PERMASTEEL PG-50506SRLA User Manual

Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
USER'S MANUAL
MODEL NUMBER: PG-50506SRLA
CUSTOMER SERVICE: (888)-287-0735
DANGER
If you smell gas:
1.
Shut off gas to the appliance.
2.
Extinguish any open flame.
3.
Open lid.
4.
If odor continues, keep away from the
appliance and immediately call your gas
supplier or your fire department.
FOR OUTDOOR USE ONLY
WARNING
1.
Do not store or use gasoline or other
flammable liquids or vapors in the
vicinity of this or any other appliance.
2.
An LP cylinder not connected for use
shall not be stored in the vicinity of this
TM
or any other appliance.

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the PG-50506SRLA and is the answer not in the manual?

Questions and answers

Related Manuals for PERMASTEEL PG-50506SRLA

Summary of Contents for PERMASTEEL PG-50506SRLA

  • Page 1 FOR OUTDOOR USE ONLY USER’S MANUAL MODEL NUMBER: PG-50506SRLA CUSTOMER SERVICE: (888)-287-0735 DANGER WARNING If you smell gas: Do not store or use gasoline or other Shut off gas to the appliance. flammable liquids or vapors in the Extinguish any open flame.
  • Page 2 Product. If your Product is defective or otherwise requires service or parts, please first call PermaSteel Customer Service toll-free at (888)-287-0735, between 8:00 a.m. and 5:00 p.m., PST. Please tell us which model you purchased, the date of purchase, and the problem with your Product.

  • Page 3: Table Of Contents

    TABLE OF CONTENTS BEFORE YOU BEGIN MESSAGE TO OUR USERS PAGE 1 SAFETY SYMBOLS PAGE 1 INSTALLATION & SAFETY PRECAUTIONS PAGE 2 PROPANE & GAS WARNING PAGE 2 ASSEMBLY PARTS PAGE 3 STEP I PAGE 6 STEP II & STEP III PAGE 7 STEP IV &...

  • Page 4: Message To Our Users

    MESSAGE TO OUR USERS Thank you for your purchase of our Stainless Steel BBQ Gas Grill. We sincerely wish you will enjoy using our fine products. Please read this User’s Manual in its entirety before using the grill. Please contact our customer service at (888)-287-0735 if you have any questions. Please read this User’s Manual carefully.

  • Page 5: Installation/Safety Precautions

    This grill is safety certified for use in the United States and Canada only. Never modify to use in other places. Modification may cause serious bodily injury or property damage. PermaSteel is not responsible for any modifications, and all warranties will be void.

  • Page 6: Parts

    GRILL PARTS DIAGRAM...
  • Page 7 GRILL PARTS LIST REF# DESCRIPTION Q’TY REF# DESCRIPTION Q’TY Double-layer Lid Acorn Nut Temp. Gauge Seat Rotary Pin Temp. Gauge Back Panel Clip Rings Hole Bushing Name Plate Rear Burner Cover Handle Seat Thermocouple Cover Handle thermocouple Bracket Rotiesserie Kit Firebox Somker Cover Corrugated Pipe B...
  • Page 8 GRILL PARTS DIAGRAM REF# Parts of Left Cabinet CounterTop Motor Bracket Back Panel Cross Bar Magnets Left Side Panel Drawer Brackets Sliding Bars Drawer Seat Drawer Transom Right Side Panel Drawer Front Panel Drawer Handle Seats Drawer Handle Upper Door Hinge Left Door Handle Left Door Door Transom...

  • Page 9: Step Ipage

    ASSEMBLY INSTRUCTIONS Tools Required: #2 Philips head screwdriver (not provided) Hexagon/Allen wrench (provided). The following hardware is provided with island sides. Item Description Specification Quantity Truss head screw 1/4-20x1/2” 2 pcs (With Split lock And Gasket) STEP I: Take out grill body and the cabinets from packing carton, and remove all the packing materials.

  • Page 10: Step Ii & Step

    ASSEMBLY INSTRUCTIONS STEP II : Place the motor bracket to the left side cabinet with 2 pcs of 1/4-20*1/2 screws. STEP III : Remove packing material from flame tamers, cooking grids, warming rack, then place them in the proper positions shown below.

  • Page 11: Step Vi & Step

    ASSEMBLY INSTRUCTIONS STEP IV : When the grill is in the desired location, lock the caster brakes, this will keep the grill unit in place for safe operation. STEP V : Place the side cabinets close to grill, make them on the same line.
  • Page 12 ASSEMBLY INSTRUCTIONS STEP VI: Take out rotisserie parts from carton. Tread key washers and counter balance onto treaded end of rotisserie rod ,next tread handle and tighten, slide shaft collar through other side of rod followed by the two prongs, (forks should be pointing towards each other) tighten thumb screws on shaft collar and prongs.

  • Page 13: Satety Notice

    ASSEMBLY INSTRUCTIONS Safety Notice: The regulator hose(natural gas hose) should go through the U shaped bracket, in order to prevent the hose from lifting up and touching the hot firebox. Note: if replacing regulator (natural gas hose) please make sure to put regulator hose (natural gas hose) through U shape bracket.

  • Page 14: Gas Connection

    GAS CONNECTION ONLY USE THE REGULATOR AND HOSE ASSEMBLY PROVIDED WITH THIS GRILL. REPLACEMENT PRESSURE REGULATORS AND HOSE ASSEMBLIES MUST BE THOSE SUPPLIED BY THE MANUFACTURER This is a LP (Liquefied Petroleum Gas) configured grill. Do not attempt to use a natural gas supply unless the grill has been reconfigured for natural gas use.
  • Page 15 GAS CONNECTION CONNECT THE REGULATOR TO THE LP TANK VERY IMPORTANT: - THE REGULATOR SHALL NOT BE IN A LOCATION THAT WILL ATTAIN A TEMPERATURE ABOVE 140℉（60℃）. - THE REGULATOR SHALL INCORPORATE A PRESSURE RELIEF VALVE OR OVERPRESSURE DEVICE. - THE INLET OF THE PRESSURE REGULATOR SHALL BE FITTED TO CONNECT THE TYPE I CONNECTION OF THE TANK VALVE PER ANSIZ21.81.
  • Page 16 GAS CONNECTION WARNING Never insert any foreign objects into the valve outlet. It may damage the valve and cause leak, leaking gas may result in fire, explosion, heavy body injury, or even death. Do not connect this grill to the self-contained LP gas system of a motor home or camper trailer.

  • Page 17: Leak Testing

    LEAK TESTING GENERAL Although all gas connections on the grill are leak tested at the factory prior to shipment, a complete gas tightness check must be performed at the installation site due to, possible mishandling in shipment, or excessive pressure unknowingly being applied to the unit.

  • Page 18: Final Installation Checklist

    LEAK TESTING SAFETY TIPS: 1) ALWAYS CHECK FOR LEAKS AFTER EVERY LP TANK CHANGE. 2) ALWAYS CHECK FOR LEAKS BEFORE EACH USE. 3) USE LONG BBQ TOOL TO AVOID BURNS. 4) CHECK ALL GAS SUPPLY FITTINGS FOR LEAKS BEFORE EACH USE. IT IS HANDY TO KEEP A SPRAY BOTTLE OF SOAPY WATER NEAR THE SHUT-OFF VALVE OF THE GAS SUPPLY LINE.

  • Page 19: Grill Lighting Instruction

    GRILL LIGHTING INSTRUCTION VERY IMPORTANT: ALWAYS INSPECT THE HOSE PRIOR TO EACH USE. BEFORE LIGHTING: Inspect the gas supply hose before turning the gas “ON”. If there is evidence of cuts, wear, or abrasion, it must be replaced before use. The replacement hose assembly must be that specified by the manufacturer.
  • Page 20 GRILL LIGHTING INSTRUCTION FLAME CHARACTERISTICS: 1) Check for proper burner flame characteristics. Each burner is adjusted prior to shipment; however, variations in the local gas supply may take subtle necessary adjustments. 2) Burner flames should be blue and stable with small yellow tips, no excessive noise, or lifting.

  • Page 21: Operating Instruction

    OPERATING INSTRUCTION CAUTION Clean the grill often. A grease fire that may damage the grill may occur if the grill has not been cleaned frequently. NEVER leave the grill unattended while using. Do not use water to extinguish the grease fire, it may cause body injury. Turn knobs off and LP tank off in case grease fire occurs.
  • Page 22 OPERATING INSTRUCTION TOTAL GAS CONSUMPTION: Total gas consumption (per hour) of PG-50506SRLA grill with all burners on “HI”: Main burners 60,000 Btu/hr Rotisserie burner 12,000 Btu/hr Total 72,000 Btu/hr GENERAL USE OF THE GRILL: The grill burners encompass the entire cooking area and are side ported to minimize blockage from falling grease and debris.

  • Page 23: Care & Maintenance

    OPERATING INSTRUCTION WARNING ELECTRICAL GROUNDING INSTRUCTIONS This grill is equipped with a three-prong (grounding) plug for your protection against, and should be plugged directly into a properly grounded three-prong receptacle. Do not cut or remove the grounding prong. Keep any electrical supply cords and the fuel supply hose away from any heated surfaces.
  • Page 24 CARE & MAINTENANCE MAINTENANCE (CONTINUED) 4) Call our after service center at (888)-287-0735 for warranty replacement parts. CLEANING STAINLESS STEEL CLEANING The grill is made of stainless steel. There are many different stainless steel cleaners available. Always use the mildest cleaning procedure first, scrubbing in the direction of the grain.

  • Page 25: Trouble Shooting

    TROUBLE SHOOTING SPIDER AND INSECT WARNING Spiders and insects can nest in the burners after storing. These nests can cause fires inside the tube or beneath the grill. This is a very dangerous condition. So always clean the burners before use. WHEN TO LOOK FOR SPIDERS Inspect the burners at least once a year or immediately if any of the following conditions occur:...

  • Page 26: Food Safety

    FOOD SAFETY FOOD SAFETY: 1) Always follow the following tips to enjoy safe and healthy outdoor grilling. 2) Always use hot soapy water to wash hands, surfaces & utensils after processing raw meat. 3) Always separate raw meat from cooked foods to avoid cross-contamination. 4) Always use clean utensils to handle the food.
  • Page 27 Product Registration form and (1) fax the form and a copy of your receipt to FAX # 909-287-0733, or (2) mail the form and a copy of your receipt to PermaSteel Inc, 14231 Fern Ave, Building 10, Chino, CA 91710.
  • Page 28 PERMASTEEL, INC. 14231 Fern Ave, Building 10 CHINO, CA 91710 TEL: (888)-287-0735 FAX: (909)-287-0733 EMAIL: SERVICE@PERMASTEEL.NET...

This manual is also suitable for:

Pg-50506srl-sc-1
