DVD and Blu-ray Disc:
CD and SACD:
In addition to the playback time, the on-screen display may also contain the following information about the content currently playing:
• Playback status: an icon indicating play, pause, and fast forward/reverse status.
• Bit rate meter: an indication of the bit rate of the audio and video stream.
• Current and total title numbers. (DVD and Blu-ray Discs)
• Current and total chapter numbers of the current title. (DVD and Blu-ray Discs)
• Current and total tracks. (CD and SACD)
• Audio information: current and total available number of audio tracks, language, format, and channels.
• Subtitle information: current and total available number of subtitle tracks and language.
• Video format information: encoding type, frame rate and original aspect ratio.
• HDMI output information: connection status, video resolution, frame rate, color space, audio format and channels.

Volume Control

On the UMT remote, the volume control buttons will control any MSB DAC with the volume option installed (if this feature does not
work, check your firmware code revision on the DAC and download an update.)
• Press the VOL – button to decrease the volume.
• Press the VOL + button to increase the volume.
NOTE: The volume setting shown on-screen has nothing to do with the MSB DAC volume and should be ignored.
Mute
1. Press the MUTE button on the remote control during content playback to turn off audio output. The TV screen displays a mute icon.
The front panel MUTE indicator will also light up.
2. Press the MUTE button again to resume audio output.
NOTE: Check the MUTE status on the front panel display of the player when there is no audio output. You may also press the MUTE
button to verify the MUTE status.

Audio Language/Track Selection

1. To select the audio language or track, press the AUDIO button on the remote control during playback.
2. Repeat pressing the AUDIO button or use the UP/DOWN ARROW buttons to choose from all available language or audio tracks.
NOTE: Availability of languages and audio channels varies by disc. Some DVD-Audio discs allow audio track selection with the AUDIO
button, while others require the user to select from the audio setup menu of the disc. When playing an SACD with both multi-channel
and stereo contents, the AUDIO button can be used to switch between the two formats.

Subtitle Selection

1. When playing a DVD, Blu-ray Disc or other video programs recorded with subtitles, press the SUBTITLE button on the remote control
to select the desired subtitle.
2. Repeat pressing the SUBTITLE button or use the UP/DOWN ARROW buttons to choose from all available subtitles.
3. To turn off subtitles, select "Off" from the list.
NOTE: This function is available only when the discs are recorded with multiple angles. The angle mark on the screen can be turned
off using the Setup Menu of the player.

HDMI / MHL Input

Disabled
- Title elapsed time
- Title remaining time
- Track elapsed time
- Track remaining time
30
- Chapter elapsed time
- Chapter remaining time
- Disc elapsed time
- Disc remaining time
