- Page 1 Instruction Manual Portable Air Conditioner Model: WA-9010E It is important that you read these instructions before using your portable air conditioner and we strongly recommend that you keep them in a safe place for future reference. Sales Inquiries - 800-934-9194...
-
Page 2: Table Of Contents
TABLE OF CONTENTS Thank you and energy saving tips Introduction..........1 P a r t s a n d a c c e s s o r i e s ........2 Installation........... -
Page 3: Thank You
THANK YOU! Thank you for choosing the portable air conditioner from SPTusa, a leading brand in indoor air treatment. We would like you to enjoy the many benefits this unit offers, so please take the time to read this manual carefully and take full advantage of the many advanced features that your SPTusa Air Conditioner offers you. -
Page 4: Introduction
INTRODUCTION Portable Air Conditioner This Portable Air Conditioner is a small size appliance, which can adjust the temperature and humidity in a room. Its flexibility characteristics make it easily used on different occasions in different rooms. It also has multiple functions, including cooling, dehumidifying and fan ventilation. - Page 5 ACCESSORIES, PARTS AND FUNCTIONS FRONT control panel up/down air swinging louvers left/right air swinging louvers air outlet handle water tank power cable caster BACK ACCESSORIES window kit x 2 upper air inlet grill AC/hose adapter x 2 hot air outlet grill lower air inlet grill flexible exhaust hose COOL DRY FAN...
-
Page 6: Installation
INSTALLATION Selection of installation location Place the portable air conditioner on a flat surface where the air outlets are not blocked. Place the unit with at least 20 inches of clearing from a wall or other obstacles. 32.7 inch Installing the air exhaust duct 1) Fix adaptors onto hose by turning clock-wise 2) Fix the square end of the duct to the exhaust terminal of the unit 3) Lead the other end to the nearest window. - Page 7 INSTALLATION Correct mounting shown below. If mounting through wall, the height of the hole should be between 16 ~ 51 inches from the floor. fig. 23 51 inch 16 inch If the air exhaust requires bending, use the following as a guideline: 20 inch 24 inch 20 inch...
- Page 8 INSTALLATION Example WRONG mounting diagram (Air exhaust bend is too large, will cause overheating.) Window Kit Installation Your window kit has been designed to fit most standard "vertical" and "horizontal" window applications. However, it may be necessary for you to improvise/modify some aspects of the installation procedures for certain types of windows.
- Page 9 INSTALLATION Installation Accessories (Fig. 25) Fig. 25 Flexible exhaust hose with adapters..3/set stretches from 19 1/2" to 78 3/4" Window exhaust adapter (flat mouth )..1pc Unit exhaust adapter (round) .....1pc Adjustable window slider kit.....2/set from 26 5/8" to 48 3/8" Drain hose connector........1pc continuous drain option (hose not included) NOTE: Exterior drain hose extension is not...
-
Page 10: Control Panel Functions
CONTROL PANEL FUNCTIONS TIMER Button SWING Button FAN SPEED Button MODE Button Press this button to Press this button will select Selection of this button Press this button will switch-on, switch-off or among the modes of will determine the air choose high, medium delete timer. - Page 11 OPERATION AND FUNCTIONS OF REMOTE CONTROL Display screen ON/OFF Button Temperature setting button Turns the unit ON or OFF. Sets the room temperature. Each press of the " " or COOL DRY FAN " " button, the temperature setting is increased or MODE selection decreased by 1 button...
-
Page 12: Operating The Unit
OPERATING THE UNIT DEHUMIDIFYING AND COOLING OPERATION The operating range for cooling is between 63 F ~ 88 The operating range for dehumidifying is 68 F ~ 88 POWER SOURCE * The AC socket must be firm and reliable. * Do not connect the portable air conditioner to a multiple socket outlet that is shared with other electrical appliances. -
Page 13: Drainage
USE OF CONTROL PANEL TIMER SETTING To set time to start the unit when power is off (but with power supplied): 1. Press " " button, the LCD window will show " ". 2. Press the TIME button and set the number of hours you wish to start running the unit. For example, if you wish to have the unit start in 8 hours, press the TIME button repeatedly until 8 hours is indicated. -
Page 14: Water Drainage Methods
WATER DRAINAGE METHODS f i g . 2 f i g . 3 CAUTION 1. When in cooling or dehumidifying mode, do not remove the water tank, or the compressor will stop and mode will change to FAN. 2. If you want to take out the tank before the water becomes full, please stop the machine first and wait for 3 minutes, to prevent the water spilling into the unit 3. -
Page 15: Maintenance
MAINTENANCE MAINTENANCE METHODS * Unplug the unit before cleaning * Make sure there is no power to the unit before beginning to maintain or repair, to prevent accident caused by electric shock. * Do not use chemical solvent (like benzene or alcohol glazer) to clean the surface of the unit, which will scratch, damage or deform the casing. - Page 16 MAINTENANCE KEEP SURFACE CLEAN Clean the surface of the unit with a damp cloth, then dry with duster or similar. WATER TANK 1. Hold the handle in water tank and draw out slowly. 2. Pour out the water. Clean with neutral detergent, rinse clean and dry.
-
Page 17: Storage
STORAGE END OF SEASON OPERATION & STORAGE 1. To remove drain water from the drain tank, take out the plug from the plastic pipe shown in Fig. 4. Then operate the unit in fan mode for half a day until the pipe is dry. - Page 18 SAFETY CAUTIONS * Do not use the unit in a very narrow room with obstacles to avoid breakdown. * Do not use the unit under direct sunlight to avoid surface color change. * Do not use the unit in or near water to avoid possible shock of electricity. * Do not use near gas appliances, fire or the vicinity of flammable liquids.
-
Page 19: Cautions
CAUTION Unplug and stop running immediately in case of the following and contact SPT at 1-800-330-0388: 1. The fuse and switch breaks often. 2. The power cord get excessively hot or the sleeve of the cord is broken. -
Page 20: Specification
SPECIFICATIONS Model Number WA-9010E Cooling Capacity 9,000BTU/hr Power Consumption 1,120W / 9.7A Humidity Removal Capacity 50 pts./day Recommended Room Size* 250 sq. ft. Power Supply 115V / 60HZ / 1 Phase Compressor Rotary Refrigerant R - 22 Fan Speed Timer... -
Page 21: Defective Notice
DEFECTIVE NOTICE If this product is defective or not working properly Please DO NOT return to your retail store Please contact us directly with any Service or Technical Assistance Contact us toll free at: 1-800-330-0388 Sales Inquiries - 800-934-9194... -
Page 22: Your Guarantee
The warranty applies to the use of this product in the United States. Warranty does not include freight charges. Note : For service, please call: 800-330-0388 or visit www.spt-usa.com SUNPENTOWN INT'L INC. This GUARANTEE is in addition to your Statutory Rights.
