MyTek 8X192 ADDA User Manual page 15

FORMAT CONVERSION OPERATION.
7.
ADC IS OFF, DIGITAL IN TO DIGITAL OUT, DA MONITORING DIGITAL IN.
In this mode the 8X192 unit can be used for format conversion between all installed digital interfaces.
Once a digital input is selected for "SOURCE TO DIGITAL", the "SAMPLE RATE" switch is disabled and
EXT.CLOCK SOURCE and SOURCE TO ANALOG OUT automatically set to selected digital input. The
incoming digital signal is converted to all available digital formats simultanouesly as well as is sent to DA
converter for monitoring. The wck divider affects only WCK outs. WCK is derives from incoming digital
input, in this example DIOCARD1.
LED ON
LED OFF
