Summary of Contents for Gefen HDMI Switcher
- Page 1 HDMI Switcher U S E R M A N U A L www.gefen.com...
- Page 2 6265 Variel Ave. Woodland Hills, CA 91367-9897 Notice Gefen Inc. reserves the right to make changes in the hard ware, packaging and any accompanying doc u men ta tion without prior written notice. HDMI Switcher is a trademark of Gefen Inc.
-
Page 3: Table Of Contents
TABLE OF CONTENTS Introduction Features Panel Descriptions Connecting and Operating the HDMI Switcher RMT2-IR Installation IR Confl ict Codes IR Extender Installation Specifi cations Warranty... -
Page 4: Introduction
Our Commitment Gefen will always offer the fi nest quality product at the best possible price. Included in that price is a lifetime of support from a team of outstanding engineers. The ex•tend•it HDMI Switcher allows two HDMI devices to be switched easily in to one HDMI compatible monitor or projector. -
Page 5: Features
• Extends any HDMI compliant device by regenerating the HDMI signal • Maintains high resolution video—beautiful, sharp HDTV resolutions up to 1080P are easily achieved. For computer users, the 2x1 HDMI Switcher conforms with HDMI specifi cations for resolutions up to 1920 x 1200. -
Page 6: Panel Descriptions
PANEL DESCRIPTIONS Connects to IR Indicates if port 1 or Selects port 1 IR eye extender port 2 is selected or port 2 HDMI Out HDMI In 2 Connects to HDMI In 1 5VDC power supply... -
Page 7: Connecting And Operating The Hdmi Switcher
2 Connect the cable from your display (monitor or projector) into the HDMI Out of the HDMI Switcher. 3 Plug the 5VDC power supply into the HDMI Switcher. How to Operate the HDMI Switcher 1 Use the front panel push button to switch between sources. -
Page 8: Rmt2-Ir Installation
1-4 will have to be repeated. Note: The RMT2-IR ships with two batteries. One battery is required for operation, the second battery is complimentary. The optional IR extender allows you to re- locate your HDMI Switcher and still have IR control of the HDMI Switcher... - Page 9 IR Code Confl icts How to Resolve IR Code Confl icts There are matching pairs of dip switches underneath the Switcher unit (outlined below) and under the remote battery cover. Each has two switches which need to be matched for the remote to work.
-
Page 10: Ir Extender Installation
IR Extender Installation How to Connect the IR Extender 1 Plug the IR extender into the Remote port on the front of the Switcher Unit 2 Flip the Dip Switch #1 underneath the unit from the set that is not outlined on the previous page to the ON position... -
Page 11: Specifi Cations
SPECIFICATIONS Video Amplifi er Bandwidth ................1.65 Gbps Input Video Signal ..................1.2 volts p-p Input DDC Signal ..................5 volts p-p (TTL) Single Link Range ..................1920 x 1200 HDMI Input/Output Connector Type ..........Type A (19 pin) female Power Consumption ................ -
Page 12: Warranty
If equipment fails because of such defects and Gefen Inc. is notifi ed within one (1) year from the date of shipment, Gefen Inc. will, at its option, repair or replace the equipment, provided that the equipment has not been subjected to mechanical, electrical, or other abuse or modifi... - Page 13 6265 Variel Avenue Woodland Hills, CA 91367 1-800-545-6900 818-884-6294 fax: 818-884-3108 www.gefen.com gsinfo@gefen.com...
