  • Page 13: Step Ix:

    ASSEMBLY INSTRUCTIONS STEP IX: Take out right side shelf carton from cart, remove packing materials. Use two 1/4-20 x 1/2” screws to attach right side shelf from inside of firebox. Use one1/4-20 x1/2” screw to attach right side shelf from outside of firebox.
  • Page 14 ASSEMBLY INSTRUCTIONS STEP X: 1) Take out the side burner valve from the square hole of right side panel. 2) Remove the packing materials. 3) Pull out the knob from side burner valve. 4) Unscrew two M4*6 screws from gas valve. 5) Unscrew the 4 screws on side burner bracket A&...
  • Page 15 ASSEMBLY INSTRUCTIONS 7) Place side burner valve in back of side burner control panel. Make sure valve stem comes through large hole of the panel. 8) Secure gas valve to panel using the M4*6 screws which take off on Step 4. 9) Replace the side burner, placing end of burner over side burner valve.
  • Page 16 ASSEMBLY INSTRUCTIONS STEP XI: Take out rotisserie rod from bottom panel packing foam, also forks from the carton in side shelves. Slide the two forks ( forks should be pointing toward each other) on to the rod. Remove packing material from cooking grids, warming rack, then place them in the proper positions shown below.

  • Page 17: Step Xiii

    ASSEMBLY INSTRUCTIONS STEP XIII: When the grill is in the desired location, lock the caster brakes, this will keep the grill unit in place for safe operation.

  • Page 18: Gas Connection

    GAS CONNECTION ONLY USE THE REGULATOR AND HOSE ASSEMBLY PROVIDED WITH THIS GRILL. REPLACEMENT PRESSURE REGULATORS AND HOSE ASSEMBLIES MUST BE THOSE SUPPLIED BY THE MANUFACTURER This is a LP (Liquefied Petroleum Gas) configured grill. Do not attempt to use a natural gas supply unless the grill has been reconfigured for natural gas use.
  • Page 19 GAS CONNECTION CONNECT THE REGULATOR TO THE LP TANK VERY IMPORTANT: - THE REGULATOR SHALL NOT BE IN A LOCATION THAT WILL ATTAIN A TEMPERATURE ABOVE 140℉（60℃）. - THE REGULATOR SHALL INCORPORATE A PRESSURE RELIEF VALVE OR OVERPRESSURE DEVICE. - THE INLET OF THE PRESSURE REGULATOR SHALL BE FITTED TO CONNECT THE TYPE I CONNECTION OF THE TANK VALVE PER ANSIZ21.81.
  • Page 20 GAS CONNECTION WARNING Never insert any foreign objects into the valve outlet. It may damage the valve and cause leak, leaking gas may result in fire, explosion, heavy body injury, or even death. Do not connect this grill to the self-contained LP gas system of a motor home or camper trailer.

  • Page 21: Leak Testing

    LEAK TESTING GENERAL Although all gas connections on the grill are leak tested at the factory prior to shipment, a complete gas tightness check must be performed at the installation site due to possible mishandling in shipment or excessive pressure unknowingly being applied to the unit.

  • Page 22: Final Installation Checklist

    LEAK TESTING SAFETY TIPS: 1) ALWAYS CHECK FOR LEAKS AFTER EVERY LP TANK EXCHANGE. 2) ALWAYS CHECK FOR LEAKS BEFORE EACH USE. 3) CHECK ALL GAS SUPPLY FITTINGS FOR LEAKS BEFORE EACH USE. IT IS HANDY TO KEEP A SPRAY BOTTLE OF SOAPY WATER NEAR THE SHUT-OFF VALVE OF THE GAS SUPPLY LINE.

  • Page 23: Grill Lighting Instruction

    GRILL LIGHTING INSTRUCTION VERY IMPORTANT: ALWAYS INSPECT THE HOSE PRIOR TO EACH USE. BEFORE LIGHTING: Inspect the gas supply hose before turning the gas “ON”. If there is evidence of cuts, wear, or abrasion, it must be replaced before use. The replacement hose assembly must be that specified by the manufacturer.
  • Page 24 GRILL LIGHTING INSTRUCTION Usage: 1) Read instructions before lighting. 2) Open the lid during lighting. 3) Strike the match and place approximately 1/2” above lighting hole located on right and left hand side of the grill body. 4) Push and turn the knob to “HI” position, make sure the burner lights and stays lighted.

  • Page 25: Operating Instruction

    OPERATING INSTRUCTION CAUTION Clean the grill often. A grease fire that may damage the grill may occur if the grill has not been cleaned frequently. NEVER leave the grill unattended while in use. Do not use water to extinguish the grease fire, it may cause bodily injury. Turn knobs off and LP tank off in case grease fire occurs.
  • Page 26 OPERATING INSTRUCTION TOTAL GAS CONSUMPTION: Total gas consumption (per hour) of PG-50410S0LB grill with all burners on “HI”: Main burners 36,000 Btu/hr Side burner 12,000 Btu/hr Searing burner 10,000 Btu/hr Total 58,000 Btu/hr GENERAL USE OF THE GRILL: The grill burners encompass the entire cooking area and are side ported to minimize blockage from falling grease and debris.
  • Page 27 OPERATING INSTRUCTION WARNING ELECTRICAL GROUNDING INSTRUCTIONS This grill is equipped with a three-prong (grounded) plug for your protection against, and should be plugged directly into a properly grounded three-prong receptacle. Do not cut or remove the grounding prong. Keep any electrical supply cords and the fuel supply hose away from any heated surfaces.

  • Page 28: Care & Maintenance

    CARE & MAINTENANCE MAINTENANCE 1) Keep the grill area clear and free from combustible materials, gasoline and other flammable vapors and liquids. 2) Keep the holes in the three sides of the cart clear and free from debris, thus ensure the flow of combustion and ventilation air is unobstructed. 3) Visually check burner flames as following: - Remove cooking grids and flame tamers.

  • Page 29: Trouble Shooting

    TROUBLE SHOOTING SPIDER AND INSECT WARNING Spiders and insects can nest in the burners after storing. These nests can cause fires inside the tube or beneath the grill. This is a very dangerous condition. Always clean the burners before use. WHEN TO LOOK FOR SPIDERS Inspect the burners at least once a year or immediately if any of the following conditions occur: 1) Yellow flame with burning smell.

  • Page 30: Food Safety

    FOOD SAFETY FOOD SAFETY: 1) Always follow the following tips to enjoy safe and healthy outdoor grilling. 2) Always use hot soapy water to wash hands, surfaces & utensils after processing raw meat. 3) Always separate raw meat from cooked foods to avoid cross-contamination. 4) Always use clean utensils to handle the food.

  • Page 31: Product Registration

    Product Registration form and (1) fax the form and a copy of your receipt to FAX # 909-287-0733, or (2) mail the form and a copy of your receipt to PermaSteel Inc, 14231 Fern Ave, Building 10, Chino, CA 91710.
  • Page 32 PERMASTEEL, INC. 14231 Fern Ave, Building 10 CHINO, CA 91710 TEL: (888)-287-0735 FAX: (909)-287-0733 EMAIL: SERVICE@PERMASTEEL.NET...
